Alcatel 5085Y Repair Document

Alcatel 5085Y Repair Document

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TCL
L2 Repair Document
Communication Ltd.
ELSA6
5085Y/D/H
5085A/B/J/Q/I/N
Rev.
Page
1.3
1/41
5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

Advertisement

Table of Contents
loading

Related Manuals for Alcatel 5085Y

Summary of Contents for Alcatel 5085Y

  • Page 1 L2 Repair Document Communication Ltd. ELSA6 5085Y/D/H 5085A/B/J/Q/I/N Rev. Page 1/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 2 Wilson li 2017-01-09 Draft creation Xiaolong Yang Jane Rev. Date Modification description Prepared By Checked By Approved By Rev. Page 2/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 3: Table Of Contents

    2.1 Warranty confirmation of L1..................5 2.2 Visual mechanical check ..................6 2.3 Pretest ........................7 Software download ....................10 Disassembly and assembly 5085Y/D/A/B/J/Q/I/N/H ..........12 4.1 ESD Safety ....................... 12 4.2 Disassembly tool ..................... 12 4.3 Disassembly process ....................16 4.4 Disassembly Notice: ....................

  • Page 4: Level 2 Repair Process

    1 Level 2 repair process Please refer to <L2 repair process> in support (CSS/RSH) website for details. Rev. Page 4/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 5: Warranty Check And Visual Inspection

    If humidity sensitive label is not good, the cell phone will be considered as out of guarantee. 1). Liquid was detected by humidity sensitive label. 2). Position of humidity sensitive sticker. Rev. Page 5/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 6: Visual Mechanical Check

    Communication Ltd. 2.2 Visual mechanical check Please refer to <Visual mechanical check> in support (CSS/RSH) website for details. Rev. Page 6/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 7: Pretest

    For detail instruction of each test item, please refer to <MMI TEST> video in support (CSS/RSH) website. Rev. Page 7/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 8 L2 Repair Document Communication Ltd.  Smart Cover (Optional) Smart cover is a new feature of ELSA6 (5085Y/D/A/B/J/Q/I/N/H), only selection of “MANU” in MMI test can lead to smart cover test:  Music Cover I. Connect Music Cover to phone;...
  • Page 9 Smart Diagnosis Tool to proceed with the test:， with Smart Diagnosis Tool, please refer to < Smart Diagnosis Manual > in support (CSS/RSH) website. Rev. Page 9/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 10: Software Download

    (CSS/RSH) Please refer to <instructions of SUGAR Tool> video in support (CSS/RSH) website. Rev. Page 10/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 11 L2 Repair Document Communication Ltd. Rev. Page 11/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 12: Disassembly And Assembly 5085Y/D/A/B/J/Q/I/N/H

    L2 Repair Document Communication Ltd. 4 Disassembly and assembly 5085Y/D/A/B/J/Q/I/N/H 4.1 ESD Safety Please wear static loop or static glove 4.2 Disassembly tool You may use the following tools during the disassembly and reassembly procedure: Tool Picture Plastic Flake （0.96mm）...
  • Page 13 L2 Repair Document Communication Ltd. Screwdriver (TORX6 normal screwdriver and Torque screw driver) Rev. Page 13/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 14 L2 Repair Document Communication Ltd. Rev. Page 14/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 15 L2 Repair Document Communication Ltd. Anti-static Tweezers Suction cup (Normal suction cup and special suction cup Rev. Page 15/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 16: Disassembly Process

