MEFA SPEDYTOR User Manual

THERMAL PRINTER
MEFA SPEDYTOR
USER'S MANUAL

PRINTER COMPONENTS

PAPER
CONTAINER
COVER
OPENING
BUTTON
FOR PAPER
CONTAINER
POWER ON INDICATOR
PRINTER STATUS INDICATOR
The panel has two buttons and three LEDs.
Power on indicator (left green LED - ON).
The indicator lights when the printer is on.
Printer power button (on / off).
Briefly pressing the button when the printer is turned off turns the
printer on. If the eject button is released during power up, the printer
enters normal operation mode. Turning the printer on with the paper
feed button pressed will activate the special mode.
ON BAT LF
The signaling diode flashes alternately white and the color indicating the mode.
To change the mode, press the power button briefly. To confirm the selection,
POWER SOCKET
briefly press the paper feed button. To turn off the printer, press and hold the
power button for longer.
USB INTERFACE
WHITE / GREEN PRINT TEST

CONTROL PANEL

LF
BATTERY STATUS INDICATOR
Pressing the button and holding it down for more than 1 second while the
printer is on turns off the printer. After proper configuration, the printer can also
(ONLY FOR PRINTER WITH BATTERY)
turn off automatically after a certain period of inactivity.
Paper eject button.
Briefly pressing the button in normal operation mode ejects the paper one line.
Holding the button down causes a continuous stroke, lasting until the button is
released.
Printer status indicator (multicolor LED).
With normal and correct operation of the printer, the indicator lights up steadily
and its color indicates the active interface through which the printer receives
data
- BLUE / GREEN : USB
- BLUE : Bluetooth.
Printer sleep
After proper configuration, the printer can be put to sleep to save energy while
being ready for use. In sleep mode, the status indicator goes off.
The printer wakes up when one of the selected data sources is activated.

INCLUDED

1. Printer
2. Power supply
3. USB cable
4. Roll of 105mm x 40mb label paper
5. Stand for the JUMBO roller
6. User manual and warranty card
CONTROL PANEL
Signaling Printer Status
SIGNALLING NAME
WHITE / BLUE DATA DUMP
WHITE / RED MASS
MEMORY
WHITE / SETTINGS
ORANGE
DESCRIPTION
Printing, print test.
Storing printed data in a file.
Access to configuration files and data dump,
software update.
Basic settings menu.
