TVS-2-TAIT
High Level Rolling Code Scrambler for the Tait Orca & TM-8000 Radios
VPU-15-TAIT
Voice Inversion Scrambler for the Tait Orca & TM-8000 Radios
Manual Revision: 2008-05-01
Covers Software Revisions:
TVS-2-TAIT: 4.93 & Higher
VPU-15-TAIT: 4.93 & Higher
This manual & product supports the following radios:
Portables: Tait Orca 5010/5020/5040
Mobiles: TM-8115
1
Advertisement
Table of Contents
Related Manuals for Midian TVS-2-TAIT
Summary of Contents for Midian TVS-2-TAIT
- Page 1 High Level Rolling Code Scrambler for the Tait Orca & TM-8000 Radios VPU-15-TAIT Voice Inversion Scrambler for the Tait Orca & TM-8000 Radios Manual Revision: 2008-05-01 Covers Software Revisions: TVS-2-TAIT: 4.93 & Higher VPU-15-TAIT: 4.93 & Higher This manual & product supports the following radios: Portables: Tait Orca 5010/5020/5040 Mobiles: TM-8115...
-
Page 2: Specifications
VPU-15: The VPU-15 is an entry level voice inversion scrambler. The scrambler is capable of features such as ANI, ENI, Deadbeat Disable, Spy, and more when using Midian’s Kryptic Signaling format with the CAD- 300/DDU-300/TRC-300. For more details, please see the VPU-15 Technical Reference Manual. -
Page 3: Radio Programming
RADIO PROGRAMMING Tait Orca Portables: In the “Specifications” screen, set the “Maximum Number of Encryption Codes” to the desired number of codes (1-4 codes). This should correspond to the number of codes programmed into the scrambler. The 5010 can only be single code. - Page 4 Tait TM-8000 Mobiles: Set the Programmable I/O on the Digital tab as follows: 1. Set Pin IOP_GP101 to Output > PTT > Reflect PTT Status > Active Low. 2. Set Pin IOP_GP102 to Input > PTTOUT > External PTT 1 > Active Low. 3.
- Page 5 1. Set one key (Key 1 – Key 4) to Encryption. This will be the front panel key used to turn the scrambler on/off. If the button is programmed for latched (see above) the button can only be used for mode selection. Key 2-4 can be programmed for momentary.
-
Page 6: Hardware Installation
HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. Tait Orca Portables: Disassembling the Radio: Reference the Tait Orca Service Manual for instructions on disassembly of the radio. Use extreme care when disassembling the radio. - Page 7 Tait TM-8000 Series Mobiles: Tait Orca Portables: Disassembling the Radio: Reference the Tait Service Manual for instructions on disassembly of the radio. Use extreme care when disassembling the radio. Installing the Scrambler: The scrambler plugs into the TM-8000 using the encryption interface module (EIM) from Tait. The Tait part number for this is 228-24341-01.
- Page 8 4. Plug the gray ribbon cable from the SK102 connector on the main board to the SK102 connector on the EIM, as shown in the picture below: 5. Mount the EIM into the metal lid of the radio using the mounting screws (torx type), as shown in the picture below: Reassembling the Radio: If programming the scrambler using the KL-3, proceed to the programming section.
-
Page 9: Product Programming
PRODUCT PROGRAMMING Midian’s TVS-2-TAIT and VPU-15-TAIT are programmed via Midian’s KL-3 programming cable or using Tait’s TOPA-EA-007G. Please reference the KL-3 manual for setup instructions of the KL-3 software and hardware. From the product selection screen on the KL-3 software, select the appropriate product from the list and click OK. -
Page 10: Operation
TVS-2-TAIT and VPU-15-TAIT the binary is reversed. This means that code 4 in the TVS-2-TAIT or VPU-15-TAIT would equate to code 1 in a... - Page 11 MIDIAN CONTACT INFORMATION Midian’s sales and technical support departments are available by phone, fax and e-mail from 8 am to 5 pm (Arizona Standard Time) Monday through Friday (except holidays). Midian Electronics Inc. 2302 East 22 Street Tucson, Arizona 85713 USA...
- Page 12 This page intentionally left blank...