    L2 Repair Document Communication Ltd. 4.3 Disassembly process The steps of disassembly 5085Y/D/A/B/J/Q/I/N are as below. Step1: Take off the battery cover by using plastic flake. Rev. Page 16/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 17 0262C0 type,+1.4F1,With Nylok,SWCH18A,HV 350--550,Plating White ZN,N/A,SEOUL Step3: Remove the Diversity Antenna Support ASM by using plastic flake. Rev. Page 17/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 18 Remove the Main Antenna Support ASM by using plastic flake. III. Remove the Furnished Frame by using plastic flake. Rev. Page 18/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 19 ASM and Furnished Frame from Front Casing Underfilling Asm. Step 4: Disconnect several FPCs connector and coaxial cable with tweezers. Rev. Page 19/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 20 Front Casing Underfilling Asm. Pry up the sub PCBA and remove it from Front Casing Underfilling Asm. Rev. Page 20/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 21 L2 Repair Document Communication Ltd. Step 5: Pull the Battery PET according to the directions of the arrows carefully; Rev. Page 21/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 22 Pull the Battery PET completely; Remove the battery from Front Casing Underfilling Asm by using suction cup. Rev. Page 22/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 23 Side Key FPC Receiver Front Flash Furnished FPC Main & Sub board Furnished FPC Coin Vibrator Mic Rubber Speaker Rev. Page 23/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 24 L2 Repair Document Communication Ltd. Step7: Disconnect the Main Camera. Disconnect the Front Camera. Disconnect the Audio Jack Rubber. Rev. Page 24/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 25 Main & Sub board Furnished FPC Sub PCBA RF cable line Side Key Furnished FPC P-Sensor Rubber Rev. Page 25/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 26: Disassembly Notice

     When assembling battery, make sure that the battery does not be damaged, leaked or deformed throughout the process. Rev. Page 26/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 27 0.5mm,+ type,0,With Thread Lock,SWCH18A,HV 380-480,Plating White ZN,N/A,XIANGJIAN 螺钉, Screw,PM (Machine),PM1.4×0.3P×L3.0mm,Flat BMA1430262C0 Head,HD=Ф2.6×T0.5mm,+ type,+1.4F1,With Nylok,SWCH18A,HV 350--550,Plating White ZN,N/A,SEOUL Rev. Page 27/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 28: Disassembly Process Evaluation

    Furnished Frame Plastic Flake Class 1 Main PCBA Tweezers Class 2 RF cable line Tweezers Class 2 Rev. Page 28/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 29: Disassembly Complete

    NOTE: The SPL here is just for reference. Actual Spare Part List depends on the CU reference. Please check with RSH webshop or Forlog system for the spare part list of specific CU. Rev. Page 29/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 30 L2 Repair Document Communication Ltd. Rev. Page 30/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 31: Level 2 Repair

    This chapter describes the Level 2 repair that can be done without any diagnostic equipment.  Charging failure Rev. Page 31/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 32 Main & Sub board Check whether Main & Sub Furnished FPC board Furnished FPC connector connector is normal Replace PCBA Rev. Page 32/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 33 （ i n t e r c h a n g e asm) method） Reweld or replace LCD Check whether LCD connector is connector normal Replace PCBA Rev. Page 33/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 34 Casing Underfilling method) asm) Reweld or replace TP Check whether TP connector is connector normal Replace PCBA Rev. Page 34/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 35 C h e c k w h e t h e r S I M c a r d Re-weld or change SIM connector is good card connector Replace PCBA Rev. Page 35/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 36 C h e c k w h e t h e r t h e T F c a r d Re-weld or change TF connector is good card connector Replace PCBA Rev. Page 36/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 37 C h e c k w h e t h e r M a i n c a m e r a Reweld or replace Main connector is normal camera connector Replace PCBA Rev. Page 37/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 38 R e w e l d o r r e p l a c e s u b connector is normal camera connector Replace PCBA Rev. Page 38/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 39 Reweld or Replace Check whether battery battery connector connector is normal Replace PCBA Rev. Page 39/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 40: Pcba Exchange

    Enter *#2886# at the dial mode to start the MMI test or using Smart Diagnosis Tool to do the test. If you have any question or problem, please feel free to contact us Rev. Page 40/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 41 Communication Ltd. Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. Mar. 14 , 2017 Rev. Page 41/41 5085Y/D/A/B/J/Q/I/N/H Level 2 Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
