- Page 1 INDUSTRIAL ASSEMBLY INSTRUCTIONS Model: BI01, BI04...
- Page 2 INDUSTRIAL ASSEMBLY INSTRUCTIONS Model: BI01, BI04...
-
Page 3: Tools And Materials Required
INTRODUCTION Thanks for choosing Mobia Bikes. Please read these instructions thoroughly before attempting the assembly. If at any time during the assembly process you would like some help or have questions, Mobia’s customer service department is available Monday through Friday, 8.30 a.m. to 5 p.m. PST by calling 888-800-5999. -
Page 4: Bicycle Assembly Steps
BICYCLE ASSEMBLY STEPS: 1. Open shipping box and remove bicycle. 2. Extend the dual leg kickstand after unboxing to keep the bicycle upright and stable during further assembly. - Page 5 3. Remove the small box found at the bottom of the bicycle shipping box containing additional parts. Included in this small box Ref.# Description Notes Mobia Owner’s Manual Gates Carbon Drive Owner’s Manual Pedals- 1 set marked right and left on axle assembly depends on country Wheel reflectors- 1 set, amber color regulations...
- Page 6 HOW TO INSTALL HANDLEBAR/FRONT BASKET 4. Remove all packaging around the front stem. 5. Loosen the two M6X18 rear stem bolts by turning them in a counter-clockwise direction, but do not fully remove them. 6. Rotate the stem 180º forward to align with the front wheel. M6X18...
- Page 7 7. Remove the four M5X22 stem clamp bolts by turning the bolts in a counter-clockwise direction as well as the front stem cap. 8. Position handlebar into the front stem clamp. • Center the handlebar (right to left) with the stem clamp. ．Remove the stem clamp bolts...
- Page 8 9. Rotate the handlebar to the desired comfort angle for the wrist and arm positions.
- Page 9 10. Reinstall the four M5X22 stem clamp bolts by turning the bolts in a clockwise direction to 44.2 in-lbf (5 Nm) using a torque wrench. • Note: Use a torque wrench to tighten bolts at this time (tightening sequence 1->2->3->4)
- Page 10 11. Slightly loosen the two M5X15 bolts bolts attaching the basket support bars to the front fork dropouts bolts by turning the bolts in a counter-clockwise direction. Rotate the two basket support bars forward so the upper bolt holes are level with the ground. M5X15 M5X15...
- Page 11 12. Unbox the front basket and assemble onto the preinstalled support bracket near the front of the fork. Install the two M6X18 bolts, washers and locknuts provided by turning the bolts by hand in a clockwise direction. (Final tightening will happen in the following steps) •...
- Page 12 13. Assemble the support bars to the underside of the basket mount area using four M6X18 bolts by turning the bolts in a clockwise direction to 53–70 in-lbf (6-8 Nm) using a torque wrench. ． Torque to 6-8 Nm...
- Page 13 14. Check to make sure the basket is level. If not, adjust by sliding the basket forward or rearward until level. Tighten the two M6X18 bolts at the bottom of the basket by turning the bolts in a clockwise direction to 53–70 in-lbf (6-8 Nm) using a torque wrench. ．...
- Page 14 15. Tighten the two M5X15 bolts attaching the basket support bars to the front fork dropouts bolts by turning the bolts in a clockwise direction to 44–61 in-lbf (5-7 Nm) using a torque wrench. M5X15 M5X15 ． Torque to 5-7 Nm ．...
- Page 15 16. Align the stem/front basket/handlebar with the front wheel. 17. After insuring that the basket is properly aligned with the front wheel tighten the two M6X18 rear stem clamp bolts by turning the bolts in a clockwise direction using a torque wrench to 53.1 in-lbf (6 Nm), alternate tightening of bolts. ．...
- Page 16 18. Remove packaging on crank arms. 19. Install the right and left pedals. Please note each pedal is marked with an “R” or “L” on the axle flat area. The right pedal goes on the right side of the bike or the side where the belt or chain drive is located and the left pedal on the opposite side. Apply a small amount of lithium grease to both pedal threads before assembly to the crank arm.
- Page 17 20. Remove any remaining packaging on the bicycle. 21. Recheck all fasteners for tightness (according to the torque specification chart found at www.mobiabikes.com/support) and that no parts are rubbing against the wheels or drive train. 22. Test ride the bike in an area with no traffic or other obstacles and make sure both brakes and shifting work, that tires are properly working and that the seat is at the right height for the intended user.
- Page 18 MOBIA BIKES WORLDWIDE LIMITED WARRANTY Mobia Bikes (hereinafter “Mobia”, “our”, “we” or “us”) warrants to the original purchaser ("you") that the Mobia product for which you received this warranty is free from defects in material and workmanship for the time frames set forth below from the date of original purchase.
- Page 19 WWW.MOBIABIKES.COM ©2018 Mobia Bikes...
