  • Page 1 Vectis iX06/16/32/48 Network Video Recorders Installation Manual Vectis iX06 Vectis iX16/32/48 Network Video Recorders Installation Manual (EN) v1.0...
  • Page 2 Internet: http://www.vanderbiltindustries.com/ Training courses Vanderbilt International provides training courses for all products. The software included in this product contains some Open Sources. You may obtain the complete corresponding source code from us. See the Open Source Guide on the software CD (OpenSourceGuide\OpenSourceGuide.pdf) or as a printed document...

  • Page 3: Revision History

    Revision History Version Date / Time Description April 2016 The initial release © Vanderbilt 2016...

  • Page 4: Table Of Contents

    System Architecture ................11 Install Hardware ................... 12 Install HDD ..................... 12 7.1.1 HDD Requirement .................. 12 7.1.2 Install HDD(s) for Vectis iX06..............13 7.1.3 Install HDD(s) for Vectis iX16/32/48 ............18 7.1.4 Initialize HDD ..................21 Connect I/O .................... 25 7.2.1...

  • Page 5: Safety

    Danger of electrical shock on the open device  Only qualified personnel should open the unit. 1.2.1 Transport  Keep the packaging material for future transportation.  Do not expose the device to mechanical vibrations or shocks. © Vanderbilt 2016...

  • Page 6: Installation

     Use the device only in conjunction with a power supply cable that has been approved in your country and complies with the national standards. 1.2.3 Service and Maintenance  Do not attempt to service or modify this device yourself. Refer this work to qualified service personnel. © Vanderbilt 2016...

  • Page 7: Meaning Of Written Warning Notices

    Type of risk CAUTION There is a risk of minor to medium injuries or damage to property IMPORTANT Malfunctioning may result Meaning of Hazard Symbols The nature of the hazard is indicated by icons. Warning of a hazard © Vanderbilt 2016...

  • Page 8: Declaration Of Conformity

    This product complies with the requirements of the following standards: 2.1 CE 2.2 FCC 2.3 EAC & ACMA The EU declaration of conformity is available to the responsible agencies at: Vanderbilt International (IRL) Ltd. Clonshaugh Business and Technology Park Clonshaugh Dublin 17 Ireland European Directive 2004/108/EC “Electromagnetic Compatibility”...

  • Page 9: Fcc

    EAC & ACMA This device has been tested and found to comply with the requirements of EAC (EurAsian Conformity) and ACMA (Australian Communications and Media Authority). © Vanderbilt 2016...

  • Page 10: Technical Data

    Technical Data Technical Data Type Vectis iX06 Vectis iX16/32/48 Core™ i5-2400 Processor ® ® ® Intel Celeron G1620 Processor Intel Memory DDR3-1333 4G DDR3-1333 4G Operation System (OS) Windows 7 Embedded Network Protocols TCP/IP ,UDP, HTTP, HTTPs, SMTP,SNMPv3, DNS, DHCP, NTP, ARP, ICMP, FTPc, FTPs, DDNS, RTP (RTCP, RTSP), IGMPv3, UPnP, CIFS, NFS, IEC802.1x...
  • Page 11 Technical Data Global-Features Vectis iX06 Vectis iX16/32/48 Configurations Configurations of NVR, Camera, Event, Alarm, Device, DI/DO, etc. User Authority Export Video Clip, PTZ Control, Live View, Playback, Alarm Search, Configuration, Remote System Control, etc. Recording Mode Full Time Recording, Recording by Schedule, Event, Alarm, Motion Detection...
  • Page 12 Technical Data Vectis iX06 Vectis iX16/32/48 Minimum system requirements Free RAS software CPU: Pentium Intel Dual Core 2.4GHz or above RAM:2048 MB at least Operation System: Windows XP SP2 and Windows XP SP3 Display: Graphic-card nVidia chipset, DirectX3D support, Minimum resolution 1280X1024, recommended resolution 1680X1050.)

  • Page 13: Details For Ordering

    Details for Ordering Details for Ordering Weight* Part Number Type Designation V54569-C104-A100 Vectis iX06-1TB NVR Vectis iX06-1TB NVR 6ch, H264, Max. 72Mb/s 3.62 kg V54569-C105-A100 Vectis iX16-4TB NVR Vectis iX16-4TB NVR 16ch, H264, Max. 288Mb/s 15.79 kg V54569-C106-A100 Vectis iX32-8TB NVR Vectis iX32-8TB NVR 32ch, H264, Max.

