A&D GX-A Series Instruction Manual
  1. Manuals
  2. Brands
  3. A&D Manuals
  4. Recording Equipment
  5. GX-A Series
  6. Instruction manual
A&D GX-A Series Instruction Manual

A&D GX-A Series Instruction Manual

Options external interface, with a print foot switch/with a rezero foot switch/for inccorporating into a system/external ir switch
Hide thumbs Also See for GX-A Series:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
www.scaleman.com offers the full line of A&D Weighing products
GXA-23-PRINT
GXA-23-REZERO
GXA-23-PLUG
GXA-26
2017 A&D Company, Limited. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, or translated
into any language in any form by any means without the written permission of A&D
Company, Limited.
The contents of this manual and the specifications of the instrument covered by this
manual are subject to change for improvement without any notice and obligation on the
part of the manufacturer.
1WMPD4003637A
Buy online at https://scaleman.com/
With a PRINT foot switch
With a REZERO foot switch
For incorporating into a system
External IR switch

Advertisement

loading
Need help?

Need help?

Do you have a question about the GX-A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for A&D GX-A Series

Summary of Contents for A&D GX-A Series

  • Page 1 www.scaleman.com offers the full line of A&D Weighing products GXA-23-PRINT With a PRINT foot switch GXA-23-REZERO With a REZERO foot switch GXA-23-PLUG For incorporating into a system GXA-26 External IR switch 2017 A&D Company, Limited. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, or translated into any language in any form by any means without the written permission of A&D Company, Limited.
  • Page 2 www.scaleman.com offers the full line of A&D Weighing products 1. Introduction This manual describes how to use the GXA-23 and GXA-26 optional interfaces for the GX-A and GF-A series balances and how to get the most out of them in terms of performance.

  • Page 3: Installing The Option Board

    www.scaleman.com offers the full line of A&D Weighing products 3. Installing the Option Board Step 1. Remove the two screws, and then remove the Step 1 option panel from the rear of the balance. Step 2 Step 2. Peel off the connector that is secured to the panel with double-sided tape and insert it into the socket on the option board.
  • Page 4 www.scaleman.com offers the full line of A&D Weighing products 4. How to Use the GXA-23 4.1. GXA-23-PRINT and GXA-23-REZERO Connect the plug of the foot switch to either jack on the option board panel. Connecting the plug of the PRINT foot switch enables the switch to perform in the same way as the PRINT key.
  • Page 5 www.scaleman.com offers the full line of A&D Weighing products 5. How to Use the GXA-26 Step 1. Connect the plug of the external IR (touchless) switch to the jack on the option board panel. When the connection is completed properly, the LED on the external IR switch illuminates.
  • Page 6 www.scaleman.com offers the full line of A&D Weighing products Step 3 The function table stores parameters that specify how to operate the balance, and it is used to mointor or update those parameters. In the function setting, assign the PRINT or RE-ZERO key function to the external IR switch.
  • Page 7 BC5 in * Refer to the GX-A/GX-F series balance instruction manual. Internal mass value correction * Only for the GX-A series Factory setting The external IR switch sensitivity adjustment function is available for balances with software version P-1.200 or later.

This manual is also suitable for:

Gxa-23-rezeroGf-a seriesGxa-23-plugGxa-26Gxa-23-print
