Divitec DT-CA7000VDVF-I2 User Manual

Specification
Model DT-CA7000VDVF-I2
Pick up Element 1/3" SONY Super HAD CCD
Effective Picture Elements
NTSC:976(H)×494(V) PAL:976(H)x582(V)
(H×V)
700 TV Line
Horizontal Resolution
0.001 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
More than 52dB
S/N Ratio
2:1 interface
Scanning System
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
0.45
Gama Characteristic
25 Meters (with ￠5X30 PCS Infrared LED)
IR Distance
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V（+/-10%)/400mA
Power/Current
2.8-12mm Manual Zoom Lens
Lens
￠135x 110(H)
Dimension (mm)
1200
Weight (g)
-30~+60℃ RH95% MAX
Storage Temperature
-10~+50℃ RH95% MAX
Operating Temperature

Packing List

No
Name
1.
Vandalproof
DT-CA7000VDVF-I2
IR Dome Camera
2.
User Guide DT-CA7000VDVF-I2
II
Franchiser：
Model Number
1
1
DT-CA7000VDVF-I2
Vandalproof IR Dome Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
