Ultra Z Series Installation

Replacement Parts / Pièces de rechange / Repuestos
NO. Description
1 Diverter Knob & Rod Assembly
2 Deck Spout Set Screw & Allen Key
3 Handle
4 Bush &Screw Assembly
5 Handle Base Assembly
6 Base Assembly
7 Aerator
8 Base Assembly
9 Shower Base Assembly
10 Hand Shower
11 Hand Shower Set Screw & Allen Key
1
2
3
4
5

Limited Lifetime Warranty

Ultra Faucets warrants to the original purchaser that its products will be free from defects in workmanship and materials. All Ultra
Faucets are provided with a life time limited warranty. This warranty does not cover any other labor or service charges associated with
the removal, repair, or reinstallation of Ultra Faucets products. This express warranty does not apply to products that have been
damaged as a result of misuse, abuse, negligence, accident, faulty installation or maintenance practices and/or used in any manner
contrary to those recommended by the manufacturer.
Need help? Please call our toll-free customer service line at 1-888-658-5872 for additional assistance or service.
Besoin d'aide? Veuillez communiquer avec notre service à la clientèle au numéro gratuit 1-888-658-5872 pour tous renseignements
ou services complémentaires.
¿Requiere asistencia? Llame a nuestro Servicio al Cliente, sin costo, al 1-888-658-5872 para asistencia adicional o servicio.
Part No.
9Q225000CP/AP/HA
9Q1350NT
5C0001500CP0
9Q224700PL
9Q224800CP/AP/HA
9Q224900CP/AP/HA
5E0M0115PL
9Q225200CP/AP/HA
9Q225100CP/AP/HA
5F0001400CP0
9Q1349NT
11 10
9
8
6 7
Z Series
UF65440
UF65443
Roman Tub with Hand Shower
UF65445
Installation/Installation/Instalación
CUSTOMER SERVICE
TOLL-FREE 1-888-OK-ULTRA (658-5872)
Tools You Will Need / Outils dont vous aurez besoin / Herramientas necesarias
• If you use soldering for the installation of the faucet, the seats, cartridges and washers will have to be removed
before using flame. Otherwise, warranty will be void on those parts.
• Cover your drain to avoid losing parts.
• 0℃~55℃.
• Si vous posez le robinet par brasage, il est essentiel de retirer les sièges, les cartouches et les rondelles avant
d'appliquer la flamme, faute de quoi la garantie sur ces pièces sera annulée.
• Couvrez le drain pour ne pas perdre des pièces.
• 0℃~55℃.
• En el caso de utilizar soldadura para instalar el grifo, remueva los asientos, cartuchos y arandelas antes de usar la
llama. De lo contrario, se anulará la garantía para esos componentes.
• Tape la boca del desagüe para prevenir la pérdida de piezas pequeñas.
• 0℃~55℃.
Adjustable Wrench Phillips Screwdriver
Clé à molette Tournevis cruciforme
Llave ajustable Destornillador cruciforme

SAFETY TIPS

CONSIGNES DE SÉCURITÉ
CONSEJOS DE SEGURIDAD
UF65440
UF65443
UF65445
Groove join pliers
Pince multiprise
Pinzas ajustables
