Sielox AC-1500 Controllers Series
Installation Manual
Copyright © 2006-2007 by Sielox, LLC.
Released July 2007.
Published by:
Sielox, LLC. 170 East Ninth Avenue
Runnemede, NJ 08078
Rev.: DRAFT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-1500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sielox AC-1500 Series

  • Page 1 Sielox AC-1500 Controllers Series Installation Manual Copyright © 2006-2007 by Sielox, LLC. Released July 2007. Published by: Sielox, LLC. 170 East Ninth Avenue Runnemede, NJ 08078 Rev.: DRAFT...
  • Page 2: Table Of Contents

    Retrofit Plate Kit (P/N 7202975) ................8 Installation of AC-1500L Backplanes BP4, BP5 or BP7 ......9 Connectors and Fuses Assignment................10 AC-1500 Controller Modules ..............12 Installing Cables into the Sielox Enclosure ..........13 Signal Cables ..................13 Communications ..................15 Main Controller ......................15 LANLink™........................
  • Page 3: Introduction

    AC-1500 Installation Manual Introduction The AC-1500 Series are Sielox access control and event management controllers. They can be used in a variety of applications such as access control, parking lot, elevator control, time and attendance and others. They are modular and scalable allowing from 2 doors to 8 doors on the same backplane and from 4 to 244 I/O using the I/O backplanes or Reader I/O backplane that combines 2 readers and 32 I/O.
  • Page 4: Controller Features

    AC-1500 Installation Manual Controller Features The Sielox AC-1500 Controller Series is an access control and event management controller, It is powered by a 32-bit microcontroller. It comes with a power supply/UPS/Battery charger module (PR-DUAL) that keeps the unit running in the event of a power failure.
  • Page 5: Installing Sielox Enclosures

    Large Enclosure p/n 7969269 for large backplanes • Small Enclosure p/n 7106307 for small backplanes To install the Sielox enclosures, perform the following procedure: 1. Position the enclosure or template at the desired installation location and mark the four keyhole slot locations for mounting.
  • Page 6: Installing Tamper Switch

    7969269 or in the lower right hand corner of the small enclosure p/n 7106307. The switch provided by Sielox will be installed in this mounting channel. The Tamper Switch must be connected to an Input of an installed controller. This input shall be configured as normally closed with supervision.
  • Page 7: Mounting Plate (P/N 7372565)

    AC-1500 Installation Manual Mounting Plate (P/N 7372565) The AC-1200-MAP mounting plate can be used where an AC-1500 is not being installed in the AC-1200-ENC-32 Enclosure. Not evaluated by UL (The AC-1200-MAP has not been evaluated by UL and is not UL294 compliant.
  • Page 8: Retrofit Plate Kit (P/N 7202975)

    AC-1500 Installation Manual Retrofit Plate Kit (P/N 7202975) AC-1200-RFK (Retrofit Plate Kit). Not evaluated by UL (The AC-1200-RFK has not been evaluated by UL and is not UL294 compliant. Use the AC-1200-ENCS for UL294 compliance.) Page 8 of 33...
  • Page 9: Installation Of Ac-1500L Backplanes Bp4, Bp5 Or Bp7

    AC-1500 Installation Manual Installation of AC-1500L Backplanes BP4, BP5 or BP7 In order to mount the AC-1500 series of backplanes into the enclosure or mounting plate, 12 SEMS screws #6-32 x 5/16 must be used. The enclosure and the mounting plate have threaded studs for the utilization of these screws.
  • Page 10: Connectors And Fuses Assignment

    AC-1500 Installation Manual Connectors and Fuses Assignment Connectors Description J200/J201 AC-1500-CPU (CPU 1 slot) J300/J301 AC-1500-CPU (CPU 2 slot) J302/J303 AC-1500-CPU (CPU 3 slot) J304/J305 AC-1500-CPU (CPU 4 slot) J204/J203 AC-1200-PR5 (Used with AC-1200 only) J205/J206 AC-LAN-COMM or AC-1500-RS485 Primary J209/J210 AC-LAN-COMM or AC-1500-RS485 Secondary (Reserved) J102/J101/J3...
  • Page 11 AC-1500 Installation Manual AC-1500L BP4 Connectors and Fuses location Page 11 of 33...
  • Page 12: Ac-1500 Controller Modules

