Summary of Contents for Prime Bolt 4GA
- Page 1 LTE Tracker Bolt 4GA User Manual Revision: 1.00 Document Title Bolt 4GA User manual 1.00 Version Finale Date 2018-11-06 Status Released Document Control ID TRACKER Prime Bolt 4GA...
-
Page 2: Table Of Contents
2.3 LED Description ......................... 4 3 Getting Started ..........................4 3.1 Parts List ..........................4 3.2 Battery Charging ......................... 5 3.3 Prime Bolt 4GA Charger ..................... 5 3.4 Power on/Power off ......................6 4 Frequency ............................6 4.1 WIFI............................. 6 4.2 433............................ -
Page 3: Introduction
1 Introduction Bolt 4GA is a powerful GPS locator which is designed for vehicle and assets tracking. It works on LTE CATM1 B2/B4/B12 with superior receiving sensitivity. Its location can be real time or schedule tracked by back-end server or specified terminals. Based on the embedded wireless tracking protocol, Bolt 4GA can communicate with the back-end server through LTE network, and transfer reports of emergency, Geo-fencing, device status and scheduled GPS position etc…... -
Page 4: Led Description
2.3 LED Description Figure 1-2 There are four LED lights in Prime Bolt 4GA device, the description as following. Light Event State Power on Slow flash (blue) Power LED Power on and normal Dark Fully charged Slow flash (green) In charging... -
Page 5: Battery Charging
Adapter. Charging will last about 5 hours. Note: If the Bolt 4GA device is firstly used, please make sure the battery is fully charged, which will make the life of battery much longer. 3.3 Bolt 4GA Charger Bolt 4GA is charging with an AC Adapter. -
Page 6: Power On/Power Off
3.4 Power on/Power off Figure 2-2 Power on: The Bolt 4GA can only be powered on by a charger plug in.. Power off: Press the Reset key , the device will turn off immediately. Once turned on, the charger can be unplugged. The follow-up is to rely on the battery to maintain work. -
Page 7: Trouble Shooting And Safe Ty Info
Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion. Please do not use Prime Bolt 4GA on the airplane or near medical equipment. FCC Caution. § 15.19 Labelling requirements. - Page 8 § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
