VERIFY THE CONTENTS INSIDE PACKAGE BOX
The package should contain the items plus VIP-254NT. If any item is missing or damaged, please contact the seller immediately.
Quick Installation Guide
Step 1. Handset Connection
Plug Handset Core with Handset and Handset Jack
Step 2. Connecting Power Adapter and Network
Plug RJ-45 Cable with WAN port and Switch/Hub
DC
LAN/PC
WAN
TEL IN
NOTE :
Use only the power adapter shipped with the unit to ensure correct functionality
Quick Guide
CD-ROM
Handset
Handset Core
RJ-11 cable
RJ-45 cable
Handset
DC
LAN/PC
WAN
VIP-254NT
Power Adapter
