Power cable
Motor power phases wires
The power cable (incl.) doesn't require any modifications as it was equipped with a proper plug compatible with
simDrive.
Attention :
If you use cables longer than 5 meters you should use shielded wire for servo motors powering. Shield of the
cable should be connected to PE only from a simDrive side.
2
It is recommended to use separate PE wire with 1,5m
thickness.
11
