Summary of Contents for Pentair Pool Products Blaulain Recambios FLECK 5000SE

  • Page 1 Recambios FLECK 5000SE 6600 4600 6700XTR 5600 7700 5600SXT www.blaulain.com blaulain@blaulain.com...
  • Page 2 FLECK RECAMBIOS. VÁLVULAS. 5000SE P. 03 4600 / 5600 P. 15 5600SXT P. 22 6600 P. 44 6700XTR P. 56 7700 P. 82 www.blaulain.com blaulain@blaulain.com...
  • Page 3 MODEL 5000SE Upflow Brining Service Manual IMPORTANT: Fill in pertinent information on page 2 for future reference.
  • Page 4 MODEL 5000SE Upflow Valve Powerhead Assembly (See opposite page for parts list) Page 16 Printed in U.S.A.
  • Page 5 MODEL 5000SE Upflow Valve Powerhead Assembly Parts List Item No. Quantity Part No. Description 1 ... 1 ... 18201-025 ... . Plate, Front 2 .
  • Page 6 MODEL 5000SE Upflow Control Valve Assembly (See opposite page for parts list) Page 18 Printed in U.S.A.
  • Page 7 MODEL 5000SE Upflow Control Valve Assembly Parts List Item No. Quantity Part No. Description 1 ... . 1 ... . . 18815 ....Valve Body, 5000, 1″, Dist. 18815-20 .
  • Page 8 MODEL 5000SE Upflow 3/4″ Turbine Meter Assembly (See opposite page for parts list) VALVE Page 20 Printed in U.S.A.
  • Page 9 MODEL 5000SE Upflow 3/4″ Turbine Meter Assembly Parts List Item No. Quantity Part No. Description 1 ... 1 ... 19797 ....Meter Body Assembly 2 .
  • Page 10 MODEL 5000 2310 Safety Brine Valve (See opposite page for parts list) Page 22 Printed in U.S.A.
  • Page 11 MODEL 5000 2310 Safety Brine Valve (Cont’d.) Item No. Quantity Part No. Description 1 ... 1 ... 19645 ....Safety Brine Valve Body 2 .
  • Page 12 MODEL 5000SE Upflow By-Pass Valve Assembly, Plastic Parts List Item No. Quantity Part No. Description 1 ... 1 ... 19723 ....By-Pass Valve Body, Plastic 2 .
  • Page 13 MODEL 5000 By-Pass Valve Assembly, Brass Parts List Item No. Quantity Part No. Description 1... 1 ... .17290 ....By-Pass Valve Body, 3/4″ 1 .
  • Page 14 MODEL 5000SE Upflow Valve Wiring Diagram CB1 - 5000SE Circuit Board VDM - Valve Drive Motor EM - Electronic Flow Meter (Optional) SW1 - Homing Switch SW2 - Step Switch HCAM - Homing Cam DFSCAM - Downflow Step Cam Page 26 Printed in U.S.A.
  • Page 15 4600 & 5600 5 6 0 0 4 6 0 0 MANUEL D’UTILISATION....P.2 SERVICE MANUAL ......P.10 BEDIENUNGSANLEINTUNG....P.18 MANUAL DE USO ......P.26 MANUALE DI USO ......P.34 HANDLEIDING VOOR GEBRUIK ..P.42...
  • Page 16 6 - TÊTE DE COMMANDE / POWER HEAD / STEUERKOPF / CABEZA DE MANDO / PANNELLO DI COMMANDO / PROGRAMMEERKOP Pièces spécifiques à la version chronométrique Parts specifically for timeclocked version Spezifische Teile zur zeitgesteuerten Ausführung Piezas específicas de la versión cronométrica Pezzi specifici della versione cronometrica Specifieke onderdelen voor de chronometrische versie ITEM...

  • Page 17: Tête De Commande

    6 - TÊTE DE COMMANDE / POWER HEAD / STEUERKOPF / CABEZA DE MANDO / PANNELLO DI COMMANDO / PROGRAMMEERKOP ITEM DESCRIPTION DESIGNATION 40422 Wire nut Connecteur 11545 European power cord Cordon d’alimentation européen 24544 Kit meter cable delayed 8 m Kit câble de compteur retardé...

