  • Page 1 Network Mini PT Dome Camera Quick Start Guide...

  • Page 2: Regulatory Information

    Network Mini PT Dome Camera·Quick Start Guide About this Manual This Manual is applicable to DS-I12Q DS-I22Q Network Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Mini PT Dome Camera·Quick Start Guide FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    Network Mini PT Dome Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 5 Network Mini PT Dome Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
  • Page 6 Network Mini PT Dome Camera·Quick Start Guide ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Cautions ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ●...
  • Page 7 Network Mini PT Dome Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.

  • Page 8: Table Of Contents

    Network Mini PT Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 9 Overview ................. 9 Installing SD / SIM Card ..........15 Remote Control ............. 16 2 Installation ................. 18 3 Setting the Network Camera over the LAN ......... 23 Wiring ................

  • Page 9: Appearance Description

    Network Mini PT Dome Camera·Quick Start Guide 1 Appearance Description Overview Two types of network Mini PT cameras are shown below. Type I: WiFi network transmission is supported for the Type I network Mini PT camera. Overview (1)-Type I Figure 1-1 Overview (2)-Type I Figure 1-2...
  • Page 10 Network Mini PT Dome Camera·Quick Start Guide Overview (3)-Type I Figure 1-3 Description of Type I Network Mini PT Camera Table 1-1 Description Silicone Gasket Dome Drive WPS(Wi-Fi Protected Setup) Button Micro SD Card Slot Photic Cover Lens Lens Ring PIR(Passive Infrared) sensor Mounting Base 10M / 100M self-adaptive Ethernet interface...
  • Page 11 Network Mini PT Dome Camera·Quick Start Guide Description Alarm Input/output Interface Reset Audio Out Power supply interface (5 VDC) Speaker Solid blue: Network is connected, and camera is unarmed. Flicking blue: No network connection. Solid red: Camera is armed. Status LED Flicking red: Camera is not working properly.
  • Page 12 Network Mini PT Dome Camera·Quick Start Guide Type II: Wireless alarm is supported for the Type II network Mini PT camera. 4G and Wi-Fi network transmission are optional. Overview (1)-Type II Figure 1-4 Overview (2)-Type II Figure 1-5 For the Type II network Mini PT camera supporting the 4G network transmission, the Wi-Fi network transmission does not take effect.
  • Page 13 Network Mini PT Dome Camera·Quick Start Guide Overview (3)-Type II Figure 1-6 Description of Type II Network Mini PT Camera Table 1-2 Description Silicone Gasket Dome Drive 4G SIM Card Slot, (optional) Micro SD Card Slot Photic Cover Lens Lens Ring PIR(Passive Infrared) sensor Mounting Base Alarm Input/output Interface...
  • Page 14 Network Mini PT Dome Camera·Quick Start Guide Description 10M / 100M self-adaptive Ethernet interface Audio Out WPS(Wi-Fi Protected Setup) Button, (optional) Power supply interface (5 VDC) Reset Speaker Solid blue: Network is connected, and camera is unarmed. Flicking blue: No network connection. Solid red: Camera is armed.

  • Page 15: Installing Sd / Sim Card

    Network Mini PT Dome Camera·Quick Start Guide  You can disable the status LED when you access the camera via browsers. Go to Configuration—Advanced Configuration—System—Service, and check off the checkbox of Enable Status LED to disable the status LED.  Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, port No., etc.

  • Page 16: Remote Control

    Network Mini PT Dome Camera·Quick Start Guide Removable Cover Micro SD Card SIM Card Figure 1-7 Install SD / SIM Card Remote Control A remote control is supplied for the Type II network Mini PT camera. Figure 1-8 Remote Control...
  • Page 17 Network Mini PT Dome Camera·Quick Start Guide Table 1-3 Description of Remote Control Button Description Press the button to arm the camera. In arming status, the alarm function, such as the wireless alarm Arm Button and the PIR alarm is enabled. Disarm Press the button to disarm the camera.

  • Page 18: Installation

    Network Mini PT Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.
  • Page 19 Network Mini PT Dome Camera·Quick Start Guide Steps: Drill the screw holes on the ceiling according to the supplied drill template. Figure 2-1 Drill Template Align the screw holes on the ceiling and adapter plate, and then fix the adapter plate to the ceiling with the supplied screws.
  • Page 20 Network Mini PT Dome Camera·Quick Start Guide Bayonet Joint Figure 2-2 Install the Adapter Plate For cement wall, you need to use the expansion screw to fix the mount; for wooden wall, you can just use the self-tapping screw to fix the mount.
  • Page 21 Network Mini PT Dome Camera·Quick Start Guide OPEN LOCK Figure 2-3 Install the Camera Adjust surveillance view angle. 1) Hold and rotate the main camera body to adjust the view angle in the pan direction: [0°~355°]. 2) Move the dome drive upwards or downwards to adjust the view angle in the tilt direction: [-20°~90°].
  • Page 22 Network Mini PT Dome Camera·Quick Start Guide Pan: 0°~355° Camera Body Dome Drive Tilt: -20°~90° Figure 2-4 Adjust the View Angle Table mounting is also available for the network Mini PT camera. If the camera needs to be fixed on the table, refer to the above steps described for the ceiling mounting;...

  • Page 23: Setting The Network Camera Over The Lan

    Network Mini PT Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 24: Activating The Camera

    Network Mini PT Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.

  • Page 25: Activation Via Sadp Software

    Network Mini PT Dome Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 26 Network Mini PT Dome Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 27: Modifying The Ip Address

    Network Mini PT Dome Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 28 Network Mini PT Dome Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.
  • Page 29 Network Mini PT Dome Camera·Quick Start Guide Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP.

  • Page 30: Accessing Via Web Browser

    Network Mini PT Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 31 Network Mini PT Dome Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 32: Operating Via Guarding Vision App

    Network Mini PT Dome Camera·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models.

  • Page 33: Enable Guarding Vision Service Via Web Browser

    Network Mini PT Dome Camera·Quick Start Guide Service” “Privacy Policy” Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4.
  • Page 34 Network Mini PT Dome Camera·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Figure 5-2 Platform Access Configuration (Web) 3.

  • Page 35: Guarding Vision Setup

    Network Mini PT Dome Camera·Quick Start Guide Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching “Guarding Vision” in App Store or Google Play 2. Launch the app and register for a Guarding Vision user account. 3.
  • Page 36 Network Mini PT Dome Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 37: Initializing The Memory Card

    Network Mini PT Dome Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
