USSC 6041 How To Use And Maintain

USSC 6041 How To Use And Maintain

Hide thumbs Also See for 6041:

Advertisement

Quick Links

Download this manual
H
o
w
t
o
H
o
w
t
o
U
S
S
C
U
S
S
C
M
a
i
n
t
a
M
a
i
n
t
a
w
i
t
w
i
t
6
0
4
1
M
6
0
4
1
M
i
n
C
o
n
s
i
n
C
o
n
s
h
y
o
u
r
h
y
o
u
r
u
l
t
i
-
F
u
l
t
i
-
F
i
s
t
e
n
t
H
i
s
t
e
n
t
H
u
e
l
S
t
o
v
u
e
l
S
t
o
e
a
t
e
a
t
e
v
e

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6041 and is the answer not in the manual?

Questions and answers

Ray Hart
March 28, 2025

What are the specs for the Auger pellet drive motor? 1 rpm CW? 1 rpm ccw 4 rpm ?

0
1 comments:
Mr. Anderson
May 14, 2025

The specifications for the USSC 6041 Auger pellet drive motor are:

- 4 RPM (revolutions per minute)
- Clockwise rotation when facing the shaft
- Sealed bearing design (no lubrication or oiling required)
- Used as the agitator/stirrer motor in the USSC 6041 model
- 1-year replacement warranty

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for USSC 6041

Summary of Contents for USSC 6041

  • Page 2 Page 4 provides safety precautions you will need to consider as you operate the USSC 6041 Multi-Fuel Stove. On page 5, you will find a picture of the USSC 6041 Multi-Fuel Stove with annotations you can reference throughout the class.
  • Page 3 Also, you will learn the proper startup procedures for the USSC 6041 Multi-Fuel Stove. Lesson Two will be followed by a two part Check on Learning starting on page 18. The Lesson Two Check on Learning answer key can be found on page 26.

