Instructions for use 1402
1. Turn the Master On/Off toggle to the 'On' position. It is located under the left side
edge of the control head.
2. The handpieces are automatically activated when removed from their hanger.
3. Depress the Foot Control to operate the activated handpiece. Pressure is shown on
the gauge for the handpiece being used.
•
NOTE: Individual handpiece pressure adjustments are located at the bottom rear
of the control head.
To adjust the pressure to each handpiece, turn the adjustment screw clockwise to
decrease pressure or counterclockwise to increase pressure.
CAUTION:
This may result in unnecessary damage to the handpiece control block.
To activate water spray, turn the Water On/Off Toggle to the 'On' position. It is
4.
located on the right-side edge under the control head. Flow adjustment to the 'wet'
handpieces is controlled by the controls labeled 'Flow Control'.
When adjusting the handpiece pressure, do not over-tighten the screws.
Summit Dental Systems
Toll Free: (800)275-3368
www.summitdental.com
Summit Dental Systems
Advertisement
Table of Contents
Related Manuals for SDS 1402
Summary of Contents for SDS 1402
- Page 1 Summit Dental Systems Toll Free: (800)275-3368 www.summitdental.com Instructions for use 1402 1. Turn the Master On/Off toggle to the ‘On’ position. It is located under the left side edge of the control head. 2. The handpieces are automatically activated when removed from their hanger.
- Page 2 Summit Dental Systems Toll Free: (800)275-3368 www.summitdental.com 5. To release the air lock of the unit arm, activate the momentary toggle valve and adjust the height of the flex arm to desired position. When desired position is achieved, release the momentary toggle switch to lock the height of the flex arm. CAUTION: Do not attempt to adjust the height of the flex are without releasing the air-brake valve.
