Page 1: User Manual
2019 p.n.300149 User Manual 4K 100M HDMI Extender + IR... - Page 2 2019 Introduction The Extender uses single cat5e or cat6(recommended) cables instead of HDMI cable to transmit high definition signal up to 100 meters, cutting down the cost. The Extender is designed to supply for long distance transmission of high definition signal. TX Extender RX Extender Features...
-
Page 3: Specifications
2019 Specifications: Length of CAT5e/CAT6 cable between Rx and TX ……………....Up to 100 meters HDMI Input …..…………………...………....4k/1080p/720p/576p/576i/480p/480i HDMI Output …..…………….…......4k/1080p/1080i/720p/576p/576i/480p/480i Max bandwidth ………………………………………………………………………….. 340MHz Max baud rate ……………….…….………………….………….…………………... 3x3.4Gbps Input video signal ………….…………………………………………….…..0.5~1.5Volts p-p Output DDC signal …………………………………………………....5Volts p-p (TTL) Input HDMI cable distance .... - Page 4 2019 Connection diagram: Application diagrams HDMI extender over IP is used in audio-visual conference, command and control center, ticketing platform, home theater, multi-media teaching, conference system and so on. Audio-visual conference Command and control center Home Theater...
- Page 5 2019 Physical interface diagram Port Function description Turn on the power, it turns blue. when there is signal Status input, it turns red HDMI IN HDMI Input port DC/ 5V 5V DC Power input port IR-TX IR-TX port R/ L Stereo output Cat5E/6 Cat5e / 6 cable connection port...
