- Page 1 Sept 2019 Humidex HCS Rev 2.1 En Installation & Owner’s Manual English This Manual Covers the Following Models HCS-BSF-HDEX Manufactured by: ClairiTech Innovations Inc. 1095 Ohio Rd. Boudreau-Ouest, NB Canada E4P 6N4...
-
Page 2: Table Of Contents
Humidex Table of Contents Table of Contents ........................1 Service and Warranty ......................... 2 ........................2 USTOMER SSISTANCE ........................ 3 ONSUMER IMITED ARRANTY Pre-Installation .......................... 4 ..........................4 NCLUDED OMPONENTS ....................... 4 OOLS EQUIRED FOR NSTALLATION Installation ..........................5 ........................... 5... -
Page 3: Service And Warranty
Humidex Service and Warranty For Customer Assistance To aid in answering questions if you call for service or warranty purposes, please record below the model and serial number located on the side of the unit. Product Name: Model #: Date of Manufacturing:... -
Page 4: Consumer Limited Warranty
Humidex Consumer Limited Warranty ClairiTech Innovations Inc. warrants to the first consumer that this product, when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its discretion, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for the period(s) set forth below. -
Page 5: Pre-Installation
Humidex Pre-Installation Included Components Before installing your Humidex, make sure that you have the right model and accessories. The following items should be included in the accessory box. If parts are missing, contact our customer service at 1-888-533-1348. 1x Owner’s Manual 6x #8 x 9/16”... -
Page 6: Installation
Humidex Installation Key Installation Facts 1) To minimize noise propagation, install at least 6 ft. of 6 in. insulated flex between the universal duct boot (connected to the floor register) and the HCS-BSF. 2) To further decrease noise propagation, 6 ft. of insulated flex can be used on the exhaust side of the unit. -
Page 7: Preparing The Humidex For Installation
Humidex Preparing the Humidex for Installation To allow the booster fan to draw air from the upper levels, a universal boot must be installed. First locate a safe place to cut out a hole to fit the universal boot. Once a safe and adequate area had been found, proceed by cutting the hole. - Page 8 Humidex On the booster fan end of the wire attach the green connector with the wiring matching the wiring guide above Now that the connecter has been wired, insert it into the Booster fan unit. Now that the booster fan has been installed and connected to the main exhaust unit, the HCS-BSF can be plugged into any 115V outlet.
-
Page 9: Specifications
Humidex Specifications Technical Data Model Amps Watts Airflow Capacity (CFM) (Sq.Ft.) HCS-BSF-HDEX 0.30 2,400 All Units require a 115 VAC electrical outlet Dimensions Model Height (In.) Width (In.) Depth (In.) HCS-BSF-HDEX 10.75” 11.5” 8.5” *A 24 Inch extension section is available if extra height is required...
