  • Page 1 INSTRUCTION MANUAL PARTICLE SENSOR KS-19F 3-20-41 Higashimotomachi, Kokubunji, Tokyo 185-8533, Japan http://www.rion.co.jp/english/...
  • Page 3 This manual describes the features and operation principles of the light scattering type liquid-borne particle sensor KS-19F. For information regarding the operation of other equipment in the case of incorporating the KS-19F into a measurement system with other equipment, always make sure to refer to the documentation of the other equipment.

  • Page 4: Troubleshooting

    Troubleshooting Describes countermeasures to take when the CELL indicator, the LIQUID LEAK indicator and the LASER indicator are lit, and fl ash. Specifi cations Lists the technical specifi cations of the unit. This product may cause interference if used in residential areas.

  • Page 5: For Safety

    FOR SAFETY In this manual, important safety instructions are specially marked as shown below. To prevent the risk of death or injury to persons and severe damage to the unit or peripheral equipment, make sure that all instructions are fully understood and observed.
  • Page 6 WARNING Types of sample fl uids and cleaning fl uids The unit is designed for measuring the particle number concentration in liquid. The particle count is determined for various sizes. Never use the unit with the liquid types listed below, to prevent false mea- surement and the possibility of accidents and damage to the unit.
  • Page 7 WARNING Sample fl uid danger prevention When toxic sample fl uid comes into contact with any part of the human body or when toxic gases generated by the sample fl uid are breathed, there is a danger of severe injury or death. When sample fl uid comes into contact with other objects in the vicinity, there is a risk of fi re, explosion, corrosion, deformation or other effects.
  • Page 8 • The pressure of sample fl uid passed through the unit may not exceed 300 kPa (gauge pressure). Ensure that the supply system (sampler, sample fl uid lines etc.) has suffi cient pressure resistance. • When using sample fl uid which may generate harmful gases, provide adequate ventilation as prescribed by applicable laws and regulations.
  • Page 9 Purge with plenty of ethyl alcohol (followed by n-hexane if required). [Note] The above information has been compiled by Rion to the best of our knowledge, but it does not cover all possible cases or applications. Be aware that other risks or dangers may exist...
  • Page 10 WARNING The unit uses a laser source This unit is designated as a class 1 laser product according to IEC 60825-1 (2014). The internal particle detector mechanism uses a laser, but it is fully shielded so that the beam cannot exit from the enclosure.
  • Page 11 Warning Labels The following types of warning labels are used with this unit. Transport label Instructs the user to purge the sample fl uid system with pure water and fi ll it with ethyl alcohol for maintenance or servicing. When sending the units, please follow any related laws and regulations, and the instructions of your shipping carrier.
  • Page 12 Caution label for remove the sample fl uid and clean the system after measurement Instructs the user that the sample fl uid should be removed after measurement and replaced by a suitable fl uid that serves to clean the system and does not cause corrosion.
  • Page 13 Laser product warning label This unit is designated as a class 1 laser product according to IEC 60825-1 (2014). The internal particle detector mechanism uses a laser, but it is fully shielded so that the beam cannot exit from the enclosure. The label is affi xed to the top of the unit.
  • Page 14 Precautions • Operate the unit only as described in this manual. • The fl uid-contacting parts of this product are made of sapphire and PFA, which provides high resistance against corrosion by hydrofl uoric acid. However, gradual corrosion may occur in some cases. If hydrofl uoric acid was left in the unit for a long time, replacement of fl uid-contacting parts may become necessary.
  • Page 15 • If sample fl uid has accidentally entered other part of the unit, there may be a risk of fi re. Disconnect the connection cable immediately from the CONTROLLER connector of the unit. • If the unit operates abnormally, disconnect the connection cable from the CONTROLLER connector of the unit.

  • Page 17: Table Of Contents

    Contents FOR SAFETY ................iii Outline ....................1 Light source service life .............1 Particle size detection ..............2 Leak detection ................2 Measurement system confi guration examples ......3 Panel Explanation................6 Front panel .................6 Rear panel ..................8 Preparations ..................9 Place of Installation ..............9 Connection to controller KE-40B1 ........... 11 Sampling tubes ................12 Connecting the sampling tubes ..........12 Removing the sampling tubes ..........
  • Page 18 Maintenance .................. 31 Steps after use................31 Cleaning the piping ..............31 Cleaning main unit ..............33 Laser service life detection .............33 Cooling fan ................33 Replacement of consumables ..........33 Periodic maintenance ..............34 Transport .................34 Troubleshooting ................37 When CELL indicator is lit in red ...........37 When LIQUID LEAK indicator is lit in red ......37 When LASER indicator is lit in red .........37 When LASER indicator fl ashes in red ........37...