    AC-1500 Installation Manual AC-1500 Controller Modules AC-1500-CPU CPU Module (Requires AC-1500-RDR) Capacity of AC-1500-OUT • Real Time Clock (RTC) • Data and RTC Battery Backup Output Module • 50K Cards • 8 Outputs • 10K off-line events (Relays- C, NO,NC) AC-1500-RDR Reader Module (requires AC-1500-CPU) •...
  • Page 13: Installing Cables Into The Sielox Enclosure

    Connect signal cables to any reader, door strike, output, input, request-to-exit and door switch. Follow these procedures: 1. Pull signal cables through the Sielox Enclosure. (See table below) 2. When connecting these cables to the AC-1500 reader, input or output modules, form a cable bundle using plastic cable ties (Tie wraps).
  • Page 14 AC-1500 Installation Manual AC-1500 Typical Wiring Field wires connected to a Terminal Controller Page 14 of 33...
  • Page 15: Communications

    AC-1500 Installation Manual Communications The AC-1500 communicates to Pinnacle Hardware Server using RS-485 or Ethernet interfaces. When communicating via RS-485 the AC-1500 can be connected to a Main controller AC- 900 or to the X-LAN. You can also connect the AC-1500 LANLink™ to the Ethernet. Main Controller The Main Controller (MC) is connected to the AC-IF2, the AC-IF2 is an RS-232 to RS-485 converter.
  • Page 16: Lanlink

    AC-1500 Installation Manual LANLink™ The LANLink™ is Sielox’s IP based access control controller; also know as LAN Controller (LC). You can have from 2 to 8 doors per LC. Pinnacle Hardware Server Pinnacle Hardware Server Network Switch Network Switch Ethernet Ethernet AC-1500 LANLink™...
  • Page 17: X-Lan

    AC-1500 Installation Manual X-LAN X-LAN is and Ethernet to RS-485 converter. The X-LAN does not require a Main controller and allows up to 16 TC’s (4 fully populated BP4 backplanes) per Ethernet connection. The X-LAN is and ideal solution for installations that have an Ethernet Network infrastructure, because it reduces the installation cost.
  • Page 18: Installing Lan Module

    AC-1500 Installation Manual Installing LAN Module In order to use this interface you have to plug in the AC-LAN-COMM module to connectors J205 and J206 (RS 485 Primary) located on the backplane. (See Backplane Connector Locations AC-1500 Modules Table). Proper orientation must be observed when installing the module into the connectors, see figures below.
  • Page 19: Connecting The Ethernet Cable

    AC-1500 Installation Manual Connecting the Ethernet Cable 1. Pull the communication cable through the Sielox Enclosure. (See table below) 2. Terminate the CAT5 cable with an RJ-45 connector. 3. Connect the RJ-45. Cable Type Wires Where Used Color Code Max. Dist.
  • Page 20: Installing Rs-485 Module

    AC-1500 Installation Manual Installing RS-485 Module In order to use this interface you have to plug in the AC-1200-RS485 module to connectors J205 and J206 (RS 485 Primary) located on the backplane. (See Backplane Connector Locations AC-1500 Modules Table). Proper orientation must be observed when installing the module into the connectors, see figures below.
  • Page 21: Connecting The Rs-485 Cables

    AC-1500 Installation Manual Connecting the RS-485 Cables 4. Pull the communication cable through the Sielox Enclosure. (See table below) 5. Insert the stripped conductors into the removable RS-485 P (J211) connector and tighten set screws. 6. Observe the polarity. 7. Insert removable connector on the J211 connector.
  • Page 22: Installing The Reader Module (Ac-1500-Rek)

