- Page 1 Operating Manuel High Speed Screw Jack G1-G3 NEFF-High Speed Screw Jacks G1-G3 Model N/V/R Version N/V/R...
-
Page 2: Table Of Contents
NEFF High Speed Screw Jack G1-G3 Contents Important Information ............... 2 Instructions on Documentation ............2 Safekeeping of the Documentation ..........2 Used Symbols ..................2 Qualified Staff ................... 2 General Safety Instructions ............... 3 Overview of the High Speed Screw Jacks ..........4 Setup High Speed Screw Jack ............. -
Page 3: Important Information
NEFF High Speed Screw Jack G1-G3 Important Information This chapter contains important information on the safe handling of the product and on this operating manual. Instructions on Documentation The following instructions will guide you through the entire documentation. We assume no liability for damages resulting from non-compliance with this operating manual. -
Page 4: General Safety Instructions
Intended Use: The G1-G3 High Speed Screw Jacks are intended only to carry out lifting, lowering, tilting and feeding motions. Please find lifting capacities in our catalog or atwww.neff-gewindetriebe.de Any other use is considered misuse. -
Page 5: Overview Of The High Speed Screw Jacks
Neff High Speed Screw Jacks are used for applications where precise lifting, lowering, tilting and feeding motions are required. Our standard range comprises 3 models (G1-G3). The cubic housing that is machined on 4 sides allows for the installation of motors, gears or pressure transducers. -
Page 6: Setup High Speed Screw Jack
The bevel gear is seated on a hollow shaft which is attached via a feather key with the spindle. Version N/VK, lifting spindle Neff High Speed Screw Jacks Version N/VK with lifting spindle are equipped with spiral-toothed bevel gear, gear oil lubrication and greased spindle . -
Page 7: Assembly
NEFF High Speed Screw Jack G1-G3 Assembly General Assembly Instructions The High Speed Screw Jack is fastened via the housing or other fastening components (mounting plates or cardan adapters, see QR code below). The housing always needs to be screwed to a machined surface (not to rolled steel profiles or similar) in order to avoid misalignment or noise. -
Page 8: Assembly Guide
NEFF High Speed Screw Jack G1-G3 Assembly guide Ensure parallelism between spindle and machine guides adjustments, always start continued from the basic position, with the lowest clearance between gear and guided along the entire stroke length Avoid stress!. (Important for the life time)) -
Page 9: Mounting Several High Speed Screw Jacks In Parallel
NEFF High Speed Screw Jack G1-G3 Mounting Several High Speed Screw Jacks in Parallel Requirement: One High Speed Screw Jack is already installed and fastened as described in chapter 4. Bring the second High Speed Screw Jack into the planned position, but do not fasten it yet. -
Page 10: Disassembly The Screw
NEFF High Speed Screw Jack G1-G3 Disassembly the Screw Version R, rotating spindle: Loosening the cap (2) from the bearing neck with a sharp screw driver. (1) Loosen the threaded screw (3) from the spindle mounting nut. (4) ... -
Page 11: Commissioning
NEFF High Speed Screw Jack G1-G3 Commissioning Attention! Screw Jack oil filled and with vent valve: Install enclosed vent valve before operation. Note install position, vent valve must be mounted above the oil level. Attention! Check the operation of the limit switch. If possible, start the High Speed Screw Jack without any load and increase the load slowly. -
Page 12: Lubricants And Fill Quantities
NEFF High Speed Screw Jack G1-G3 Lubricants and Fill Quantities Types of factory grease: High Speed Screw Jacks with trapezoidal screws: Screw: NEFF Grease 2 Follow the QR-Code for Safety data sheet Bevel gear: Aral Degol GS220 Safety data sheet: www.neff-gewindetriebe.de... -
Page 13: Malfunctions
NEFF High Speed Screw Jack G1-G3 Malfunctions Service: Should malfunctions occur during operation, first try to identify the manner of the malfunction with the table below and to repair it. If it is a malfunction you can not repair, please contact our technical service (see last page). -
Page 14: Manufacturer's Declaration
NEFF High Speed Screw Jack G1-G3 Manufacturer’s Declaration We hereby declare that the following product: High Speed Screw Jack with trapezoidal screws or ball screws model N, R or V in the sizes G1-G3 for lifting and lowering loads was manufactured in accordance with the EC machinery directive 2006/42/EC annex II B on incomplete machinery.
