- Page 1 8-in-1 CABLE TESTER User Manual CBT-8...
- Page 2 A six-way selection knob provides easy selection of the pins to be tested. LED indicators illuminate to show that each pin on the cable is properly connected. The CBT-8 can test cables with any combination of Speakon, XLR, RCA, 3-pin and 5-pin DIN, TRS, and 3.5 mm mini plugs.
- Page 3 Remove the battery during long periods of non-use. • Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Kopul will not be responsible for any damage. • Clean the unit with a soft dry cloth. Battery Check LED •...
-
Page 4: Installing The Battery
Installing the battery Lift the cover of the battery compartment in the direction of the arrow. A click indicates that it is unlocked. Slide the battery compartment out of the cable tester. Insert a 9-volt battery into the compartment with the orientation indicated by the diagram on the inside of the compartment. - Page 5 Operating the cable tester Testing cables: Plug the connectors of the cable into the corresponding jacks on either side or the top of the cable tester. Switch the selection knob to “1.” Turn the knob one click at a time to test each pin on the cable (see table on pages 5-6). Reading the LED indicators •...
- Page 6 Manually testing cables Plug the banana plugs of the leads into the corresponding red and black jacks on the front panel of the cable tester. Touch each lead to the corresponding pin on either end of the cable. A lit LED accompanied by a tone indicates good connectivity and continuity. Jack Speakon Phono...
-
Page 7: Specifications
Specifications XLR balanced to XLR balanced Pin 1 Pin 1 Pin 2 Pin 2 Dimensions (H × W × L) 1.4˝ × 3.5˝ × 5.5˝ Pin 3 Pin 3 (3.5 × 8.9 × 14 cm) Weight 1.4 lb. (0.6 kg) Material XLR unbalanced to XLR balanced All-metal construction... - Page 8 To obtain warranty coverage, contact the Kopul Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Kopul along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