  • Page 14: Package Contents

    Package Contents Package Contents Vectis iX06 NVR  Vectis unit  Power cable  90W power adapter  HD screws  Product CD  Installation Manual Vectis iX16/32/48 NVR  Vectis unit  Power cable  HD screws  Rack mount handle kit ...

  • Page 15: System Architecture

    System Architecture Here in this chapter are the diagrams that show the possible system architecture with one Vectis unit: Vectis iX06 Vectis iX16/32/48  For Vectis iX16/32/48, choose 2 display outputs out of 3.  Network connection cable between NVR and Giga switch should be CAT 5E or...

  • Page 16: Install Hardware

    7.1.3 Install HDD(s) for Vectis iX16/32/48 7.1.4 Initialize HDD 7.1.1 HDD Requirement It is always recommended to use the hard disks certified by Vanderbilt. Find the certified hard disk list at: www.vanderbiltindustries.com Vanderbilt does not guarantee the system performance and system stability if a HDD model that is not certified by Vanderbilt is used.

  • Page 17: Install Hdd(S) For Vectis Ix06

    Install Hardware 7.1.2 Install HDD(s) for Vectis iX06 See the picture below. Loosen the two knobs and slide the top cover from the system. Once the top cover is gone, the inside of the system becomes viewable. Two HDD trays are available in the system, one is bigger and the other is smaller.
  • Page 18 See the picture below. Loosen and remove the 4 screws. Dismount the HDD trays from the system. Place an HDD in the small HDD tray. Make sure its SATA connector is positioned as the picture below shows: SATA connector © Vanderbilt 2016...
  • Page 19 See the picture below. Fasten 2 screws to each side of the HDD tray to fix the HDD in place, total 4 screws. Place another HDD in the bigger tray. Make sure its SATA connector is positioned as marked in the picture below. © Vanderbilt 2016...
  • Page 20 Install Hardware See the picture below. Fasten 4 screws to fix the HDD in place. Put the bigger HDD tray back to the system. Connect the SATA cable and power cable to the HDD. © Vanderbilt 2016...
  • Page 21 Put the smaller HDD tray back to the system. Connect the SATA cable and power cable to the HDD. See the picture below. Restore the 4 screws to fix the HDD trays in place. Restore the top cover to the system. © Vanderbilt 2016...

  • Page 22: Install Hdd(S) For Vectis Ix16/32/48

    Dismount the top cover from the system. The inside of the system then becomes viewable. Two HDD racks are available. See the pictures below. Loosen and remove the 4 screws that fix an HDD rack. Then dismount the rack from the system. © Vanderbilt 2016...
  • Page 23 See the picture below. An HDD rack provides 3 trays. Slide your HDD(s) into the available tray(s) and fix the HDD(s) in place by fasten the screws. Install both HDD racks back to the system and connect the HDD(s) with the SATA data / power cables. © Vanderbilt 2016...
  • Page 24 Install Hardware After the HDD(s) are installed, it looks just like what the pictures below show. Restore the system’s top cover. © Vanderbilt 2016...

  • Page 25: Initialize Hdd

    The newly added hard disk drive(s) need to be initialized before a storage volume can be created. On the Windows desktop, right-click on the My Computer icon A context menu then opens. From the context menu that opens, click Manage. The Computer Management window then opens. © Vanderbilt 2016...
  • Page 26 Install Hardware On the left pane of the Computer Management window is a Computer Management (Local) tree, double-click Storage. the Computer Management (Local) tree Double-click A drop-down list then opens. The drop-down(s) © Vanderbilt 2016...
  • Page 27 The right pane then shows the local disk drives detected. A “non-Initialized” HDD is displayed with a stop sign on it. Disk 1 A “non-Initialized” Right-click on a “non-Initialized” HDD. A context menu then opens. Click Initialize Disk. An Initialize Disk window then opens. © Vanderbilt 2016...
  • Page 28 Select the HDD(s) to initialize. Then hit the OK button. Select the HDD to initialize. For HDD size greater than 2TB, select GPT instead of MBR when initializing. The selected HDD(s) then become initialized by changing the status to “Online”. © Vanderbilt 2016...

