Non-Magnetic and Non-Reflective Tower
MPB 2019 ver. 1.02
MPB S.r.l.
Via Giacomo Peroni
400/402
00131 Rome - Italy
User manual
NMR-03
up to 4 meters
applicable to version 1.0 of NMR-03
Tel +39 0641200744
Fax +39 0641200653
info@gruppompb.com
www.gruppompb.uk.com
Advertisement
Related Manuals for MPB NMR-03
Summary of Contents for MPB NMR-03
- Page 1 MPB S.r.l. Tel +39 0641200744 Via Giacomo Peroni Fax +39 0641200653 400/402 info@gruppompb.com 00131 Rome - Italy www.gruppompb.uk.com User manual NMR-03 Non-Magnetic and Non-Reflective Tower up to 4 meters applicable to version 1.0 of NMR-03 MPB 2019 ver. 1.02...
- Page 2 USER MANUAL N M R – 03 Release history Version Description First version 1.02 New mounting details - 2 -...
-
Page 3: Safety Notes
N M R – 03 SAFETY NOTES Read before using the product MPB works to provide the best safety conditions available and complies with the latest safety standards. The instrumentation described in this manual was produced, tested and left the factory in conditions that fully comply with European standards. -
Page 4: General Information
Mounting ........................... - 8 - Warnings ..........................- 17 - 1 General information The NMR-03 is a tower for the support of sensors and antennas in environments where no metallic or reflective materials are allowed. Entirely made of fiberglass tubes, DELRIN, PLA. PEEK, polyethylene, Nylon and ABS. - Page 5 USER MANUAL N M R – 03 NMR-03 T650 NMR-02 NMR-03 hub top NMR-02 upper junction poles - 5 -...
- Page 6 USER MANUAL N M R – 03 NMR-03 2T2000 NMR-03 pole joint NMR-03 sliding support NMR-03 clamp with support - 6 -...
- Page 7 USER MANUAL N M R – 03 NMR-03 T500 tube NMR-03 winch NMR-03 threaded bar NMR-03 M8 knob NMR-03 M8 knob with M8x60mm screw NMR-03 rope - 7 -...
- Page 8 USER MANUAL N M R – 03 NMR-03 counterweight 3 Mounting Follow the steps below to mount the NMR-03 in the easiest and most comfortable way Step 1 Place the base on a flat surface Step 2 Insert T650 on the base...
- Page 9 USER MANUAL N M R – 03 Step 3 Place 2t2000 on the ground and insert the pole joint Step 4 Insert the hub top and the hub on the 2T2000. Attention use the side where the junction are at 700mm Step 5 Insert the sliding...
- Page 10 USER MANUAL N M R – 03 Step 6 Insert the assembly of step 5 on that of step 2 Step 7 Insert the threaded bars on the hub and screw on the base. Tighten well them until complete tightening. After that insert the knobs on the...
- Page 11 USER MANUAL N M R – 03 come out of the hub and tighten Step 8 Insert on the second 2T2000 the upper junction poles Step 9 Move at 90° the base, and Insert last 2T2000 as in figure Step 10 In the same position of step 9 place...
- Page 12 USER MANUAL N M R – 03 Step 11 Move the tower in the vertical position, Straighten the pole and fasten the winch to the desired height with appropriate supports Step 12 Insert the rope into the appropriate holes as shown in the figure.
- Page 13 USER MANUAL N M R – 03 Step 13 Insert the T500 tube in clamp with support. Push the tube all the way down, center the holes and insert in the screw the bolt into the hole making sure you have set T500.
- Page 14 USER MANUAL N M R – 03 Step 14 Insert the horizontal bar in the sliding support. Turn the winch crank to tension the rope. After that cut the band on the winch. Step 15 Insert the counterweig hts and relative fixing knobs Step 16...
- Page 15 USER MANUAL N M R – 03 antenna can be fixed for both vertical horizontal polarization. Insert the antenna cable into the antenna holder to avoid twisting the cable Step 17 Scroll horizontally with the counterweig hts and with the bar to balance the weight, refer to the level...
- Page 16 USER MANUAL N M R – 03 Step 18 Lift the antenna with the winch to the desired height - 16 -...
- Page 17 USER MANUAL N M R – 03 4 Warnings Periodically open the cap of the winch and make sure that the gear is well greased. If necessary, add the grease to lubricate the toothed wheels 2. Check before lifting that the 3 nodes of the sliding support are tight 3.
