Page 1: User Manual
User Manual PS-691 HDMI Extender over Cat5e/6 All Rights Reserved Version: PS-691_2017V1.1... -
Page 2: Safety Precaution
HDMI Extender over Cat5e/6 Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The func�ons described in this version are updated �ll June 14, 2017. In the constant effort to improve our product, we reserve the right to make func�ons or parameters changes without no�ce or obliga�on. -
Page 3: Package Contents
HDMI transmission. Advanced power design (PoC) allows this product to be powered at Transmi�er, and only one power supply is required. In addi�on, the PS-691 send/receive IR signals each other over the same CATx cable with IR pass through. -
Page 4: Panel Description
HDMI Extender over Cat5e/6 Panel Description Transmitter (TX) DC 5V HDMI IN HDMI OUT CAT OUT IR IN IR OUT RESET ① CAT OUT: RJ45 connector with Green& Yellow indicators. Connect to Receiver over CATx cable. The Green indicator lights up when powered on. The Yellow indicator lights up when linked successfully between Transmi�er and Receiver. -
Page 5: Specifications
HDMI Extender over Cat5e/6 ② IR IN: Connect with IR Receiver. ③ IR OUT: Connect with IR Emi�er. ④ HDMI OUT: Connect to display. ⑤ EQ SETTING: A�er the system is connected, press this bu�on repeatedly un�l the best image output. When the cable, source, or display is changed, or reset the output resolu�on, it is need to press this bu�on repeatedly to ensure the best image. -
Page 6: Connection Diagram
HDMI Extender over Cat5e/6 Input: 100VAC~240VAC, 50/60Hz; Output: Power Supply 5VDC 1A Power Consump�on 4W (Max) Work Temperature -10 ~ 55℃ Rela�ve Humility 10% - 90% Dimensions (W*H*D) 66mm x 16.8mm x 66mm Weight Transmi�er: 36g; Receiver: 38g Connection Diagram Catx: HDMI: Power:...
