- Page 1 Operating Instructions Bona OptiSpread 100 Battery Valid as of October 2014...
-
Page 2: Table Of Contents
2.3. Signs and Symbols used in the Operating Instructions ..... 5 Scope of Application and Product Description ........6 3.1. Appropriate Use ................6 3.2. Technical Data Bona OptiSpread 100 Battery ........6 3.3. Technical Data Battery..............6 Product Safety Notes ................7 4.1. -
Page 3: Foreword
OptiSpread System will enable you to apply Bona parquet adhesives in 5400 ml tubular bags in a simple and ergonomic manner. And the Bona OptiSpread 100 Battery is now even more user-friendly. In addition to the large filling tube and the wide coating nozzle, application of... -
Page 4: Important Information
Annex II A. Manufacturer/Distributor: Bona GmbH Deutschland Jahnstraße 12 65549 Limburg Description an Identification of Machine: Product names: Bona OptiSpread 100 Battery Year of construction: From May 2014 Article number: AT32046046 Series/Type name: Bona OptiSpread 100 Battery The following harmonized norms have been applied: EN 61310-2:1995 Safety of Machines –... - Page 5 Warranty Bona GmbH Deutschland grants a warranty of 24 months for this product. Material or production errors identified on this device will be rectified by Bona during this period free of charge. The warranty does not cover errors and faults which are not caused by material and production errors, e.g.
-
Page 6: What You Must Know About These Operating Instructions
Bona OptiSpread 100 Battery and will be able to use the tool efficiently. The operating instructions must be kept for the entire service life of the Bona OptiSpread 100 Battery and passed on to subsequent owners and users. -
Page 7: Scope Of Application And Product Description
3. Scope of Application and Product Description 3.1. Appropriate Use Bona OptiSpread 100 Battery is a parquet adhesive application unit which has also been developed for the application of the highly viscous adhesive, Bona R850T. Other adhesives made by Bona GmbH Deutschland can also be squeezed from the 5400 ml foil bag. -
Page 8: Product Safety Notes
Do not use any sharp items. Never insert any sharp and/or metallic items into the inside of the device. The Bona OptiSpread 100 Battery must only be filled with Bona saline adhesive in a foil bag 5400 ml. The machine must not process any non-system adhesives. This will result in the exclusion of all warranty claims. -
Page 9: Safety Notes For Handling Battery-Operated Tools
CAUTION! When not using the Bona OptiSpread 100 Battery, store it in the holder provided. Select a location where there is no risk of tripping or falling. Only use the Bona OptiSpread 100 Battery when the nozzle is unscrewed and secured! Avoid injury by ensuring your hands do not come close to the piston or feed unit. -
Page 10: Scope Of Delivery And Operation
Check completeness of delivery in accordance with the scope of delivery before using the device for the first time. If any parts are unexpectedly missing, please report this immediately to your respective Bona system consultant or contact our Service Hotline on +49 (0) 180-42 66 283... -
Page 11: Operation
FLASHING RED LIGHT – BATTERY IS HOT, COLD OR DAMAGED GREEN LIGHT – BATTERY IS FULLY CHARGED FLASHING GREEN LIGHT – BATTERY IS BEING CHARGED As soon as the battery has been completely charged, the Bona OptiSpread 100 battery can be used. -
Page 12: Filling/Replacing Tubular Bag
5.2.2. Filling/Replacing Tubular Bag Place the machine on the support block provided if you need to fill the Bona OptiSpread 100 Battery or to replace an empty tubular bag. Secure the machine at the head end using the clamping rubber. -
Page 13: Applying Adhesive
5.2.3. Applying adhesive Place the full Bona OptiSpread 100 Battery on the nozzle head, press the starter and step back. Starter The amount of adhesive applied depends mainly on your speed of motion, the nozzle size and the feed which can be adjusted continuously from 1-9. -
Page 14: Replacing The Nozzle
DIN 18356. If necessary, appropriate action must be taken to prepare the undersurface to ensure it is suitable for use. Respective Bona products can be found in our extensive product portfolio. -
Page 15: Maintenance And Cleaning
It is not permitted to use any lubricants, greases, oils or any other similar products. The inside of the tube must only be cleaned with compressed air or with a clean, lint-free cotton cloth or with Bona Tool Cleaner. -
Page 16: Correct Storage
In the case of a longer period of interruption from work of up to 12 hours, the nozzle of the Bona OptiSpread 100 Battery can remain on the machine. Partially used adhesive foil bags can also remain in the machine. The nozzle must be cleaned on the outside with Bona Tool Cleaner. -
Page 17: Troubleshooting
8. Troubleshooting Malfunctions are not to be expected, if the Bona OptiSpread 100 Battery is used and operated correctly and properly in accordance with the instructions and notes contained in these operating instructions. However, if malfunctions do occur, you should examine possible sources of... -
Page 18: Technical Drawing
9. Technical Drawing... -
Page 19: Service Address
If you have any questions, ideas or unexpected complaints, please contact your Bona system consultant. Please explain your issue in detail to him/her and provide the serial number which is on the lid of the Bona OptiSpread 100 Battery and the purchase date. -
Page 20: Disposal
Disposal Adhesive guns, batteries and chargers must be disposed of in compliance with the respective regulations of your local waste management company.
