CS1 CART
FOOT OPERATED UNDERPINNER
USER & PARTS MANUAL
READ THIS MANUAL CAREFULLY
BEFORE USING THE MACHINE
Version 1 06/ 2013
®
Cassese
/ Communication
Z26059

Advertisement

Table of Contents
loading

Related Manuals for Cassese CS1 CART

Summary of Contents for Cassese CS1 CART

  • Page 1 Inventor and World No.1 Manufacturer of Picture Framing Machines & Consumables Since 1976 CS1 CART FOOT OPERATED UNDERPINNER USER & PARTS MANUAL READ THIS MANUAL CAREFULLY BEFORE USING THE MACHINE Version 1 06/ 2013 ® Cassese / Communication Z26059...
  • Page 2 WORK POSITION REFERENCE PEDAL MAGNETIC ADJUSTABLE ROD CLAMP ASSEMBLY CROSSBAR STAPLING STOP TABLE Fig N°1 Fig N°2 AFTER UNPACKING THE MACHINE, SET THE 4 FEET TO LEVEL THE MACHINE Non contractual document - Cassese France ® - Document non contractuel...

  • Page 3: Table Of Contents

    CS1 CART - USER & PARTS MANUAL CONTENTS Page INTRODUCTION ACCESSORIES SUPPLIED WITH THE MACHINE TECHNICAL SPECIFICATIONS OF CS1 CART OPTIONS GUARANTEE ADJUSTMENTS SELECTION OF WEDGE POSITIONS 3, 4 SETTING AND STORING THE WEDGE POSITIONS PROPER ADJUSTMENT OF MAGNETIC ADJUSTABLE...
  • Page 4 Non contractual document - Cassese France ® - Document non contractuel...

  • Page 5: Introduction

    CS1 CART - USER & PARTS MANUAL INTRODUCTION Thanks for having purchased the CS1 CART underpinner and for your trust in &DVVHVH SURGXFWV 7KH &6 &$57 EHQH WV IURP &DVVHVH V H[SHULHQFH VLQFH  in designing and manufacturing highest quality underpinners, for which we are world-famous.

  • Page 6: Adjustments

    ADJUSTMENTS SELECTION OF WEDGE POSITIONS The CS1 CART is designed to join mouldings in one, two or more positions without limitation of the number of wedges in any of those places. The selection depends on the width and height of the moulding to join.
  • Page 7 Now the two positions of joining are set and the sliding table can move only within the limits of these two positions. position Last position Wedges between WKH UVW DQG WKH last position Non contractual document - Cassese France ® - Document non contractuel...

  • Page 8: Proper Adjustment Of Magnetic Adjustable Rod Clamp Assembly

    1 and 2. NEW MAGNETIC OPTIONAL ADJUSTABLE CLAMPS Z24703 = Now with quick-change magnetic clamps, it is easy to change from chevron to a round clamp. Z1791 = Z21525 Non contractual document - Cassese France ® - Document non contractuel...

  • Page 9: Use

    E\ WKHLU ZKLWH SODVWLF SXVKHU  +: IRU +$5':22' LGHQWL DEOH E\ WKHLU \HOORZ SODVWLF SXVKHU DQG 0') LGHQWL DEOH E\ WKHLU UHG SODVWLF SXVKHU RU UHG VWLFNHU RQ LQGLYLGXDO ER[HV  Your CS1 CART underpinner is designed for using all sizes of CASSESE ®...

  • Page 10: Joining The Frame

    E until wedge position stop handle 6 reaches the stapling stop 10 and repeat step 4. NOTE* : If stapling more than one wedge in any position is desired then repeat 4 step. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 11: Maintenance

    Periodically, remove the wedge distributor block and clean it with an air gun. It is recommended to lubricate the wedge driver blade (use the Cassese’s grease Z1896). To do so, you will have to remove the wedge distributor block with the 2,5mm Allen Key and perform this procedure.

  • Page 12: B) Cleaning And Lubrication Of The Wedge Distributor Block

    Tighten the locking screw of the wedge wedge distributor block on the wedge distributor block, paying attention to driver blade with the window facing the level it with the working table. cartridge channel. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 13: C) Removal Of The Wedge Driver Blade

    TO SLIDE THE WEDGE DRIVER BLADE UP WITH THE PEDAL step step Now, the wedge driver blade is pulled Push the pedal and maintain it. up so you can remove it from its place. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 14: D) Installation Of New Wedge Driver Blade

    Push the wedge driver blade fully in with a piece of wood or moulding ; press the pedal to engage the wedge driver blade entirely. Check the wedge driver blade installation, it should slide smooth with no resistance. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 15: E) Unjamming Of The Wedge Distributor Block

    -If the old wedge driver blade is damaged and remains in the machine : PERFORM THE PROCEDURE B STEP 1 TO STEP 5, THEN PROCEED TO PROCEDURE C + D COMPLETELY. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 16: F) Removing The Side Panel

    SHGDO RI LWV D[LV E\ and the pedal together to D[LV DQG SXW LW LQ YHUWLFDO pulling up. H[LW WKH PHFKDQLFDO SDUWV position. from the frame. Non contractual document - Cassese France ® - Document non contractuel...

  • Page 17: H) Replacement Of The Wedge Distribution Channel Elastic Cord

    ,Q RUGHU WR UH W WKH V\VWHP GR Unscrew the last screw with the following steps in the reverse the Allen key of 4mm. direction. Non contractual document - Cassese France ® - Document non contractuel...
  • Page 18 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 19 NOMENCLATURE / SPARE PARTS - CS1 CART Z26150 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 20 NOMENCLATURE / CLASSIFICATION CS1 CART Non contractual document - Cassese France ® - Document non contractuel...
  • Page 21 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 22 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 23 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 24 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 25 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 26 3UHQGUH OD &O« $OOHQ GH PP SRXU OHV YLV GH OD WDEOH 7KLV SURFHGXUH LV WKH VDPH IRU 81, &$57 XQGHUSLQQHUV  &HWWH SURF«GXUH HVW OD P¬PH SRXU OHV DVVHPEOHXVHV 81, &$57  r Non contractual document - Cassese France ® - Document non contractuel...
  • Page 27 AVANT / BEFORE APRES / AFTER Non contractual document - Cassese France ® - Document non contractuel...
  • Page 28  9HLOOH] ¢ JDUGHU OH P¬PH HVSDFH HQWUH  0HWWH] OD UDOORQJH GH WDEOH DX P¬PH FKDTXH F¶W« GH OD WDEOH SRXU «YLWHU OHV niveau de la table de travail de votre CS1 frottements. CART. Non contractual document - Cassese France ® - Document non contractuel...
  • Page 29 OPTIONAL ACCESSORIES ON THE CS1 CART ACCESSOIRES OPTIONNELS SUR LA CS1 CART Z22027 Z22027 Z25147 Z25147 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 30 OPTIONAL ACCESSORIES ON THE CS1 CART ACCESSOIRES OPTIONNELS SUR LA CS1 CART Z25450 Z25450 Non contractual document - Cassese France ® - Document non contractuel...
  • Page 31 Zone Industrielle  9(51(8,/ / (7$1*  )5$1&( 7HO         )D[        E-mail: cassese.sa@cassese.com EXPORT DEPARTMENT 7HO        )D[       ...
