  • Page 1 Locker Controller ELS ASSIGN Touch Technical Manual...
  • Page 2: Table Of Contents

    Locker Controller ELS ASSIGN Touch Technical Manual Table of contents Locker Controller ELS ASSIGN Touch Technical Manual ................. 3 Product description ..........................3 Basic Parts ............................4 Locker Controller PCB with two extension modules and connecting PCB ........4 Emergency Open Push-button (optional) ..................4 Installation ............................
  • Page 3: Locker Controller Els Assign Touch Technical Manual

    The Metra ELS ASSIGN products have been developed, designed and manufactured in accordance with the EU directive for Electromagnetic Compatibility (2004/108/EC). Locker Controller ELS ASSIGN Touch Technical Manual [rev.0-240111] 2011 Metra inženiring d.o.o. All Rights reserved. No part of this manual may be reproduced in any form or by any means without prior written permission of Metra inženiring d.o.o.
  • Page 4: Basic Parts

    Locker Controller ELS ASSIGN Touch Technical Manual Locker Controller also supports emergency and security features. A pushbutton for emergency opening of all Lockers connected to the Locker Controller (and belonging extension modules) is fitted on the main electronics board and also an external emergency pushbutton can be connected. In case of attempt of break-in an Alarm message is distributed over Metra NET Network to Metra user interface devices and over Metra Network Controller to LAN / WAN and Metra software.
  • Page 5: Full Network Configuration

    Locker Controller ELS ASSIGN Touch Technical Manual ELS Assign can be set up as standalone system, where only Locker Controllers and Displays Touch as user interfaces are used. Display Touch + up to 16 Locker Controllers form a group. Devices in the same group must be connected to the same Metra NET Network.
  • Page 6: Connections

    Locker Controller ELS ASSIGN Touch Technical Manual  Connections description description Electronic Lock 1 Electronic Lock 27 Electronic Lock 2 Electronic Lock 28 Electronic Lock 3 Electronic Lock 29 Electronic Lock 4 Electronic Lock 30 Electronic Lock 5 Electronic Lock 31...
  • Page 7: Connecting Locker Extension Modules

    Locker Controller ELS ASSIGN Touch Technical Manual *NOTE: Local CAN connectors are internally parallel connected. **NOTE: Local CAN connectors are internally parallel connected. ***NOTE: Local CAN connectors are internally parallel connected. ****NOTE: 12V DC Power connectors are internally parallel connected.
  • Page 8: Connecting Electronic Locks

    Locker Controller ELS ASSIGN Touch Technical Manual  Connecting Electronic Locks  Connect Electronic Locks using 6 wire flat cables.  Maximum length of each cable is 20 meters.  Cables from Electronic Locks with lower locker numbers must be connected to lower index connector.
  • Page 9: Power Supply Connection (Locker Controller With Distribution Board)

    Locker Controller ELS ASSIGN Touch Technical Manual  Power supply connection (Locker Controller with distribution board) Regulated 12 VDC power supply is required for proper operation. Connect as many units as possible to a single power supply unit. Consult the Technical Specifications section of this document for current consumption.
  • Page 10: Metra Net Network Connection (Locker Controller Without Distribution Board)

    Locker Controller ELS ASSIGN Touch Technical Manual  Metra NET Network connection (Locker Controller without distribution board) The Metra NET Network connection provides for operational functionality of the Locker Controller. Different devices in parallel can be connected to the Metra Network Controller by a single unshielded twisted pair (UTP) cable.
  • Page 11: External Emergency Open Pushbutton Connection (Optional)

    Locker Controller ELS ASSIGN Touch Technical Manual  External emergency open pushbutton connection (optional) Connect the blue and blue/white wires of the UTP cable from the Emergency open pushbutton to designated terminals as shown in the schematic. Page 11...
  • Page 12: Dip Switch Settings

    Locker Controller ELS ASSIGN Touch Technical Manual  DIP switch settings description description Emergency open pushbutton Network Address DIP switch Parameters request button Operating Mode DIP Switch (Not used) To change between different pins positions, use a small flat headed screwdriver or similar object to push DIP switch pins to desired position.
  • Page 13 Locker Controller ELS ASSIGN Touch Technical Manual  NOTE  Each Metra device must have different address setting. Switch must be set to OFF (switch down). Look up the code for desired network address in the coding table. Set switches...
  • Page 14: Operating Modes

    Locker Controller ELS ASSIGN Touch Technical Manual  Operating modes Operating Mode DIP Switch is not used in this type of ELS ASSIGN system. Switches #1 through #8 the Operating Mode DIP Switch must be set to OFF (switch down).
  • Page 15: Operation

    Locker Controller ELS ASSIGN Touch Technical Manual  Operation Each Locker Controller and Locker Extension Module has a blinking green LED operating indicator. All these signals are under software control indicating that the device is running.  Network Communication Network communication (Metra NET) is signalled on the Locker Controller by four LEDs: ...
  • Page 16: Setting Operational Parameters - Via Display Touch

    Each Locker Controller must have set its unique Metra NET Network address – ID. PROCEDURE:  Set Locker Controllers Network adresses – IDs on Displays Touch. See “ELS ASSIGN Touch SW – System Setup Manual”.  If correct Metra NET Network address is set on the Locker Controller and Locker Controller is added in the ELS Assign PC application it is detected automatically.
  • Page 17: Internal Emergency Open Pushbutton

    Locker Controller ELS ASSIGN Touch Technical Manual  Internal Emergency open pushbutton STEP 1: Press the Emergency open pushbutton. All lockers connected to the Locker Controller start to unlock and open one after another.  External Emergency open pushbutton STEP 1: Turn the key on emergency open pushbutton clockwise to initiate emergency opening of all Lockers.
  • Page 18: Maintenance

    Locker Controller ELS ASSIGN Touch Technical Manual STEP 8: Close the Locker Controller Box/Locker (see Locker manufacturer's documentation).  Maintenance No special maintenance is needed. The maintenance people should check the device operation at least once a year.  NOTE ...
  • Page 19 Locker Controller ELS ASSIGN Touch Technical Manual Physical dimensions Mounting rails Physical dimensions Mounting plate Network schematic Device configuration example Page 19...
  • Page 20 Locker Controller ELS ASSIGN Touch Appendix 1 Physical dimensions Locker Controller 75.5 6 7 8 Locker Controller Extension Module 1 2 3 4...
  • Page 21 Locker Controller ELS ASSIGN Touch Appendix 2 Physical dimensions Mounting rails 6 7 8...
  • Page 22 Locker Controller ELS ASSIGN Touch Appendix 3 Physical dimensions Mounting plate 46.5 46.5...
  • Page 23 Locker Controller ELS ASSIGN Touch Appendix 4 Network schematic Metra NET Network up to 1 km / up to 100 devices Line Terminator Locker Controller 1 Locker Controller 2 Locker Controller N Electric Locks Electric Locks Electric Locks Display Display...
  • Page 24 Locker Controller ELS ASSIGN Touch Appendix 5 Device configuration example Display Touch 6 7 8 1 2 3 4 1 2 3 4 OPTIONAL To other Metra devices...
