Alemlube 20088 Owner Technical Manual

Description

The Alemlube 20088 LED Slimline Work Light, being only 11mm thin, is the ultimate workshop inspection light
to reach into tight and restricted spaces. Complete control over brightness is achieved by turning a stepless dimming
switch for the level of illumination suitable for your specific job at hand.
Special features include a super strong magnet in the circular base and the ability to rotate the light around 360°.
High moisture intrusion and impact resistance ratings protect the 20088 LED Slimline Work Light to enhance
its reliability and longevity in the workshop.

Technical Details

Item No.
High Power COB LED - Main Light
Light Source
High Power SMD LED - Top Light
ca. 60-700 Im - Main Light (Min-Max)
Luminous Power
ca. 120 Im - Top Light
ca. 16-1.5 h - Main Light Full Power Mode
Operating Time
ca. 9.5 h - Top Light
Battery Specification Li-Ion 3.7 V, 2600 mAh, 9.62 Wh
Charging Time ca. 4 h
Charging Input DC 5V 1A
Degree of Protection IP 54, IK 07
Operating Temperature -10 °C to +40 °C
NSW/ACT QLD/PNG
TEL: (02) 9939 0711 TEL: (07) 3889 8480
FAX: (02) 9939 0411 FAX: (07) 3889 8490
OWNER'S TECHNICAL MANUAL
LED Slimline Work Light
20088
VIC/TAS
TEL: (03) 8787 8288
FAX: (03) 8787 8266
Visit our website at www.alemlube.com.au
WA SA/NT
TEL: (08) 9209 3066 TEL: (08) 8241 7111
FAX: (08) 9209 3933 FAX: (08) 8241 7011
or www.alemlube.co.nz
20088
February 2019
NZ
TEL: (09) 447 1007
FAX: (09) 447 1008
1
