Summary of Contents for Inferno Wicked Lasers

  • Page 2 User’s Manual and Laser Safety Guide www.wickedlasers.com...
  • Page 3 F O R E W O R D First and foremost, we are laser enthusiasts. We desire nothing more than to achieve perfection in our craft. For us, pushing the limits of technology is part of our daily routine. It’s only impossible if we don’t try. As we continue to advance in our search for perfection, we’ve set benchmarks for others to follow and new limits for us to test.

  • Page 4: Table Of Contents

    Table of Contents S3 Inferno Series Technical Specifications We wanted to create the world’s most powerful handheld laser - we succeeded and inadvertently set a world record in doing so. We are extremely proud to be included S3 Inferno Series Diagram in the Guinness Book of World Records for 2007.
  • Page 5 W W W.W I CK E D LA SE RS. COM Technical Specifications Model Name: S3 Inferno Series Laser Product Class: Wavelength: 635nm Laser Type: Direct Diode Laser Power: 750mW Beam Shape: 8mm x 5mm Beam Divergence: ~3.0mRad Size: 257mm x 35.8mm...

  • Page 6: Using Your Laser: How To Power On

    WWW.W I CK E D L AS ER S. C OM WW W. WI CK E D L AS ER S . CO M Laser Diagram Using Your Laser : How To Power On REMOVABLE FRONT LENS EMISSION / BATTERY INDICATOR BATTERY COMPARTMENT INTERLOCK PIN TAIL CAP...

  • Page 7: Using Your Laser: The Smartswitch

    WWW.W I CK E D L AS ER S. C OM Using Your Laser : The SmartSwitch Using Your Laser : The SmartSwitch The S3 Series are the world’s first and only hand held lasers equipped with SmartSwitch™ technology. The SmartSwitch™ combines both safety and intelligence by requiring the user to follow a protocol of simple clicks and click/holds to operate the device.

  • Page 8: Smartswitch Codes Recap

    WWW.W I CK E D L AS ER S. C OM Using Your Laser : The SmartSwitch Using Your Laser : The SmartSwitch SmartSwitch 2.0™ Codes: To summarize: three quick clicks + two This is the first code you should remember short holds After unlocking your laser, you can select among the active modes by using one of these following codes when (press and hold the button briefly for less than 1 sec.) will unlock the laser.

  • Page 9: Color Perception Chart

    WWW.W I CK E D L AS ER S. C OM FDA Compliant Endcap Diagram Color Perception Chart Screw Safety Interlock How Intensely the Human Eye Perceives Different Colors Contact Guard Based on the human eye’s perception: Screw equal powers of green 532nm light is 20 times brighter than blue 445nm light, 8 times brighter than red 650nm light, and 190 times brighter than...

  • Page 10: Using Your Fda Compliant Endcap

    WWW.W I CK E D L AS ER S. C OM WW W. WI CK E D L AS ER S . CO M Using Your FDA Compliant Endcap Safety and Maintenance Safety and Maintenance CAUTION - Use of controls or adjustments or performance of procedures other than those specified CAUTION - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

  • Page 11: Lens Cleaning Procedure And Troubleshooting

    You can find this at the beam emitted will look similar to the above pictures. by Wicked Lasers, however, will not be covered in your your local camera or glasses store. Simply follow the cleaning instructions to restore the spot warranty.
  • Page 12 You will not be able to clean this as water has condensed inside the lens and/or crystal set. This condition can be repaired by Wicked Lasers, however, will not be covered in your warranty. A repair cost will apply.

  • Page 13: Class 4 Laser Safety Instructions

    WWW.W I CK E D L AS ER S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions DANGER CLASS 4 LASER : All visible lasers with beams over 500 milliwatts (1/2 watt) are classified as Class 4. AVOID EXPOSURE TO BLUE LIGHT Blue laser light can cause photochemical eye damage.
  • Page 14 WWW.W I CK E D L AS ER S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions DO NOT BURN OR DAMAGE MATERIALS OTHER IMPORTANT SAFETY AND USE CAUTIONS: DO NOT LOOK OR STARE The beam can char, burn or ignite materials. AT DIFFUSED REFLECTIONS Especially avoid dark, thin, and combustible DO NOT USE AS A LASER POINTER.

  • Page 15: Limitation Of Liability

    All S3 Inferno Series lasers come with a standard 12 Month Manufacturer’s Warranty. In no event shall Wicked Lasers or any of its subsidiaries or affiliates be liable for any indirect, special, incidental or consequential injury to persons or damage to property caused by the use of any of our products. By purchasing from Wicked Lasers, you hereby indicate that you...
  • Page 16 Manufacturer’s Warranty This warranty does not include defects or damages attributable to misuse, normal surface weathering, or damages caused by accidents or fire or other casualty or force majeure or any other causes or occurrences beyond the manufacturer’s control. To claim your warranty, please send this form or email support@wickedlasers.com with the following information: Full Name: Address:...
  • Page 17 1-877-952-7377 Unit 1010, Miramar Tower, 132 Nathan Road, Tsim Sha Tsui Kowloon, Hong Kong www.wickedlasers.com | support@wickedlasers.com...
