Midian ID-1 Manual

Automatic morse code station identifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ID-1
Automatic Morse Code Station Identifier
Manual Revision: 2012-12-17
Covers Software Revisions:
ID-1: 2.4 & Higher
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Midian ID-1

Summary of Contents for Midian ID-1

  • Page 1 ID-1 Automatic Morse Code Station Identifier Manual Revision: 2012-12-17 Covers Software Revisions: ID-1: 2.4 & Higher...

  • Page 2: Specifications

    10 KW or 22 KW PTT Output Current 100 mA Dimensions 1.27” x .83” x .17” GENERAL INFORMATION The ID-1 is an Automatic Morse Code station identifier capable of encoding 2 different Morse Code sequences either on a continuous cycle or after PTT.

  • Page 3: Hardware Installation

    Green lead from the KL-4 programmer. For Message Select Input, this lead is left floating for Station ID 1 and grounded for Station ID 2. P1-13 – Violet – Inhibit Input – When taken to active state programmed in the ID-1 the unit will not transmit the ID until the state of this input returns to the inactive state.

  • Page 4: Product Programming

    MPS software, select the appropriate product name from the list and click OK. Set the parameters of the ID-1 to fit the application. If any clarifications on a feature are required, move the mouse cursor over the feature name until the question mark appears and right click, a definition of the feature will be shown.

  • Page 5: Programmable Features

    COR/COS/CTCSS Active Polarity: This sets the active Polarity of the COR Input. This should match the active COR state that the radio gives the ID-1 when the channel is busy. Ground equals a ground or float condition and V+ equals +5 V.

  • Page 6: Operation

    After PTT Operation: In the After PTT mode the ID-1 will send the ID after the PTT Input is grounded and then released. Upon release the unit will hold the PTT Out for the time set in the PTT Drop Out Time and then the unit will wait for the amount of time set in the Wait Period After Loss of COR.
  • Page 7 COR/COS/CTCSS IN [BRN] 100p 100K P1:2 NOTE: VIN/+5V TO +15V[RED] *= NOT INSTALLED .47u .001u REMOVE R29 TO MUTE SIDE TONE P1:4 .47u MIDIAN ELECTRONICS, INC. DOCUMENT NAME ID-1 GND[BLK] MIC5206 1997-11-01 APPR DATE: DWN BY: SCHEMATIC SHEET PROJECT NUMBER 7287...
  • Page 8 This page intentionally left blank...
