0154561en 0403 Internal Vibrator M 1000 M 2000 M 3000 OPERATOR’S MANUAL...
Page 3
Foreword Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.
Page 4
Nameplate / Typenschild / Placa de Identificación / Plaque signalétique A nameplate listing the Model Number, Item Number, Revision, and Serial Number is attached to each unit. Please record the information found on this plate so it will be available should the nameplate become lost or damaged. When ordering parts or requesting service information, you will always be asked to specify the model, item number, revision number, and serial number of the unit.
Operating Information Contents Safety Information ................1A-2 Safety ....................1A-3 Technical Data ..................1A-4 Safety & Informational Labels .............. 1A-5 Label Locations ..................1A-5 Application ................... 1A-6 Recommended HMS Combinations ............. 1A-6 Extension Cords ................... 1A-7 Connecting Motor to Power Supply ............1A-7 1.10 Assembling Head, Motor and Shaft ............
OPERATION Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
OPERATION Safety When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury! The guidelines following will help the user maintain operator safety. DANGER Never operate motor with damaged or worn electrical When motor is used outdoors, use only extension cords! When using an extension cord be sure to use cords intended for and marked for outdoor use.
OPERATION Safety & Informational Labels This WACKER machine uses international pictorial labels where needed. These labels are described below: Label Meaning Wear eye, ear, and head protection when operating machine. Read operator’s manual for machine information. Label Locations FOR SAFE OPERATION READ CAUTION OPERATOR’S MANUAL.
OPERATION Application Recommended HMS Combinations The HMS series of internal vibrators can be used over a The HMS Sytem has three basic parts: wide range of applications for the consolidation of con- motor crete. shaft head WACKER internal vibrators are typically used for on-site These three pieces can be assembled in various combi- vibration of concrete for foundations, walls, columns, nations to meet job requirements.
OPERATION Extension Cords Extension cords are often required on jobsites to connect Table 2 the motor. When choosing an extension cord make sure Minimum wire size for extension cords - it has adequate wire size for safety. An undersized cord AWG (mm will cause a drop in line voltage resulting in a loss of power MAXIMUM CORD LENGTH - ft.
OPERATION 1.10 Assembling Head, Motor and Shaft 1. Apply pipe sealant to threads on head . Attach head onto end of flexshaft (left hand thread) and tighten using a wrench. 2. The shaft is attached to motor using a quick discon- nect coupler.
OPERATION 1.12 Periodic Maintenance Before Operating Inspect air filter and vent holes. Clean or replace dirty or clogged filters. Inspect electrical cords for wear or damage. Do not use damaged cords. Every 50 hours Inspect brushes in motor. Every 100 hours Clean and lubricate core in shaft.
OPERATION 1.15 Lubricating Shaft Remove wire core from shaft casing and wipe with a clean cloth. Apply a liberal amount of flex-shaft grease to the entire length of the core by hand . Insert core into casing and rotate it. Repeat this procedure several times. CAUTION: DO NOT try to force the casing full of grease.
OPERATION 1.17 Checking Head for Wear Periodically measure the outside diameter of the head casing in the area of most noticeable wear. Replace head if measured diameter is less than the minimum wear diameter. MINIMUM DIAMETER WEAR DIAMETER in. (mm) in.
OPERATION 1.19 Wiring Schematics M1000 M2000 M3000 115V 5843 6305 5845 7159 7653 NOT USED ON 6551 230V 5041 6551* 5800 SWITCH B - BLACK or BROWN * NO GROUND WIRE STATOR G - GREEN or GREEN W/ ROTOR YELLOW STRIPE LH BRUSH W - WHITE or BLUE RH BRUSH...
Page 17
EC - CONFORMITY CERTIFICATE EG-KONFORMITÄTS ERKLÄRUNG CE-CERTIFICADO DE CONFORMIDAD CERTIFICAT DE CONFORMITÉ DE LA CEE WACKER CORPORATION - MENOMONEE FALLS, WISCONSIN USA hereby certify that the construction equipment specified hereunder bescheinigt, daß das Baugerät certifica que la máquina de construcción atteste que le matériel 1.
