BFT Mitto 2M Overview

BFT Mitto 2M 4M Remote Coding Instructions
Programming of your new remote control – overview
There are many different types of receivers, so coding varies based on the type of
receiver that you have. To simply put it, if your receiver has a digital screen, use
option 2. If your receiver does not have a digital screen, use option 1.
1) Receiver without digital screen (first type of receiver):
1. Open your motor, and try and find the receiver. If your receiver is in a case, then
remove the casing. You are trying to find something that looks like a control board
2. If you wish the transmitter to activate output 1, press push button SW1,
otherwise press push button SW2 to activate output 2. The LED light on receiver
will start to flash
3. Press and release the number "3" and the number "4" button on your new
remote control at the same time. The will cause the LED to stop flashing, and
remain illuminated
