RFL eXmux 3500 Quick Start Manual

Ip access multiplexer
Hide thumbs Also See for eXmux 3500:

Advertisement

Quick Links

Download this manual

Table of Contents

1. Overview
............................................................................................................................ 1
1. Overview
Before the eXmux 3500 can be configured into a network, the Visual Network Management Software
(VNMS) needs to be installed onto the user's laptop or PC. After this is done, IP address and other
limited settings can be changed through the USB port on the eXmux 3500.
The following instructions are designed to get the user up and running quickly after receiving their
eXmux 3500 IP Access Multiplexer. These instructions are not to be used as a substitute for the
RFL Instruction Manual. Please refer to the Instruction Manual for detailed installation procedures,
set-up, and Interface Unit configuration.
Instruction Manual can be accessed through a short cut icon that is automatically placed on your
desktop. The Instruction Manual can also be accessed from the "Help" pull-down menu in VNMS.
This Quick Start Guide will give instructions on:
• Connecting Alarm Relays and Power.
• Installing the VNMS software into the user's laptop or PC.
• Changing IP address information through the USB port on the eXmux 3500.
• Activating the software through a key code and starting VNMS.
X
E
MUX 3500 Quick Start
May 29, 2013
Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
X
E
MUX
®
3500 IP Access Multiplexer
Quick Start Guide
................................................................................... 2
..................................................................................................... 19
Note, once VNMS is installed on your computer the
1
................................................................. 8
........................................................ 16
........................ 6
RFL Electronics Inc.
973.334.3100

Advertisement

loading
Need help?

Need help?

Do you have a question about the eXmux 3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RFL eXmux 3500

Summary of Contents for RFL eXmux 3500

  • Page 1: Table Of Contents

    • Activating the software through a key code and starting VNMS. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 2: Connecting Alarm Relays And Power

    This will prevent the cabinet from falling forward when the rack is moved outward. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 3: Connecting Power

    MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 4 Chassis Protective Earth Terminal MAJOR Rear of eXmux MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 5 The eXmux 3500 may now have power applied. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 6: Installing The Exmux 3500 Visual Network Management Software (Vnms)

    4. From this point on the software will prompt you to enter information it requires to complete the installation. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 7 IP Address information and other limited settings. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 8: Setting Ip Addresses Through The Usb Interface

    Windows7 users. XP user’s go to page 13. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 9 Double click on "Exmux 3500 USB Interface" MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 10 Click “Close” a confirmation window will appear as shown on the following page. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 11 Now proceed to the following page to configure the USB Serial Port. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 12 14. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 13 MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 14 Special characters (~ @ % ^ _ - + = { } [ ] . ?) MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 15 “Exmux 3500 Reboot” so that the changes take effect. Select “Logoff.” MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 16: Entering The Activation Key Code And Starting Vnms

    2. Right click on the ‘Local Area Network Connection’ and select ‘Properties’ from the pull-down menu. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 17 This information can be ignored Check OK MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 18 To view the Instruction Manual select “Help > NMS Help” from the pull down menu. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.

  • Page 19: Related Documentation

    RFL products. MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
  • Page 20 Revised May 29, 2013 Phone: 973.334.3100 www.rflelect.com Part Number MC3500QS MUX 3500 Quick Start RFL Electronics Inc. May 29, 2013 973.334.3100 Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