  • Page 19: Outline

    It is designed to be used under control of a separate controller KE-40B1 which also supplies power to the KS-19F. The KS-19F incorporates a leak sensor. If a leak is detected, an alarm output can be activated. As the KS-19F does not incorporate a fl ow control circuit for the sample fl uid, the fl ow rate of the sample fl uid must be controlled by external means.

  • Page 20: Particle Size Detection

    Leak detection The KS-19F incorporates a leak sensor. If a leak is detected, the LIQUID LEAK indicator lights up in red and the LIQUID LEAK ALARM terminals become OPEN.

  • Page 21: Measurement System Confi Guration Examples

    Outline Measurement system confi guration examples With the KS-19F, measurement control and processing of measurement results are entirely performed by the connected controller KE-40B1 or a computer connected to the KE-40B1. Confi gure your actual system according to the measurement requirements and types of sample fl uid.
  • Page 22 In this system, a pressure sampler is used to pressurize the sample fl uid, and a syringe sampler is used to draw the sample fl uid through the KS-19F. Measurement operation is linked to syringe sampler operation. This setup is suitable for example to measure sample fl uids with high viscosity or a tendency towards air bubble formation.
  • Page 23 Connection example using a fl ow controller In this system, a pressure sampler or similar is used to pressurize the sample fl uid and send it through the KS-19F. The fl ow rate is set with a fl ow controller. Particle sensor...

  • Page 24: Panel Explanation

    POWER indicator LASER indicator CELL indicator LIQUID LEAK indicator Lit (green): A leak is not detected within the KS-19F. Lit (red): A leak is detected within the KS-19F. PARTICLE MONITOR indicator Briefl y fl ashes green when particles of the minimum detectable particle size or above are detected.
  • Page 25 When the light source output is stable, LASER indicator on the front panel will be lit green. POWER indicator Lit (green): Power to the KS-19F is on. Flashing (red): An error occurred in the internal program. LASER indicator Lit (green): Light source operates normally.

  • Page 26: Rear Panel

    30 V DC, 1 A ALARM1, ALARM2 terminals These terminals are not used. INLET Sample inlet OUTLET Sample outlet PURGE air port Serves for routing purge gas through the KS-19F (see page 18). A blind plug is attached when shipped.

  • Page 27: Preparations

    Preparations Place of Installation Select an installation location for the unit, taking into account the points listed in the “Precautions” section (see page xii). Also observe the following points. Leave at least 10 cm of space around the unit to allow for heat ra- diation.
  • Page 28 Preparations Precautions against condensation The surface temperature of the fl ow cell inside the sensor section is ap- proximately equal to the sample fl uid temperature. You should control the environmental temperature and humidity at the location where the unit is being used so that no condensation occurs.

  • Page 29: Connection To Controller Ke-40B1

    When other equipments are also used in the system, set the power switch of these equip- ments also to OFF. 2. Link the CONTROLLER connector on the KS-19F with the SENSOR connector on the KE-40B1, using the connection cable A supplied with the KS-19F.

  • Page 30: Sampling Tubes

    Preparations Sampling tubes The supplied “tube A vacuum pack” contains 2 sampling tubes and union joint (for tube with 2 mm × 4 mm dia.). The sampling tubes are attached to plugs. Tube A vacuum pack (supplied) Plug Sampling tube Union joint Connecting the sampling tubes 1.
  • Page 31 Store the end plugs and plugs together in a safe place. The end plugs will be needed when the KS-19F is stored or sent to the supplier for servicing and maintenance. The plugs will be needed again when removing the sampling tube for storage.

  • Page 32: Removing The Sampling Tubes

    Preparations Removing the sampling tubes 1. Purge the KS-19F with pure water to remove any sample fl uid rem- nants. If the use of pure water poses the risk of sample fl uid reaction and heat generation, hardening or particle accumulation, use a different cleaning agent that is suitable for the sample fl uids and fi nally purge with pure water.
  • Page 33 Preparations 4. Insert the plug into the fl ared section at the tip of the sampling tube and turn the nut clockwise to secure it. Important The fl ared section will contract slightly over time. Always store the sampling tube with the plug in place.