  • Page 29: Connect I/O

    I/O connection for the system. 7.2.1 Vectis iX06 7.2.2 Vectis iX16/32/48 7.2.1 Vectis iX06 Vectis iX06 Rear Side USB port: Connect a keyboard to one of the USB ports. USB port: Connect a mouse to one of the USB ports.

  • Page 30: Vectis Ix16/32/48

    Install Hardware - Vanderbilt will not be liable for any malfunction of the system if the customer installs any non-certified 3rd-party application in the system. - Vectis iX06 series support decoding resolution from D1 up to 20M - DISCONNECT any USB device other than keyboard & mouse before the system starts.

  • Page 31: Configure System

    In Windows O.S., click the Start button | Control Panel | Date and Time. In Windows O.S., click the Start button | Control Panel | Clock, Language, and Region | Date and Time. A Date and Time window then opens. © Vanderbilt 2016...
  • Page 32 Click the Change date and time… button and set the date and time of your locale. Set the time zone of your locale in the Time Zone Settings. And set the date and time of your locale in the Date and Time Settings. © Vanderbilt 2016...
  • Page 33 Configure System Reopen the Date and Time window. Click the Internet Time tab. Click The Internet Time tabbed page opens. © Vanderbilt 2016...
  • Page 34 Hit the OK button to save the change and quit the setting. Internet connection must be available to synchronize with an Internet time server. However it isn’t recommended to do it since a system disabled from protection is liable to any harm by way of the Internet. © Vanderbilt 2016...

  • Page 35: Configure Network

    In Windows, click the Start button | Control Panel | Network and Internet | Network and Sharing Center | Change adapter settings. A Network Connections window opens. Right-click on the active connection. Right-click on the active connection. A context menu opens. © Vanderbilt 2016...
  • Page 36 Click Properties from the context menu. A [name of the connection] Properties sheet opens. Click. From the properties sheet, click the Internet Protocol Version 4 (TCP/IPv4). Then it becomes selected by a highlight. It becomes selected by a highlight. © Vanderbilt 2016...
  • Page 37 Then press the OK button to finish and quit the setting. Before conducting the network configuration, make sure the network environment is ready. If the network is not available, contact your network administrator for further help. © Vanderbilt 2016...

  • Page 38: Configure Screen Resolution

    Resolution box to open the list. Select 1680 x 1050 (the recommended). Hit the Apply button to apply the change Hit the OK button to apply the change and quit the setting. The minimum supported screen resolution is 1280 x 1024. © Vanderbilt 2016...

  • Page 39: Configure Software

    Manager) to get the job done. Follow through the guide below to create a volume for the system’s storage. On Windows desktop, double-click the SCM icon. In Windows, click the Start button | All Programs | Vanderbilt | Vectis iX NVR | Storage Configuration Manager. A Logon window then opens.
  • Page 40 In the Volume Name field, enter the name of the volume. In the Available Hard Disks box, click the hard disk(s) to add. Then click the button. Enter the name of the volume. Click Click the hard disk drive(s) to add. © Vanderbilt 2016...
  • Page 41 Click the Add to List button to add the volume into queue for formatting. Click the Create button. A Confirm windows opens showing the warning message “Create Volume will reallocate your hard disk and you will lose current data on the disk. Are you sure to keep doing these jobs?” © Vanderbilt 2016...
  • Page 42 It takes a while to create a volume. When the creation is successfully through, the progress prompt will close and the SCM will show “Create volume successfully“ in its log box. The log box shows “Create volume successfully“. © Vanderbilt 2016...

  • Page 43: Auto-Add A Camera

    Launch & Log in to NVR Manager To launch the NVR Manager: On Windows desktop, double-click the Vectis iX NVR Manager icon In Windows, click the Start button | All Programs | Vanderbilt | Vectis iX NVR | Vectis iX NVR Manager. A Logon window opens.

