Altec 1594B Operating Instructions Manual page 3

SPECIFICATIONS
I
I
Power amplifier
Gain:
lnput
Sensitivity:
Power Outout:
100 watts at less than 1% THD
from 35 Hz t o 20 kHz
100 watts at less than 0.5% THD
from 50 Hz to 15 kHz
Frequency
Response:
lnput
Imoedance:
15.000 ohms (potentiometer)
150 or 600 ohms with 1509!5A
Line Transformer
15.000 ohms with 15335A L.ine
Transformer
Load 4,
Impedance: isolated output)
Load Voltage:
20. 28. 40
Output
Typically less than 10% of load
Impedance:
impedance
Output Noise
Level: 85 dB below rated output
Controls: 1 VOLUME control, continuously
variable
1 primary power ON.OFF switch
1 FILTER IN-OUT switch (rear
panel)
Power
Requirements:
Battery minus
Operating
Temperature
Range:
Up t o 5 5 ' ~ (131°F) ambient
Dimensions
Weight: 35 pounds,
Color: ALTEC green
ALTEC 15095A Line Transformer
Accessories:
ALTEC 15335A Line Transformer
ALTEC 42526 Shelf Mount Cover
ACCESSORIES MUST BE ORDERED
SEPARATELY
or 70.7 volts
-or-
is ground
ounces
Figure 1.. Typical Power Output Versus Frequency for
0.5% THD and 1% THD (8-Ohm Load)
2.
Figure Typical Frequency Response Characteristics
Figure 3. Typical % THD Versus Frequency for 100-Watt
Output
Figure 4. Typical % THD Versus Wattage Output at 1000
