860584440
Issue 1, February 2015
www.commscope.com
SYSTIMAX 360
General
The SYSTIMAX 360™ 1100GS3 (Cat 6) and 1100GS6 (Cat 6A) Evolve modular panels exceed ISO and TIA
Performance Category standards. The performance category is identified by the color of the jacks. Jacks with
gray jack housings are Category 6A (GS6) and jacks with black jack housings are Category 6 (GS3). The
SYSTIMAX 360 1100GS3 (Cat 6) and 1100GS6 (Cat 6A) Evolve modular panels and can be used for EIA-T568A
or EIA-T568B wiring applications and are available in 24-port and 48-port flat and angled versions.
SYSTIMAX 360 InstaPATCH
the separately orderable Evolve fiber bezels, rear cable management bar, and front cable trough are utilized.
The 1100GS Evolve panels are available iPatch
application, see 860516491 iPatch
Panel kits are available unpopulated for use with separately ordered modules.
Ordering information for modular panels is listed below:
360 GS3 Modular Panels
Material ID
760152561
1100GS3 Evolve 24-port flat panel
760152579
1100GS3 Evolve 48-port flat panel
760151308
1100GS3 Evolve 24-port angled panel
760151753
1100GS3 Evolve 48-port angled panel
Ordering information for panel kits is listed below:
360 Flat Panel Kits*
Material ID
760155739
1100GS Evolve 24-port flat panel kit
760155747
1100GS Evolve 48-port flat panel kit
*Modules are not included and must be ordered separately
For RoHS Inquiries:
CommScope Inc.
Corke Abbey, Bray
Co. Dublin, Ireland
Attn: Legal Department
™
Evolve Modular Panel Instructions
®
fiber modules can be used in the 1100GS 24-port and 48-port flat panels when
®
Upgrade Module Instructions for SYSTIMAX 360 Panels.
Description
Description
© 2015 CommScope, Inc.
All rights reserved
1100GS3 and 1100GS6
®
ready.
For instructions on using panels in an iPatch
360 GS6 Modular Panels
Material ID
760152587
1100GS6 Evolve 24-port flat panel
760152595
1100GS6 Evolve 48-port flat panel
760151324
1100GS6 Evolve 24-port angled panel
760151779
1100GS6 Evolve 48-port angled panel
360 Angled Panel Kits*
Material ID
760152785
1100GS Evolve 24-port angled panel kit
760152793
1100GS Evolve 48-port angled panel kit
This product is covered by one or more U.S.
patents or their foreign equivalents. For patents, see
www.commscope.com/ProductPatent/ProductPatent.aspx
Description
Description
Page 1 of 11
Advertisement
Related Manuals for CommScope SYSTIMAX 360 1100GS3
Summary of Contents for CommScope SYSTIMAX 360 1100GS3
- Page 1 Category 6A (GS6) and jacks with black jack housings are Category 6 (GS3). The SYSTIMAX 360 1100GS3 (Cat 6) and 1100GS6 (Cat 6A) Evolve modular panels and can be used for EIA-T568A or EIA-T568B wiring applications and are available in 24-port and 48-port flat and angled versions.
-
Page 2: How To Contact Us
PartnerPRO Network Partner. Within the United States, report any missing/damaged parts or any other issues to CommScope Customer Claims at 1-866-539-2795 or email to claims@commscope.com. Outside the United States, contact your local account representative or PartnerPRO Network Partner. Tools Required ... -
Page 3: Parts List
860584440 Instruction Sheet Parts List Verify parts against parts list below: Quantity 24-Port Flat 48-Port Flat 24-Port 48-Port Description Panel Panel Angled Panel Angled Panel ─ ─ ─ 24-port flat panel ─ ─ ─ 48-port flat panel 24-port angled panel ─... - Page 4 860584440 www.commscope.com Instruction Sheet Step 1 – Mount Panel to Rack 1. Mount panel to rack using the four 12-24 mounting screws provided. After securing panel to rack, snap the Evolve cover(s) onto the front of the panel. Note: Verify the SYSTIMAX name is upright on the flat panel cover and on angled panel center cover before snapping in place.
- Page 5 860584440 Instruction Sheet ® ® Note: If using SYSTIMAX GigaSPEED X10D 91B series cable, 95B series cordage, or Xpress 88 series cable, see preparation instructions below. Note: See pages 10 and 11 for proper use of the termination manager.
- Page 6 860584440 www.commscope.com Instruction Sheet 2. Attach cable bar to rear of panel. For 48-port panels, two cable bars are provided. 3. Lay cables evenly in cable troughs and secure using hook-and-loop straps as shown. Step 5 – Install Front Labels and Label Covers 1.
- Page 7 860584440 Instruction Sheet 3. To print a designation label, go to http://www.commscope.com/Resources/Labeling-Templates and scroll down to 360 Panels and Shelves. Select the proper label template: 360 Evolve-360 PATCHMAX UNP Label Sheet A4 (760186502) 360 Evolve 360 PATCHMAX UNP Label Sheet US LTR (760183244).
- Page 8 860584440 www.commscope.com Instruction Sheet Step 5a – Populate Panel with Fiber Modules 1. Orient module in ALPHA or BETA position as required and insert into one of the openings in the panel. 2. Push module into opening until latches engage with an audible click.
- Page 9 860584440 Instruction Sheet (Optional Step) Removing Covers from Panel When removing either the flat or angled panel side cover(s), grip cover on the top and bottom at the outside edge where shown by arrows and pull forward. As cover tabs release, position fingers close to tabs to apply further pulling force.
- Page 10 860584440 www.commscope.com Instruction Sheet Patch Panel Termination Manager Instructions The termination managers provide pair positioning, control, and strain relief features to the rear termination area of the Entry holes panel. See Figure 1. Instructions for using the termination Entry manager are listed below.
- Page 11 860584440 Instruction Sheet Snap Termination Manager onto Rear Housing (Figure 4) Pairs folded back 7. Snap assembled termination manager onto rear housing with pair colors in proper position. Push on using the termination manager housing, not by pushing with the cable. (Ensure that both lock tabs on manager fully seat into rear housing).