  • Page 4: Safety Precautions

    Safety Precautions o Do not operate the heater if you smell smoke coming from the heater. Push the “OFF” Touch pad, monitor your heater, and call your dealer. o Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or ’freshen up’...
  • Page 5 Stove Schematic...
  • Page 6 Your Stove Objective: In this lesson you learn how to properly clean the USSC 6041 Multi-Fuel Stove so that it is free of ash, creosote, and fly ash; thus allowing air to freely move though air vents. You will learn to identify key areas of the stove where airflow can be constricted and proper cleaning techniques to complete the task.
  • Page 7 Used to scrape hardened ash from ash pan. Cleaning the Burn Chamber The USSC 6041 Multi-Fuel Stove operates on a negative pressure venting system. Essentially, this means the stove draws air from the room it is in and pulls it through the stove for oxygen.
  • Page 8 Step Two: Clean Ash Pan and Vermiculite Action One: Use paintbrush to remove fly ash from vermiculite by brushing in the direction of the grooves until all fly ash is removed (Figure 4). Place vermiculite aside in a safe place. (Caution: Vermiculite is particularly brittle and if handled roughly could break) Action Two: Put ash pan and agitator into bucket of warm water and allow to sit until hardened ash is loosened.
  • Page 9 Step Four: Vacuum Burn Chamber and Rear Vent Chamber Action One: Use Ash-Vac to thoroughly vacuum burn chamber of all ash (Figure 10). Action Two: Locate four entry points to the rear vent chamber, behind the burn chamber, as indicated in Figure 11 where the yellow circles are. For the two lower entry points of the rear vent chamber, lift and remove trapdoors.
  • Page 10 Clean Exhaust Pipe As stated above, the USSC 6041 Multi-Fuel Stove operates on a negative pressure venting system. The exhaust pipe is the final portion of this system and if restricted will hamper operation of the stove and will decrease the ability to properly burnt pellets and maintain a consistent heat.
  • Page 11 Step Three: Replace Terminator Cap and Cleanout Cover Action One: Properly line up terminator cap slot with exhaust pipe grove; gently slide terminator cap onto exhaust pipe; and the turn clockwise until snug. Action Two: Properly line up cleanout cover slot with exhaust pipe grove; gently slide cleanout cover onto exhaust pipe;...
  • Page 12 Lesson One – Clean Stove: Check on Learning Instructions: This end of lesson check on learning will consist of two parts. Part one is a written exam to check your understanding of cleaning the stove prior to the hands-on practice. Part two will be hands-on practice with a subject matter expert providing over the shoulder assistance to ensure proper cleaning of the stove.
  • Page 13 Hands-On Practical Exercise You will now have an opportunity to work on an actual USSC 6041 Multi-Fuel Stove and clean it under the guidance of the instructor. The instructor will use the following checklist to ensure you are able to perform each step while cleaning the USSC 6041 Multi-Fuel Stove.
  • Page 14 A pellet with too much moisture will not burn effectively and will decrease the efficiency of the USSC 6041 Multi-Fuel Stove’s heat output. Also, a pellet with too much moisture in it will produce thicker ash which will block vents and require more frequent...
  • Page 15 Less creosote buildup Step Two: Purchase Pellets An important consideration prior to starting your USSC 6041 Multi-Fuel Stove is having an appropriate amount of pellets on hand. On an average winter, you may burn through a 3 tons of pellets. Pellets normally come in 40 pounds bags. The higher the feed rate you set your stove to, the more pellets you will go through in a week.
  • Page 16 pellets in the ground, even if on a pallet. This will prevent mice and other animals trying to dig into the pellets from the underside. Also, placing a waterproof tarp over the pellets helps cut down on moisture. Step Four: Check Pellets For Moisture As stated before, it is important not to use pellets with too much moisture in them.
  • Page 17 Turn Stove On Action One: Prior to operating your USSC 6041 Multi-Fuel Stove Ensure all doors, lids, and cleanouts are properly closed, and then turn on. Action Two: Refer to table below for various command inputs for the stove. Press the on button and set initial pellet rate, for startup you will select 2.
  • Page 18 Feed Rate = 1 to 3 1 Week’s Supply 1 Month’s Supply 4. State the proper procedures for storing wood pellets. 5. Which picture best depicts unacceptable pellets due to high moisture? 6. List proper steps to start the USSC 6041 Multi-Fuel Stove.
  • Page 19 Lesson Two – Hands-On Practical Exercise You will now have an opportunity to work on an actual USSC 6041 Multi-Fuel Stove; selecting proper pellets and starting the stove under the guidance of the instructor. The instructor will use the following checklist to ensure you are able to perform each step while loading pellets into and turning on the USSC 6041 Multi-Fuel Stove.
  • Page 20 Objective: In this lesson you learn how to adjust the pellet feed rate, agitator speed, draft fan, and damper on your USSC 6041 Multi-Fuel Stove to maintain a consistent heat. Motivator: A properly adjusted USSC 6041 Multi-Fuel Stove will evenly burn pellets, with minimal ash produced, and produce a predictable level of heat.
  • Page 21 List the Properties of a Good and Poor Flame Before we start adjusting the stove, it is important to know what a good flame is and what a poor flame is. In this portion of the lesson a picture followed by a description of each flame is given. (Figures 23 through 28).
  • Page 22 Adjust Draft Fan and Damper Action One: The true science in operating the USSC 6041 Multi-Fuel Stove is in the adjustments made to the draft fan and the damper. By increasing the draft fan you supply additional oxygen to the burn chamber permitting a higher flame and the ability to burn more pellets.
  • Page 23 Is Airflow Constricted After approximately a week of constantly running your USSC 6041 Multi-Fuel Stove, ash buildup will start to constrict the vents and cause poor airflow. This may occur earlier if the burn quality of pellets is not monitored, and pellets are permitted to burn poorly.
  • Page 24 6. State what type of flame the picture best depicts. c. _______ a. ______ b. ______ d. ______ e. ______ f. ______ 7. What two areas of the 6041 Multi-Fuel Stove will most likely cause poor airflow if filled with excess ash?
  • Page 25 Lesson Three – Hands-On Practical Exercise You will now have an opportunity to make adjustments on an actual USSC 6041 Multi-Fuel Stove in order to maintain a consistent heat. The instructor will use the following checklist to ensure you are able to perform each step while maintaining consistent heat with the USSC 6041 Multi-Fuel Stove.
  • Page 26 Lesson One – Self-check Answer Key 1. Ash-Vac, Paint Brush, 3.5” Chimney Brush, Bucket with Warm Water, Flathead Screwdriver 2. Once a week. 3. b 4. c 5. c 6. At least every two to three times you clean the burn chamber, unless needed sooner. 7.

  • Page 27: Control Panel

    Quick Reference Guide: USSC 6041 Multi-Fuel Stove Cleaning Equipment Control Panel Equipment Purpose Paint Brush To brush fly ash from the A: Pellet Feed Rate inner walls of the burn B: Room Fan chamber. Ash-Vac Specially designed vacuum C: Draft Fan...
  • Page 28 Different Types Of Flames Good Flame Start Up Flame Lazy Flame Flame Smother From Too Much Air Flame With Lack Of Air Too Much Smoke FLAME TYPE CORRECTIVE ACTION TO TAKE Lazy Flame First adjust damper out to provide more air. If that does not work increase draft fan up one level Flame With Too Much Air First, adjust damper in to provide less air.
  • Page 29 Appendix A Materials Revision Matrix Analysis Instructional Strategy Problem Identified Proposed Changes Evidence and Source Pre-Instruction and None None Questionnaire and Motivation Interview during analyze learners stage Entry Skills Everyone was ok with Add pictures of the Small-group evaluation the concept of collecting tools, especially the tools, but felt more chimney brush and Ash-...