  • Page 44: Start To Add Cameras

    Start to Add Cameras To add cameras: Launch and log in to NVR Manager as described in 9.2.1 Launch & Log in to Manager. NVR Manager opens. On the software’s toolbar, find the four mode icons. The mode icons © Vanderbilt 2016...
  • Page 45 NVR Manager then changes to Configuration Mode. In Configuration Mode, find the left pane and click the Device tab. The Device Device The Device tabbed page then opens in the left pane. The Device tabbed page opens in the left pane. © Vanderbilt 2016...
  • Page 46 An Auto Discovery window then opens. Click the down-arrow at the Vendor box to open the drop-down list. Select a preferred vendor name from the list. Then hit the Search button. An Authorization Input window then opens. © Vanderbilt 2016...
  • Page 47 Auto Discovery window. Select the camera(s) to install and click the Import button. The system then proceeds to import the selected camera(s). A Modify Camera Configuration page will be opened to allow changes to a newly imported camera. © Vanderbilt 2016...
  • Page 48 On the Modify Camera Configuration page, click the Recording Settings tab. The Recording Settings tabbed page then opens. Hit the Assign Storage button. An Assign Storage window opens. Select the preferred volume and click the OK button. Select the preferred volume. Click. © Vanderbilt 2016...
  • Page 49 Configure Software The selected volume is assigned to the camera. Click the OK button to finish and quit the setting. To set up the schedule recording, see NVR user manual for more details. © Vanderbilt 2016...

  • Page 50: Enable Motion Recording

    Launch and log in to NVR Manager as described in 9.2.1 Launch & Log in to Manager. NVR Manager opens in Display Mode by default. On the software’s toolbar, find the four mode icons. The mode icons © Vanderbilt 2016...
  • Page 51 NVR Manager then changes to Configuration Mode. In Configuration Mode, find the left pane and click the Device tab. Device The Device tab The Device tabbed page then opens in the left pane. The Device tabbed page opens in the left pane. © Vanderbilt 2016...
  • Page 52 ) to expand the list of the imported camera(s). The imported camera list then opens. Click the camera to enable motion recording for. Then click the edit button Click the camera so it becomes selected by a highlight. Click © Vanderbilt 2016...
  • Page 53 On the Configuration page, click the Motion tab. The Motion tabbed page opens. On the Motion tabbed page, enable the camera to receive motion detecting events and configure the motion detecting features such as sensitivity, interested regions and so on. © Vanderbilt 2016...
  • Page 54 On the Recording Settings tabbed page, find the Recording Schedule Settings group and select Disable for the Rec Schedule setting. Select Find the Recording Disable. Schedule Settings group. Click the Alarm tab. The Alarm tabbed page opens. © Vanderbilt 2016...
  • Page 55 Click the OK button to finish and quit the setting. Different camera has different naming and ways to setup motion detection. The system will conduct self-check and self-maintenance by auto restarting itself monthly at 3:00 AM at the 23rd. © Vanderbilt 2016...

  • Page 56: System Backup & Recovery

    Enter key. Select option 1. Select Backup by entering 1 and hitting the Enter key. If you select any option by mistake, enter 0 and hit the Enter key to go back to the previous step. © Vanderbilt 2016...
  • Page 57 Backs up the system state to external storage.  Back up file to the You can save as many as backup files as you external disk want to as long as the external disk has enough space. Follow the onscreen instructions to proceed. © Vanderbilt 2016...

  • Page 58: Recover System State

    Restore system with Brings the NVR (including software settings) an external backup back to a previous state that is saved on file external storage. © Vanderbilt 2016...
  • Page 59 System Backup & Recovery To back up the system state, see 10.1 Back up System State. Follow the onscreen instructions to proceed. Once the recovery is through, the system auto-restarts to apply the change. © Vanderbilt 2016...

  • Page 60: Troubleshooting

    The camera’s IP address has different subnet settings from the NVR (the Ethernet adapter card). It is likely that the camera isn’t supported by the NVR, please see the supported cameras list at Vanderbilt website at: www.vanderbiltindustries.com I can't get any video after the camera is added. Why? The possible root cause might be: ...

  • Page 61: Disposal

    For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. © Vanderbilt 2016...
  • Page 62 Issued by Vanderbilt © Vanderbilt 2016 Clonshaugh Business and Technology Park Data and design subject to change without notice Clonshaugh Supply subject to availability Dublin 17 Document no. C-300183 Ireland Document version: v1.0 www.vanderbiltindustries.com Edition date: 11/05/2016...
