Installation Instruction
TYPEA(Slip-fitter)
Step 1: Loosen the 4 screws on the lamp
holder,connect the wires correctly and
put the wires into the lamp pole, then lock
the screws well to fix the lamp on the lamp
pole.
Step 2: Loosen the locking bolt with tools,
rotate the lamp and lock the screw after
determining required angle.
Notice: Locking bolt can be only compatible
with a lamp pole that the outer diameter is
¢60, lamp adjustable angle is 0-90°
TYPEB(Square/Round pole mount with slip-fitter function)
Step 1.Use tools to take screw apart and
put installed iron bar away, remove fixed
screw and open junction box, then pass
the AC wire through it.
Step 3.Notice: Remove the rubber mat
when the lamp is installed on round lamp
pole
Notice:
Lamp adjustable angle is 0-30°
Step 2.Use tools to fix the lamp on square
lamp pole, connect the wires correctly
and make waterproof measures well,
close the junction box and finish installation.