  • Page 34: Extending The Sampling Tube

    When the KS-19F and external equipment are installed at a distance, or when the tube shape of the external equipment and the sampling tube supplied with the KS-19F do not match, the sampling tube can be extended using a union joint.
  • Page 35 Preparations 4. Rotate the other nut of the union joint counterclockwise to loosen it. Loosen Union joint body 5. Insert the tip of the extension tube for the external equipment into the nut as far as it will go. Extension tube Union joint body 6.

  • Page 36: Purge Gas

    Preparations Purge gas In the cases listed below, the interior of the KS-19F should be cleaned with purge gas supplied to the PURGE air port, to prevent adverse effects on the optical system and electrical circuitry. If the cleanliness of usage environment is lower than classifi cation of air cleanliness class 6 defi ned by ISO 14644-1.
  • Page 37 (about from 10 minutes to 20 minutes). The PURGE air port connector is a one-touch type for dia. 6 mm tube. When the optional purge air unit is installed, the KS-19F can be used even if the cleanliness of environment is low.

  • Page 38: Before Supplying The Sample Fl Uid

    Observe the pressure limits for the sample fl uid system. The fl ow cell and INLET and OUTLET of the KS-19F are made of sapphire and PFA. Never use sample fl uids which can cause corrosion of fl uid-con- tacting parts. Otherwise leaks or seepage may occur. The fl uid system of the KS-19F is designed to withstand sample fl uid with a pressure of up to 300 kPa (gauge pressure).

  • Page 39: Sample Fl Uid Fl Ow Rate Adjustment

    The pressure in the sample fl uid system moves the sample fl uid through the KS-19F. Use a fl ow controller or similar to adjust the fl ow rate. For details, please refer to the documentation of the fl ow controller.

  • Page 40: Particle Size Setting Range

    Preparations Particle size setting range Using the controller KE-40B1, it is possible to freely specify the size ranges for particle detection (up to 10 ranges). Please note the following limitations with regard to setting particle size ranges. • Particle size ranges can be set to 0.03 to 0.13 μm in 0.01 μm steps. •...

  • Page 41: Liquid Leak Alarm Terminals

    Preparations LIQUID LEAK ALARM terminals When internal leak is detected, the LIQUID LEAK ALARM terminals of the unit become open. These terminals accept electric wire with a 1.25 mm cross section. To use the output of the LIQUID LEAK ALARM, connect the terminals to the input of the external equipment, using two-core cable (maximum per- missible cable length is 30 m).

  • Page 42: Turning The System On

    (See “Purge gas” on page 18.) The KS-19F does not have a power switch. The power of the KS-19F is also turned on when the power of the controller KE-40B1 is turned on. Important After turning on the power, wait at least 15 minutes before starting the measurement.

  • Page 43: Measurement

    KE-40B1 connected to it. For details, please refer to the documentation of the controller KE-40B1. The KS-19F is not equipped with a means for adjusting the fl ow rate of the sample fl uid. Refer to the documentation of the fl ow rate adjustment device in the measurement system and adjust the fl ow rate accordingly.
  • Page 44 Measurement When CELL indicator is lit in red Status: Measurement may not have been carried out properly, due to excessive particle number concentration in sample fl uid, fl ow cell contamination, condensation, or other cause. Operation: Measurement is possible, but may not be correct. Result data should be used with care.

  • Page 45: Automatic Recovery Of Abnormal Internal Processing

    Operation of each device associated with the recovery process is as follows. Devices Operation KS-19F Light source: turning on (When the light source is lit in the measurement, turn off the light source and turn on again.)

  • Page 46: Function For Cancelling Erroneous Count

    Function for cancelling erroneous count Function for cancelling erroneous count This function is for canceling erroneous count caused by noise or other fac- tors and indicated by count values that are clearly different from the normal particle count. If such a count occurs during periodic measurement in auto- matic measurement mode, the value is replaced by data from the immediately preceding measurement or the moving average value up to the preceding measurement.
  • Page 47 Function for cancelling erroneous count Processing of erroneous counts If during periodic measurement a given period exhibits an abnormal count, the erroneous count is replaced by the count from the immediately preced- ing measurement. During moving average measurement, the moving aver- age up to the preceding measurement is used to replace the erroneous count measurement value.
  • Page 48 Function for cancelling erroneous count What to do when erroneous count occurs Changes in environmental temperature and other environmental conditions, contamination of particle detector assembly (fl ow cell) and optical system, changes in characteristics due to light source aging or prolonged use and similar factors can lead to an increase in erroneous count frequency.

