Incra Fence System Owner's Manual

Advertisement

Quick Links

Owner's Manual
Please read this Owner's
Manual before use and keep it at
hand for reference.
From simple routing operations
such as edge forming, grooving,
dadoing, or rabbeting, to high
quality joinery, your new INCRA
Fence System and Right Angle
Fixture combined with the INCRA
Jig Positioner will provide an
unlimited source of precision and
satisfaction for all your router table
projects. The T-slot design of the
Fence and Right Angle Fixture
permit the easy addition of user
made sub fences and auxiliary
faceplates for specialty
applications. Durable aluminum
construction and double laminated
Fence and Stop ensure reliable
performance for years to come.
SAFETY
Important safety instructions for using the INCRA Fence System
Before using the INCRA Fence System and Right
Angle Fixture, carefully read and follow all of the
instructions and safety information in this manual.
Always turn off the power and make sure that the bit or
blade is fully stationary before moving any component
of the INCRA Fence System to any new setting.
When using the INCRA Fence System and Right Angle
Fixture with any other tools, make sure that all safety
guards and other safety equipment supplied by the
manufacturer of that tool are securely in place and
functional
Never let any part of the INCRA Fence System or Right
Angle Fixture interfere with another tool's safety guards
or other safety equipment.
Taylor Design Group, Inc. warrants this product for one year from date of purchase. We will repair any defects due to faulty material
or workmanship, or at our option, replace the product free of charge. Please return the failing component only, postage prepaid, along
with a description of the problem to the address below. This warranty does not apply to parts which have been subjected to improper
use, alteration, or abuse.
INCRA Products are protected by the following US Patents: #4,793,604, #4,930,221, #5,195,730, #5,725,074, #5,423,360, #5,716,045, #6,237,457, #6,557,601, #6,672,190
©
Made in America by:
2005 by Taylor Design Group, Inc.
Taylor Design Group, Inc.
Printed in the U.S.A.
www.incra.com
You can also register your INCRA product online at www.incra.com. It's quick and easy!
Printed in the U.S.A.
P.O. Box 810262
Dallas, Texas 75381
© 2020 Taylor Design Group, Inc.
Use appropriate safety devices. Keep hands clear of
the bit or blade. Always use a push stick, rubber soled
push block, or other safety devices to keep your hands
safely away from the cutting tool.
Never let the bit or blade come in contact with the
aluminum body of the INCRA Right Angle Fixture.
Never attempt to hold your work to the INCRA Right
Angle Fixture using your hands alone. Always use a
clamp or other suitable holding device to securely hold
your work to the front face of the fixture.
Never let the bit or blade come in contact with the
wooden runners on your INCRA Right Angle Fixture.
Always clamp a wooden stop to the outfeed end of the
fence to stop the forward motion of the Right Angle
Fixture before the bit contacts the wooden runners.

WARRANTY

Made in America by:
Taylor Design Group, Inc.
PO Box 810262
Dallas, TX 75381
Phone: 972-242-9975
Scan this QR code to register your product online
Other patents granted or pending.
INCRA is a registered trademark of Taylor Design Group, Inc.
Tel: (972) 242-9975
1
INCRA is a registered trademark of Taylor Design Group, Inc.
1
Fax: (972) 242-9985
Web Site: www.incra.com
