Spare Parts Catalogue - Raytheon Anschütz Pilotstar D Manual

PilotStar D
Operator Unit
Connection Unit Type 102-863.NG001 E03, NG001 E04
1
3
2
Pos. Lager-Nr. Benennung
Stock-No.
3602068 Bediengerät, neu
grau
4002326 Bediengerät, AT
1
grau
4001904 Bediengerät, AT
schwarz
3602183 Anschlusseinheit, neu
2
4003704 Anschlusseinheit, AT
3 3600205 Verdrahtungskarte
4 3600206 Klemmenkarte
5 3610815 I/O-Karte
6 3610437 CPU-Karte
All depicted items which are not mentioned in the text are not applicable for this unit. Since further development may necessitate making modifications to existing
equipment, its conformity with the relevant illustrations and drawings is not always ensured. Raytheon Anschütz will be under no liability whatever that may arise from
any such differences.
3060
RAN/MAY-VSI 1003 EDITION 05
Type 102-864.NG003
Designation
Operator Unit, new
grey
Operator Unit
reconditioned; grey
Operator Unit
reconditioned; black
Connection Unit, new
Connection Unit,
reconditioned
Wiring PCB
Terminal PCB
I/O PCB
CPU PCB
Zeichnungs-Nr. Stck.
Part-No. Qty.
102-864.X02
102-864.NG003 AT
102-864.NG001 E03
AT
102-863.X02
102-863.NG001 E04
AT
102-863.20 E01 1
102-863.23 E01 1
102-863.X01 1
102-863.100 E04 1
Ersatzteilkatalog
SPARE PARTS
ANSCHÜTZ
CATALOGUE
4
5
6
Herst.-Code Versorgungs-Nr.
MFRC NSN
D2865
D2865
D2865
D2865
D2865
D2865
D2865
D2865
D2865
1 of 1
