- Page 1 Multi-Function / Dual Chassis CABLE TESTER User Manual CBT-MF...
- Page 2 The split chassis allows users to separate the two halves of the CBT-MF. This feature provides an easy way to test the continuity of long cables that have been run through walls or ceilings as well as cables that have been put into audio or home theater installations.
- Page 3 The CBT-MF is ideal for home, project, and professional studio use. Constructed with lightweight and durable plastic, the CBT-MF is a road-ready tool for studio techs and install engineers. Precautions • Please read and follow these instructions, and keep this manual in a safe place.
- Page 4 Overview Cable testing jacks Power LEDs Cable test/Tone test power selector Tone test volume selector Power switch LED speed selector Banana plug jacks Pin indicator and continuity LEDs Battery compartments (underside - not shown) Cable testing jacks...
-
Page 5: Installing The Batteries
Installing the batteries It is recommended to check the battery prior to testing cables. To test the battery, do the following: Lift the battery compartment cover by pressing the locking tab and removing the cover. Insert the terminals of the snap connector onto the battery. Place the battery into the battery compartment making sure to place the cables underneath the battery. - Page 6 Important: If the LEDs and beep do not start immediately once the receiver has been turned on, it indicates that PIN 1 of the cable is faulty. PIN 1 needs to be connected in order for the CBT-MF to begin working.
- Page 7 To change the flashing speed of the LEDs, set the speed selector to fast, medium, or slow. Testing long cables that have been installed through walls or ceilings: The sender and receiver can be separated by sliding them apart. Connect each side to the cable to be tested. The pin indicator LEDs will flash on both sides to show each operator the status of each pin’s continuity.
- Page 8 PIN 1 is faulty or damaged. PIN 1 needs to be connected in no beep order for the CBT-MF to begin testing the other pins. The number of LEDs that light up depend A 5-pin cable will illuminate LEDs 1 through 5. The other LEDs on the number of pins in the cable will not light up.
-
Page 9: Using Test Tones
Switch the Cable Test/Tone Test selector on the receiver to the Tone Test position. The power LED will glow red. Insert one of the connectors of the cable into the appropriate jack on the CBT-MF. Select the amplitude of the test tone on the tone test volume selector (+0 dB, -10 dB,... - Page 10 XLR balanced to XLR balanced Jack Speakon Phono 1 = sleeve 1 = -1 1 = screen Pin 1 Pin 1 2 = tip 2 = +1 2 = hot Pin 2 Pin 2 3 = ring 3 = -2 Pin 3 Pin 3 4 = +2...
-
Page 11: Specifications
Specifications Dimensions (H × W × L) 1.25˝ × 6.5˝ × 6˝ (3.2 × 16.5 × 15.2 cm) Each chassis (W): 3.25˝ (8.2 cm) Weight 1.4 lb. (0.6 kg) Connectors Speakon 4-pin XLR M/F 3-pin XLR M/F 5-pin RCA (Phono) DIN 3-pin/5-pin TRS (3.5 mm) RJ45... - Page 12 To obtain warranty coverage, contact the Kopul Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Kopul along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
