- Page 1 URBAN COMMUTER ASSEMBLY INSTRUCTIONS Model: BB03, BB05...
- Page 2 URBAN COMMUTER ASSEMBLY INSTRUCTIONS Model: BB03, BB05...
-
Page 3: Tools And Materials Required
INTRODUCTION Thanks for choosing Mobia Bikes. Please read these instructions thoroughly before attempting the assembly. If at any time during the assembly process you would like some help or have questions, Mobia’s customer service department is available Monday through Friday, 8.30 a.m. to 5 p.m. PST by calling 888-800-5999. -
Page 4: Bicycle Assembly Steps
BICYCLE ASSEMBLY STEPS: 1. Open shipping box and remove bicycle. 2. Extend the dual leg kickstand after unboxing to keep the bicycle upright and stable during further assembly. - Page 5 3. Remove the small box found at the bottom of the bicycle shipping box containing additional parts. Included in this small box Ref.# Description Notes Mobia Owner’s Manual Gates Carbon Drive Owner’s Manual Pedals- 1 set marked right and left on axle assembly depends on country Wheel reflectors- 1 set, amber color regulations...
- Page 6 HOW TO INSTALL HANDLEBAR/FRONT BASKET 4. Remove all packaging around the front stem. 5. Loosen the two M6X18 rear stem bolts, but do not fully remove them. 6. Rotate the stem 180º forward to align with the front wheel. M6X18...
- Page 7 7. Remove the four (M5X22) stem clamp bolts by turning the bolts in a counter-clockwise direction as well as the front stem cap. 8. Position handlebar into the front stem clamp. • Center the handlebar (right to left) with the stem clamp. ．Remove the stem clamp bolts...
- Page 8 9. Reinstall the front stem clamp bolts by turning the bolts in a clockwise direction. • Note : only hand tighten bolts at this time (tightening sequence: 1 -> 2 -> 3 -> 4)
- Page 9 10. Assemble the two M5X22 bolts, washers, and 5mm lock nuts through the front basket and the stem support bracket. The use of an adjustable wrench may help to keep the lock nuts from turning. • Note : Tighten the two M5X20 stem clamp bolts by turning in a clockwise direction to 44.2 in-lbf (5 Nm) using a torque wrench. •...
- Page 10 11. Align stem/front basket/handlebar with the front wheel. 12. Tighten the four M5X22 stem clamp bolts by turning the bolts in a clockwise direction to 44.2 in-lbf (5 Nm) using a torque wrench. • Note : Using a torque wrench tighten bolts at this time (tightening sequence: 1 -> 2 -> 3 -> 4). ．...
- Page 11 13. After insuring that the basket is properly aligned with the front wheel tighten the two M6X18 rear stem clamp bolts by turning the bolts in a clockwise direction using a torque wrench to 53.1 in-lbf (6 Nm), alternate tightening of bolts. ．...
- Page 12 14. Remove packaging on crank arms. 15. Install the right and left pedals. Please note each pedal is marked with an “R” or “L” on the axle flat area. The right pedal goes on the right side of the bike or the side where belt or chain drive is located and the left pedal on the opposite side.
- Page 13 16. Remove any remaining packaging on the bicycle. 17. Add two cable grommets provided in the small parts box to keep the cables organized. The grommets require a slight amount of pressure to assemble over the cable housing. Position the opening of the cable grommet over the cable housing and apply pressure until the grommet snaps into place.
- Page 14 18. Add the front brake cable clip found in the small parts box, on the rear side of the fork blade to secure the front brake cable. 19. Recheck all fasteners for tightness (according to the torque specification chart found at www.mobiabikes.com/support) and that no parts are rubbing against the wheels or drive train.
- Page 15 MOBIA BIKES WORLDWIDE LIMITED WARRANTY Mobia Bikes (hereinafter “Mobia”, “our”, “we” or “us”) warrants to the original purchaser ("you") that the Mobia product for which you received this warranty is free from defects in material and workmanship for the time frames set forth below from the date of original purchase.
- Page 16 WWW.MOBIABIKES.COM ©2018 Mobia Bikes...
