Applicable Standards/Codes
IAPMO certified to meet or exceed the following:
● ASME A112.18.1/CSA B125.1
● Uniform Plumbing Code
● National Plumbing Code of Canada
● NSF/ANSI 61
● Section 116875 of the California Health & Safety Code
● EPA WaterSense
● ADA Compliant
Installation Dimensions
1
1 13/16 ＂
1 5/16 ＂ - 1 1/2 ＂
Length 30 1 1/16 ＂
15122868-B
UF3770X
NSF/ANSI 61
7 3/8 ＂
5 3/16 ＂
2 1/8 ＂
6 3/8 ＂
9/16-24 UNEF
1 1/4 ＂
4
Installation Instructions
RIFT Collection
Single Handle Lavatory Faucet
For easy installation of your faucet you will need:
● To read all the installation completely before beginning.
● To read all warnings, care, and maintenance information.
UF3770X
NSF/ANSI 61
15122868-B
Advertisement
Related Manuals for Ultra RIFT UF3770X
Summary of Contents for Ultra RIFT UF3770X
- Page 1 UF3770X UF3770X Installation Instructions Applicable Standards/Codes IAPMO certified to meet or exceed the following: NSF/ANSI 61 ● ASME A112.18.1/CSA B125.1 ● Uniform Plumbing Code ● National Plumbing Code of Canada RIFT Collection ● NSF/ANSI 61 ● Section 116875 of the California Health & Safety Code Single Handle Lavatory Faucet ●...
- Page 2 UF3770X thumbscrew Stopper Extension Clip Pivot rod Pivot nut Installation Instructions Seal "P" trap Assemble pivot rod, pivot nut, clip and seal as shown. Hand tighten pivot nut. Drop stopper into drain. (For vandal proof drain rotate stopper so pivot rod goes through eye of stopper. Make connection to "P" trap.) Remove one end of clip from pivot rod by squeezing ends together while sliding.
