VANTAGECONTROLS.COM
1061 South 800 East · Orem, Utah 84097 · Telephone 801 229 2800 · Fax 801 224 0355
Manufacturer:
Russound
Model Number/s:
ST2
Driver Version:
v. 52 or higher
DC Version:
v. 3.3 or higher
I. Overview
As part of its Premier Partner Program, Vantage Equinox products support the Russound model ST2 Tuner for control with the
InFusion System. The Equinox audio widget automatically populates the Russound user interface for the EQ41 and EQ73 in-wall
touchscreens and for mobile devices using the Equinox App on iPhones, iPads, iPods, and Android products.
II. Supported Features
Feature
Current Station
Display the current station
Current Band
Display and switch between AM and FM bands
Seek controls
Seek both backwards and forwards
Tune controls
Change stations via built in tuner
Station Presets
Cycle and assign station presets. Note that each Device can have its own presets.
EQ40 has 6 presets for each band and EQ73, EQ41, and EQApp have 8
Volume Control
Adjust the volume and display the current level on screen
Mute Control
Toggle the amplifier on or off
Multiple Tuners
Up to 2 independent tuners as sources with the same device
Supported
©Vantage Equinox
Widget:
Aliases:
Driver Category:
Connection Type:
Task Only Support
Russound:ST2
Audio
None
Tuner
Serial ( RS-232 )
EQ40
Not Supported
EQUINOX INTEGRATION GUIDE
Document Updated May 9, 2015
EQ41, EQ73 &
EQApp
page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Russound ST2

Summary of Contents for Russound ST2

  • Page 1 I. Overview As part of its Premier Partner Program, Vantage Equinox products support the Russound model ST2 Tuner for control with the InFusion System. The Equinox audio widget automatically populates the Russound user interface for the EQ41 and EQ73 in-wall touchscreens and for mobile devices using the Equinox App on iPhones, iPads, iPods, and Android products.

  • Page 2: Installation Steps

    V. Installation Steps The installation manual can be found in the link above. Follow the manual to install and configure the Russound. Once the system has been setup, check to make sure the region is correct. This can be done by: 1) Hold the “TNR SEL”...
  • Page 3 Version box. VII. Equinox 40 Setup To use Russound with the audio widget in the Equinox 40, follow these additional instructions: 6. Add EQ 40 Station – If not already added, in the Object 8. Set the area – If the EQ40...
  • Page 4 VIII. Add Additional Equinox Devices and Program Controller To use Russound with the Equinox audio widget, simply add and name any EQ 73 or EQ 41 (from Vantage Objects | Touchscreens in the Object Explorer pane) in their respective areas in your Design Center project (for the Equinox mobile app, no object needs to be added).
  • Page 5 Press to Enter Full Screen view Source Controls Zone Power Toggle (press the name of the zone) and Volume Controls Full Screen View of the Russound in the Audio Widget Enter Edit Mode view Switch to different zone Select source (can also swipe right/left) Switch radio to AM, FM or Sirius (if applicable) Preset buttons.

  • Page 6: Connection Diagram Example

    Cat 5 (RJ45) Gigabit Switch w/PoE Luxul XGS-1008P Ethernet w/PoE Cat 5 (RJ45) Audio Controller Russound MCA-C5 RS-232, Ethernet dB9 RS-232,Cat 5 Ethernet, RCA in Zone Speakers Various Various 16/4 Speaker Wire ©Vantage Equinox Russound: ST2 page 6 of 7...
  • Page 7 Tuner Seek Down Tuner Seek Up Tuner Tune Down Tuner Tune Up Select Tuner Preset Decrease Volume Increase Volume Volume Set Volume Volume Set Volume to Slider Mute Volume Mute Restore Volume Toggle Mute ©Vantage Equinox Russound: ST2 page 7 of 7...
