Summary of Contents for Tunstall Find-me
- Page 1 Tunstall Carers Watch...
- Page 2 Tunstall Carers Watch Find-me Technologies Pty Ltd Suite 11 65-69 MacGregor Terrace Bardon, Qld AUSTRALIA 4065...
-
Page 3: Table Of Contents
CONTENTS Important notes Introduction Inside the box About the Find-me Tunstall Carers Watch General care Charging the battery Turning the watch on/off 10-11 Using the red emergency button 12-13 Fall alert 14-15 Medication alert Low battery alert Activate your watch... -
Page 4: Important Notes
IMPORTANT The Find-me Tunstall Carers Watch is not a mobile phone and as such is not supplied with automatic support for emergency numbers 000, 112 or 111. The Carers Watch is water resistant and can be worn in the shower. It should not be used for swimming or kept in water for long periods of time. -
Page 5: Introduction
INTRODUCTION Thank you for choosing the Find-me Tunstall Carers Watch. Before you start, please ensure that the following items are included in your package. If any of these items are missing please contact your distributor immediately using the details on the back of this manual. -
Page 6: About The Find-Me Tunstall Carers Watch
The Find-me Tunstall Carers Watch (FM1000) is NOT a life saving device. It is a locator unit that functions off mobile and cellular network activity as outlined in this manual. Neither Find-me technologies or Tunstall accepts responsibility or liability for a unit being unable to be located due to and not limited to events such as network unavailability, unit malfunction, battery life, submersion in water and user misuse. -
Page 7: General Care
GENERAL CARE The Carers Watch can be cleaned using a light spray of water and cloth. Please do not use heavy detergents or chemicals on the Carers Watch as this may damage the watch and void the warranty. PLEASE NOTE As the watch is a mobile transmitting device, it must be turned off at airports and on any aircraft in accordance with civil aviation laws. -
Page 8: Charging The Battery
CHARGING THE BATTERY The Find-me Tunstall Carers Watch has a rechargeable battery that can be charged at any time. Simply clip the watch onto the magnetic charger (as shown in the photo). If the magnetic charger does not ‘click’ in, rotate the watch slightly until it does. -
Page 10: Turning The Watch On/Off
TURNING THE WATCH ON After charging the battery, press the ON/OFF button for 3 seconds and the Carers Watch will power up with the power on sound. The Carers Watch will display default time and day details. These details will be automatically updated when the Carers Watch has received the initial satellite signal. - Page 11 ON/OFF 12:12 The default screen will display the time and day. When not in use, the screen will deactivate to Monday conserve battery life and reactivate on tilting the Carers Watch towards you.
-
Page 12: Using The Red Emergency Button
USING THE RED EMERGENCY BUTTON Press the emergency button for 3 seconds. You will hear ‘emergency response activated, your emergency contact is being notified’ . The watch will then connect you via a two-way hands-free phone call to your authorised contacts. If possible, please hold the watch 10-15cm from your mouth while talking. - Page 13 EMERGENCY BUTTON The animated Find-me logo will appear on your screen advising you that an emergency call has been activated.
-
Page 14: Fall Alert
FALL ALERT In the case of a slip or fall being detected, the fall alert will automatically be activated and the watch will call your authorised contact(s). The Carers Watch will notify this alert by saying ‘fall alert activated’ and the animated icon to the left will be displayed on the Carers Watch. - Page 15 A BUTTON...
-
Page 17: Medication Alert
MEDICATION ALERT The Carers Watch can be programmed to play a medication reminder at set times. If you choose to set these in your user preferences, an alert will be heard at the pre-set times. Please note: only the watch wearer will be alerted. LOW BATTERY ALERT When the battery is running low you will hear ‘low battery alert’... -
Page 18: Activate Your Watch
Purchase a micro size SIM on a SIM only plan including at least 10 minutes of talk time, 100Mb data and 50+ SMS per month. Tunstall recommends you purchase a SIM on the Telstra network for greater coverage across Australia. - Page 19 Set authorised contacts Add your authorised contacts by entering their name, mobile number and email address, then select Add New Contact. By ticking the relevant boxes, you can choose which contacts receive an SMS, email and/or map link to the wearers location when the emergency button is activated. Up to 2 authorised contacts can be added.
- Page 20 Step 5. Customise watch settings Click the Settings button from the Main Menu of the Find-me tracking portal. In the settings screen you can program: • Mobile numbers for the A and B buttons • A mobile number for the watch to call when the emergency button is activated.
- Page 21 This will make a voice call to your authorised contacts. Have your authorised contacts confirm your location details from the Find-me Tunstall website. Your authorised contacts will need to use your login details. Reminder: A and B buttons only make voice calls to the defined authorised contact.
-
Page 22: Troubleshooting
TROUBLESHOOTING Carers Watch does not turn on Flat battery - see page 8 charging the battery. Carers Watch not updating time Poor signal - see page 10 turning the watch on. Display says SIM not inserted Turn the watch off - see page 10. Remove the SIM and then reinsert - see page 19. - Page 24 If you have any queries for your Find-me Tunstall Carers Watch, please contact your local Tunstall Office Tunstall Australasia 1800 603 377 www.tunstallhealthcare.com.au Tunstall New Zealand 0800 488 678 www.tunstall.co.nz Tunstall Carers Watch...
