pantherRVproducts
WIRELESS
REMOTE CONTROLLED
UNIVERSAL KIT
Mechanical Jack Conversion To
Electric Power
One button raises and lowers all jacks
Heavy duty construction
Quick and simple field conversion
Rugged precision drive system
Self-braking for safe operation
Large footpads for added stability
Secure, safe mounting system
Corrosion resistant powder coating
Weatherproof sealed head
965 Lambrecht Road ♦ Frankfort, IL 60423
Phone: 866.403.9803 ♦ Fax:815.469.4705
Email:customerservice@riecotitan.com
www.riecotitan.com
Doc. Date 7-10-09
Rev. Date12-7-10
Electronics Model #
OSI-433N
Advertisement
Related Manuals for Rieco-Titan Products OSI-433N
Summary of Contents for Rieco-Titan Products OSI-433N
- Page 1 Electronics Model # WIRELESS OSI-433N REMOTE CONTROLLED UNIVERSAL KIT Mechanical Jack Conversion To Electric Power One button raises and lowers all jacks Heavy duty construction Quick and simple field conversion Rugged precision drive system Self-braking for safe operation Large footpads for added stability...
- Page 2 pantherRVproducts CAUTION !!! If your jacks are ball screw type, with tube welded to side of gear box, make sure your camper is on your truck or supported on blocks, so that the camper cannot tip over while you are working on this conversion! Note -The installation instructions for this conversion kit follow.
- Page 3 pantherRVproducts Alternate Instructions- Atwood Ball Screw Jack CAUTION !!! IF YOUR JACKS ARE ATWOOD BALL SCREW TYPE(HAVE TUBE-WELDED TO SIDE OF THE GEAR BOX), AND YOUR CAMPER IS NOT ON YOUR TRUCK, SUPPORT IT ON BLOCKS SO THAT ANY JACK CAN BE REMOVED WITHOUT THE CAMPER BECOMING UNSTABLE.
- Page 4 MECHANICAL JACK CONVERSION Rieco-Titan Products, Inc. 2000# Mechanical TO ELECTRIC POWER 965 Lambrecht Road Jacks Frankfort, IL 60423 INSTALLATION & OPERATING Phone: 866.403.9803 INSTRUCTIONS Fax: 815.469.4705 Universal Kit Revised 6-13-08 SAFETY ALERT! This symbol - !!! is used here to alert you to potential personal safety hazards and property damage.
- Page 5 pantherRVproducts Rieco-Titan Universal Kit Power Conversion Assembly Rieco-Titan Jacks- The drive pin in the jackpost must be knocked out. The old bushing and washer must be replaced with a new steel bushing. Install new 5/32” drive pin so that it is equally protruding on each side to fit inside the drive tube collar.
-
Page 6: Electrical Installation
pantherRVproducts MECHANICAL INSTALLATION (continued) 6. Obtain the gearmotor mounting bracket. Position it so that the 11/16 diameter holes line up with the holes in the jack gearbox. The mounting bracket collar is offset 1/8” to one side. On Rieco-Titan jacks, install bracket so that the bracket offset matches offset in gearbox. - Page 7 pantherRVproducts ELECTRICAL INSTALLATION ( continued ) 6. Connect the two wires from each jack to the receiver. The left front jack should be connected to the receiver terminals marked LF. The right front to the RF terminals, and so on for the rear jacks. Each set of terminals has a (+) and a (-) side.
- Page 8 pantherRVproducts ELECTRICAL INSTALLATION ( continued ) 13. To ensure that your operating signal of the system is secure, both the transmitter and the receiver control box have identical 7 actuator, 21 position code switches. You may want to change the codes on the switches. The actuators must be set to match each other in both the transmitter and the receiver control box.
- Page 9 ALL AT "0", AND YOU SHOULD RESET THEM TO A CODE OF YOUR SELECTION. IF YOU HAVE SERIAL NUMBERS ON YOUR UNITS, YOUR FACTORY CODE SETTING IS AVAILABLE FROM RIECO-TITAN PRODUCTS, INC. 15. Our new receiver control box is equipped with an LED light in the top for each jack circuit. When the jack is activated by the remote button control, the LED for that jack or jacks is illuminated indicating a completed circuit.
- Page 10 pantherRVproducts Fig. 4 The “C” clamp and the 5” bracket are intended to be used when the camper manufacturer recommends their use. When they are called for, use three (3) bolts on the 13” bracket and one (1) on the 5” bracket. The 5” bracket is used on the left and right rear of the camper beneath the 13”...
- Page 11 pantherRVproducts Revised 7-10-09...
- Page 12 pantherRVproducts Revised 8-24-08...
- Page 13 pantherRVproducts !!! FOLLOW THE SAFETY RECOMMENDATIONS LISTED BELOW TO AVOID POSSIBLE INJURY AND/OR PROPERTY DAMAGE 1. This jack system is designed and intended for loading, unloading, and stabilizing your truck camper while in storage. Do not allow a person or persons in your camper while the jacks are in use.
- Page 14 pantherRVproducts LOADING THE CAMPER 1. Push the rocker switch "ON" in the receiver unit or the remote switch panel. Press the "UP" buttons on the transmitter until the two front jacks have raised the camper 3-4". 3. Raise the two rear jacks 3-4" until level with front. Repeat steps 2 &...
-
Page 15: Troubleshooting
The REL-2 is warranted against manufacturing defects and workmanship for two (2) years from the date of purchase. Within this period, RIECO-TITAN PRODUCTS, INC. will at its option, repair or replace the product or any part thereof without charge for parts and labor. To exercise the warranty, the original consumer-owner must return the original invoice, and the product freight prepaid and insured to RIECO-TITAN PRODUCTS, INC.