    AC-1500 Installation Manual Installing the Reader Module (AC-1500-REK) The AC-1500-REK is also know as Terminal Controller (TC). Plug in the AC-1500-REK reader module to connectors J200 and J201 (CPU 1) located on the backplane. (See Backplane Connector Locations AC-1500 Modules Table).
  • Page 23 Connect signal cables to any reader, door strike, output, input, request- to-exit and door switch. Follow these procedures: 1. Pull signal cables through the Sielox Enclosure. (See table below) 2. When connecting these cables to the AC-1500 reader, input or output modules, form a cable bundle using plastic cable ties (Tie wraps).
  • Page 24: Transient Suppressor (Door Locks And Outputs)

    AC-1500 Installation Manual Transient Suppressor (Door Locks and Outputs) It is required to install diodes on the electric door locks or other inductive load that is controlled by the TC’s output. See diagram below. Color band denotes Cathode Connect to J11 or J12 (REK), NO or NC pins.
  • Page 25 AC-1500 Installation Manual J8 - Reader 2 J7 - Reader 1 Voltage Selector Voltage Selector +12V +12V J1 - Reader 1 J9 - Reader 2 J10 - Output 4 J2,J3,J4 – Outputs 1, 2 & 3 J11 - Door Strike J12 Door Strike 2 J13, J14 - Inputs J5 - Request-To-Exit...
  • Page 26: Rek Connectors

    AC-1500 Installation Manual REK Connectors Readers 1 & 2 - J1 & J9 Name Wire Color SND BLU Sounder* Blue GND BLK Ground Black PWR RED Power** 1 WHT Data 1 White 0 GRN Data 0 Green LED BRN Brown * For use with AC-125 series of Performa readers.
  • Page 27: Setting The Terminal Controller Address

    AC-1500 Installation Manual Setting the Terminal Controller Address Each Terminal Controller (TC) needs a unique address. Locate the SW1 rotary switch on the REK. (See REK Address Switch SW1 Position TC Address Notes: If using a Main Controller the address of the first TC has to be 2 or higher, the MC is also a TC and it uses address 1.
  • Page 28: Status Led Reader Board (Top Board Of Rek)

    AC-1500 Installation Manual Status LED Reader Board (Top board of REK) Description Outputs Indicates output 1 (OUT1) is in the energized state when lit. Indicates output 2 (OUT2) is in the energized state when lit. Indicates output 3 (OUT3) is in the energized state when lit. Indicates output 4 (OUT4) is in the energized state when lit.
  • Page 29: Ram And Real Time Clock Backup Battery

    AC-1500 Installation Manual RAM and Real Time Clock Backup Battery The AC-1500-REK has a Lithium battery which holds the TC database, transactions and Real Time Clock in the event of AC loss. This battery needs to be checked on annual basis by the field technician with a voltmeter, during preventive maintenance.
  • Page 30: Power Cables

    Max. Dist. Belden 1307A Power / Battery Red/Black 50 ft. DC-IN Connection AC Power Surge Suppressor Sielox highly recommends the use of an AC power surge suppressor such as Ditek-1F. For more information go to http://www.ditekcorp.com/product-details.asp?ProdKey=11 Page 30 of 33...
  • Page 31: Installing The Power Regulator Module Ac-1500-Prdual

    AC-1500 Installation Manual Installing the Power Regulator Module AC-1500-PRDual This Sielox module is a voltage regulator and UPS (Uninterruptible Power Supply) when you connect and external sealed lead acid battery and has the following features: • 12 VDC and 6 VDC regulator •...
  • Page 32: Connecting The 12 Volts Battery

    AC-1500 Installation Manual Fuses Table Fuse Description DC In Fuse (5 Amp) Battery Fuse (5 Amp) Plug in the AC-1500-PRDual module to connectors J101 and J102 (PR12) located on the backplane (See Backplane Connector Locations AC-1500 Modules Table). Proper orientation must be observed when installing the module into the connectors, see figures below.
  • Page 33: Monitoring Ac Fail

    AC-1500 Installation Manual Monitoring AC Fail If you want to monitor AC fail connect the white wire to one of the available TC inputs. Note: You have to configure the input “Secure State” under Input Properties in Pinnacle as well the input description. See Pinnacle User Manual for more information. AC-Fail Input Secure State AC-Fail Input Description Page 33 of 33...
