- Page 1 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Installation Operation Maintenance Troubleshooting Version Dec/17 1655 Cuspidor Page 1 of 24...
-
Page 2: Table Of Contents
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Table of Contents Important Information ..........................4 Weight & Dimensions ........................... 6 Operator’s Instructions ......................... 7 Cleaning Your Cuspidor ........................8 Post Leveling............................9 Installation Instructions ........................10 Troubleshooting Guide ........................19 Parts List ............................... - Page 3 Palm Beach Cuspidor has been built with the finest materials available. The assembly and testing was completed by technicians devoted to making SDS products perform to all prescribed specifications. Our five year limited warranty is just one of the ways we express our confidence that you will be completely satisfied with your purchase.
-
Page 4: Important Information
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Important Information Technical Specifications Factory Pre-set Air Regulator Pressure: 80 PSI Factory Pre-set Water Regulator Pressure: 40 PSI Handpiece Pressure: 30-35 PSI (for most high-speed handpieces) 40-45 PSI (for most low-speed handpieces) Unpacking Pay careful attention when unpacking the cuspidor and its accessories. - Page 5 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com European Authorized Representative MT Promedt Consulting GmbH Altenhofstrasse 80 D-66386 St. Ingbert, Germany Phone: +49 (0)6894-581020 Fax: +49 (0)6894-581021 Questions? Read this manual carefully. If you have any questions, please call Summit Dental Systems Technical Service at 1-800.275.3368 (USA) or (954) 730-3636 (Outside USA).
-
Page 6: Weight & Dimensions
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Weight & Dimensions Shipping Information 13”/330.2mm 23.5”/596.9mm 39”/990.6mm Shipping Weight: 54 lbs/24.49mm General Dimensions 6.11” 8.89” 155.2mm 225.7mm 35.27” / 896mm Page 6 of 24... -
Page 7: Operator's Instructions
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Operator’s Instructions • A. Automatic Cup Fill Control Press and release cup fill button. The Cup Fill will automatically turn • B. Timed Bowl Rinse Press and release bowl rinse button. The Bowl Rinse will automatically turn off •... -
Page 8: Cleaning Your Cuspidor
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Cleaning Your Cuspidor Daily Maintenance At the end of every day. 1. Remove bowl screen from the cuspidor bowl and clean or discard (bio-hazard). 2. Raise the chair to its highest position and activate the bowl rinse several times, long enough for the water to flow down the drain for approximately 60 seconds. -
Page 9: Post Leveling
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Post Leveling 1. Install the post with the bushing at the top; be certain that the post bottoms in the post socket ad that the hole in the side of the post is facing toward the head of the chair. -
Page 10: Installation Instructions
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Installation Instructions Cup Fill & Bowl Rinse Spouts Stop Pin Clock Porcelain Bowl Solids Canister HVE & SE Hangers Clock Clock Drain Channel Assembly Cover 4 - ¼” Socket Set 4 ¼” 1. - Page 11 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com 4. Tighten the two lowest ¼” socket head screws making sure that the stop pin is at 5 clock position when cuspidor is at 12+6 clock position when mounted on chair. This position will stop the horizontal arm of the Palm Beach light at 6 clock.
- Page 12 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Test Bowl Rinse 1. Activate bowl rinse. 2. If bowl does not rinse long enough adjust 3-way bleed valve clockwise 3. If rinses to short turn 3-way bleed valve counter-clockwise Test Cup Fill 1.
- Page 13 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Junction Box Plumbing Layout Not to Scale Page 13 of 24...
- Page 14 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Cuspidor Umbilical Connections ƒ White 1/8” - spare ƒ Red 1/8” – from air filter housing to in port on master switch ƒ Yellow 1/8” – signal air from master switch to air operated solenoids in Junction ƒ...
- Page 15 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Umbilical Entering Tray Head Page 15 of 24...
- Page 16 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Utility Center Tubing Diagram Post and Swing Mounted Unit Water and Air Regulator Assembly Description Part # Description Part # ¼” Blue Tubing Wet & Dry Ft Ctrl 5-020-0058 5-070-0049 1/8” Blue Tubing Tubing, Sand 4H 5-070-0025 5-070-0028...
- Page 17 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Flow Diagram & Parts - Box Assembly Page 17 of 24...
- Page 18 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Flow Diagram & Parts - Housing Assembly Item Description Part # Cup Fill Spout 5-030-3006 Bowl Rinse Spout 5-030-3004 Cusp. Bowl Housing 2-020-3035 Egg, Syringe Holder 5-020-3003 2-Way Push Button Valve - Bowl Flush 5-030-0054 2-Way Push Button Valve –...
-
Page 19: Troubleshooting Guide
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Troubleshooting Guide SYMPTOM PROBABLE CAUSE 1. Water does not drain. A. Check drain for clogs or blockage. 2. Cup Fill and/or Bowl Rinse too slow. A. Adjust flow control valve. B. Kinked or pinched tubing. C. -
Page 20: Parts List
Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Parts List Page 20 of 24... - Page 21 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Cuspidor Assembly Item Description Part # Item Description Part # 1 Post Mounted 2-030-3001 5 Cup Fill Spout 5-030-3006 Utility Center 6 Cup Fill Push 5-030-3007 2 Porcelain Bowl 2-020-3035 Button 3 Syringe Holder 5-020-3003 7 Bowl Rinse Push 5-030-3008...
- Page 22 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com Bowl Assembly 2-030-1000 Post Mounted Box Assembly 2-030-3001 Item Description Part # Item Description Part # 1 Water Bottle Valve 2-030-0019 8 Spacer 2-030-0020 2 Back Cover 2-020-3029 9 Top Cover 2-020-3030 3 Chassis 2-030-0014 10 Beauty Collar...
-
Page 23: Warranty
Summit Dental Systems dealer is the sole responsibility of said dealer. • SDS reserves the right to make changes or improvements on any products without being required to modify existing equipment in a like manner. Please complete and retain for your records the following Information:... - Page 24 Summit Dental Systems Toll Free: (800) 275-3368 www.summitdental.com 1280 SW 27 Ave - Pompano Beach - FL 33069 Toll Free: (800) 275-3368 www.summitdental.com Page 24 of 24...