  • Page 49: Maintenance

    2. Clean the KS-19F by purging with pure water. It is not necessary to control the fl ow rate at this time.
  • Page 50 3. After suffi cient purging, pass pure water through the system at the prescribed fl ow rate (10 mL/min). 4. Verify that the CELL indicator of the KS-19F is now lit in green. If the CELL indicator is still lit in red, repeat the cleaning procedure from step 2, but use cleaning fl uid instead of pure water.

  • Page 51: Cleaning Main Unit

    When the laser output level is still within specifi cations but the laser is near- ing the end of its service life, the LASER indicator of the KS-19F and the [LASER] icon of connected controller KE-40B1 display fl ash in green as a warning indication.

  • Page 52: Periodic Maintenance

    Maintenance Periodic maintenance In order to maintain continued measurement precision, it is recommended to have the KS-19F checked and calibrated once per year. Contact the supplier regarding periodic maintenance. Transport Before returning the KS-19F for maintenance or servicing, purge the...
  • Page 53 Maintenance Use the original packing when transporting the unit. There is a longitudinal and vertical orientation of the dedicated buffer ma- terial used when packing. Both of the buffer materials for up and down, please come arrow marks on the upper side and the front panel side of the unit. Important If this unit is not packed correctly and sufficient buffering capability cannot be obtained, there...
  • Page 54 Maintenance Packing box is using a reinforced cardboard, please surely sealed as shown below by the 75 mm or more wide gaffer tape. Important If the seal is not surely, there is a possibility that the lid and bottom of cardboard might open during transport.

  • Page 55: Troubleshooting

    When LIQUID LEAK indicator is lit in red A leak has occurred in the chassis, or there is a problem with the leak sensor. Stop the sample fl uid fl ow to the KS-19F and turn off the controller KE-40B1. Then contact your supplier.

  • Page 56: Specifi Cations

    Specifi cations Optical system 90° sideway light scattering method Light source Diode pumped solid state laser (rated output 800 mW; wave length 532 nm) Laser product class Class 1, IEC 60825-1 (2014) Internal particle detection mechanism uses Class 4 laser Collecting optics Spherical lens Light detector...
  • Page 57 Specifi cations Counting effi ciency 5% ±1.5% Effective sampling fl ow rate 0.5 mL ± 0.15 mL/min Sample inlet (INLET) / sample outlet (OUTLET) 2 mm × 4 mm dia. fl ared tube joint PURGE Purge air port, one-touch type joint for dia. 6 mm tube In the cases listed below, the interior of the unit should be cleaned with purge gas to prevent adverse effects on the optical system and electrical circuitry.
  • Page 58 Specifi cations Maximum particle number concentration 40,000 particles/mL (coincidence loss is 10% or less) False count rate Average 0.1 particles/mL or less (measured with light source off) Warm-up time Max. 15 minutes (after power-on) Max. 5 minutes (from receiving laser-on command in measurement pause/laser off condition, or relight the light source after turning the light source off by pressing the LASER OFF switch)
  • Page 59 Specifi cations Input/output connectors CONTROLLER For connection of controller KE-40B1 LIQUID LEAK ALARM Shorted during normal operation, open when internal leak is detected (accepts electric wire with a 1.25 mm2 cross section [AWG16]) Maximum load: 30 V DC, 1 A Installation inclination angle Max.
  • Page 60 Specifi cations Environmental Requirements Operation Environments Indoor Use Only Altitude Up to 2000 m Overvoltage Category (when connected to controller KE-40B1) Pollution Degree 2 Protection Class Dimensions 184 mm (H) × 492 mm (W) × 340 mm (D) (maximum) 170 mm (H) × 487 mm (W) × 310 mm (D) (excluding protruding parts) Weight Approx.
  • Page 61 Specifi cations Rear view CLASS 4 LASER RADIATION WHEN OPEN AVOID EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION (800mW CW SOLID-STATE LASER 532nm) Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No.50, dated Top view LASER OFF...
  • Page 62 This product is environment-friendly. It does not include toxic chemicals on our policy. No. 59068 19-01...
