- Page 1 Instructions for 360Rize 360Penguin 360° Panoramic Camera...
-
Page 2: Table Of Contents
CONTENTS Camera Specifications ......3 Product Layout Details ......4 In The Box ..........5 Button Functions ........6 Power Button ......... 6 WiFI Wireless On/Off Button ..7 WiFI Wireless On/Off Button ..7 Function Of The LED Lights ..... 7 Charging With Power Off .... -
Page 3: Camera Specifications
24M (6912 x 3456), 18M (6112 x Resolution 3056), 16M (5760 x 2880), 12M (4896 x 2448), 8M (4000 x 2000) 4M (2880 x 1440) 360Penguin (Android & IOS) APP Preview 360° Spherical mode, Google Mode Cardboard mode, Little Planet,... -
Page 4: Product Layout Details
Product 101mm x 49mm x 26mm Dimensions 4-inch x 1.92-inch x 1 inch PRODUCT LAYOUT DETAILS Layout of product buttons and LED lights... -
Page 5: In The Box
IN THE BOX... -
Page 6: Button Functions
BUTTON FUNCTIONS There are only 3 buttons to understand on the camera. 5. 1 POWER BUTTON Power On: Hold power button for 3 seconds. Camera beeps twice and the LED light on the front comes on. The color of the light will be green when it is first powered up, then it will turn to the color that represents the battery life. -
Page 7: Wifi Wireless On/Off Button
Switch Camera Press the power button twice, the Mode: camera beeps twice. The side LED indicates the camera mode. Note: In preparation for taking pictures and video you must have the micro SD card installed. 5. 2 WI FI WI RELESS ON/OFF BUTTON Open Wi-Fi: Click the Wi-Fi button and Wi-Fi will open. -
Page 8: Charging With Power Off
6. 1 CHARGI NG WI TH POWER OFF The red light is on Camera is charging The red light is off Camera is fully charged 6. 2 CHARGI NG WI TH POWER ON The red light is on Camera is charging The green light is on Camera is fully charged 6. -
Page 9: App - Downloading App
APP – DOWNLOADING APP 360Penguin Site Google Play Store IOS App Store... -
Page 10: App - Main Screens
APP – MAIN SCREENS Figure 1 Figure 2 Figure 3 Figure 1: Main Startup – Allows the user to access Settings, Edit Files, and connect the Camera. Figure 2: Video Record Screen – Allows the user to record video and toggle multiple camera views. -
Page 11: App - Camera Settings
APP – CAMERA SETTINGS Figure 4 Figure 5 Figure 4: Main Startup -Allows the user to access Settings, Edit Files, and connect the camera. Figure 5: Video – 360 Video, 360 Photo, 360 Time Lapse, 360 Live Streaming, Social Media, and SD Card Settings are all available settings. -
Page 12: App - How To Social Share
10 APP – HOW TO SOCIAL SHARE Figure 6 Figure 7 Figure 8 Figure 6: 360 Screen – Allows the user to Livestream with a simple push of the “GO” button. Allows a direct login into Facebook or YouTube. Figure 7: Live Streaming Facebook – Allows the user to Live Stream to Facebook. -
Page 13: App - 360 Files On Mobile
11 APP – 360 FILES ON MOBILE Figure 9 Figure 10 Figure 9: Mobile Device Files – Group File Management of Mobile Files. Figure 10: Main Startup – Allows the user to access Settings, Edit Files, and connect the camera. -
Page 14: App - 360 Files On Camera
12 APP – 360 FILES ON CAMERA Figure 11 Figure 12 Figure 11: Camera Files located on Micro SD Card – Group File Management of Camera Files. Figure 12: Main Startup – Allows the user to access Settings, Edit Files, and connect the camera. -
Page 15: Mounting Options
MOUNTING OPTIONS Figure 1 Figure 2 Figure 3 Figure 1: Camera mounted on included tripod. Figure 2: Camera mounted on optional adapter, to allow for constant power via USB-C cable. Figure 3: Camera mounted on universal action mount. -
Page 16: Safety/Certifications
Warning: If you fail to take the following precautions, you may be seriously injured or killed by the electric shock or fire disaster, or your 360Penguin may be damaged. Please check before using the camera and accessories to make sure they are intact. For security, only 360Penguin accessories that are provided with the device or genuine ones purchased can be used. - Page 17 If using an external power connection, please follow all safety guidelines for third party power devices. The 360Penguin camera lens is made of glass. In the event of being damaged, keep broken pieces away from children. If the camera is getting abnormally hot during...
- Page 18 360Heros Inc. hereby declares that 360Penguin of wireless device type complies with Directive 2014/53/EU. Product Name: 360Penguin. Product Model: 360Penguin v1...
- Page 19 FCC ID: 2AQ3X-V1 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 20 The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body (the test distance of SAR is 0mm).
