Network Turret Camera·Quick Start Guide About this Manual This Manual is applicable to DS-I113 DS-I213 Network Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
Page 3
Network Turret Camera·Quick Start Guide FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Network Turret Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
Page 5
Network Turret Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
Page 6
Network Turret Camera·Quick Start Guide ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Cautions ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ●...
Page 7
Network Turret Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.
Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............8 2 Installation ..................10 3 Setting the Network Camera over the LAN ........15 Wiring ................15 Activating the Camera ........... 16 Activation via Web Browser ........ 16 Activation via SADP Software ......
Network Turret Camera·Quick Start Guide 1 Appearance Description Two types of camera are available for this camera series. Turret Camera Overview Turret Camera (PoE) Overview...
Page 10
Network Turret Camera·Quick Start Guide Description Description Enclosure Camera Body Mounting Base Power Cable Ethernet Cable Note: For the camera support power over Ethernet (PoE), the power is passed along with data on Ethernet cabling. And a switch supports PoE function is required.
Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.
Page 12
Network Turret Camera·Quick Start Guide We take one of the camera types as the example to explain the installation steps. Steps: 1. Paste the drill template (supplied) to the desired mounting position on the ceiling. 2. Drill screw holes according to the drill template. ∅110 ∅20 ∅5...
Page 13
Network Turret Camera·Quick Start Guide Disassemble the Camera 4. Fix the mounting base to the ceiling with supplied screws. Figure 2-3 Fix the Mounting Base...
Page 14
Network Turret Camera·Quick Start Guide 5. Route the cables. Connect the power cord and network cable. 6. Install the camera body to the mounting base. Install the Camera Body 7. Adjust the surveillance angle. 0° - 360° 0° -75° 0° - 360° Adjust Surveillance Angle Hold the camera body and rotate the enclosure to adjust the pan angle [0°...
Page 15
Network Turret Camera·Quick Start Guide Move the camera body up and down to adjust the tilt angle [0° to 75°]. Rotate the camera body to adjust the Loosen No.3 adjusting azimuth angle [0° to 360°].
Network Turret Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.
Network Turret Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.
Network Turret Camera·Quick Start Guide 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your...
Page 19
Network Turret Camera·Quick Start Guide SADP Interface Note: The SADP software supports activating the camera in batch. Refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including...
Network Turret Camera·Quick Start Guide 4. Click OK to save the password. You can check whether the activation is completed on the popup window. If activation failed, make sure that the password meets the requirement and try again. Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your...
Page 21
Network Turret Camera·Quick Start Guide Modify the IP Address 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the User Manual of SADP for details.
Network Turret Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
Page 23
Network Turret Camera·Quick Start Guide Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