  • Page 18: Corps De Vanne

    7 - CORPS DE VANNE / VALVE BODY / VENTILKÖRPER / CUERPO DE LA VÁLVULA / CORPO DELLA VALVOLA / LICHAAM VAN DE KLEP Corps 4600 Valve body 4600 Ventilkörper 4600 Cuerpo 4600 Corpo 4600 Lichaam 4600 ITEM DESCRIPTION DESIGNATION 12112 Screw 13546...
  • Page 19 8 - COMPTEURS & ACCESSOIRES / METERS & ACCESSORIES / WASSERZÄHLER & ZUBEHÖRE / CONTADOR & ACCESORIOS / CONTATORE & ACCESSORI / WATERMETER EN TOEBEHOREN ITEM DESCRIPTION DESIGNATION 12473 Screw 14038 Meter cover assembly 8m Couvercle compteur assemblé 8m 13847 O’ring Joint torique 13509...
  • Page 20 9 - ENCOMBREMENTS / DIMENSIONS / SKIZZE / DIMENSIONES / INGOMBRO / DIMENSIES ß 4600 5600 4600 & 5600...
  • Page 21 Résultats des tests sur demande Performances results available upon request Ergebnis der Testversuche auf Anfrage erhältlich Resultado de los test bajo demanda Risultati dei testi su richiesta Testresultaten op aanvraag 4600 & 5600...
  • Page 22 Model 5600SXT Downflow Service Manual IMPORTANT: Fill in Pertinent Information on Page 3 for Future Reference...

  • Page 23: Control Valve Assembly

    Control Valve Assembly Page 24...
  • Page 24 Control Valve Assembly Item No. Quantity Part No. Description 1 ......2-4 ......13255 .........Adapter Clip (Clock or Meter) 2 ......5 ......13242 .........Seal ......5 ......40628 .........Seal, 559PE 3 ......1 ......61400-12 ......Valve Body Assembly, 1 Dist......1 ......61400-11 ......Valve Body Assembly, 3/4 Dist. 4 ......1 ......
  • Page 25 Valve Powerhead Assembly 61501-56SE REVA Page 26...
  • Page 26 Valve Powerhead Assembly Item No. Quantity Part No. Description 1 ..... 1 .......14448-100 ....Drive Housing Assy, with Pin, 56SXT 2 ..... 2 .......12473 ......Screw, Hex Wsh 10-24 x 5/8 3 ..... 1 .......19474 ......Harness, Power, 56SXT, Elect 4 ..... 1 .......13299 ......Washer, Spring, 3/8 5 .....
  • Page 27 3/4” Turbine Meter Assembly Item No. Quantity Part No. Description 1 ....2 ....13314 ......Screw, Hex Washer, 8-18 x 5/8 2 ....2 ....19569 ......Clip, Flow Meter 3 ....1 ....19797 ......Meter Body Assembly, 3/4” Turbine 4 ....4 ....13305 ......O-ring, 119 5 ....

  • Page 28: Bypass Valve Assembly (Plastic)

    Bypass Valve Assembly (Plastic) Item No. Quantity Part No. Description 1 ....2 ....13305 ......O-ring, -119 2 ....2 ....13255 ......Clip, Mounting 3 ....2 ....13314 ......Screw, Hex Washer Head, 8-18 x 5/8 4A ....1 ....18706 ......Yoke, Plastic, 1” NPT ..........

  • Page 29: Bypass Valve Assembly (Metal)

    Bypass Valve Assembly (Metal) Item No. Quantity Part No. Description 1 ....1 ....17290 ......Bypass Valve Body, 3/4” ..... 1 ....17290NP ....Bypass Valve Body, 3/4” Nickel Plated ..... 1 ....13399 ......Bypass Valve Body, 1” ..... 1 ....13399NP ....Bypass Valve Body, 1”, Nickel Plated 2 ....

  • Page 30: 2300 Safety Brine Valve

    2300 Safety Brine Valve Item No. Quantity Part No. Description 1 ....1 ....11942 ......Brine Valve Body 1/4” NPT 2 ....1 ....10138 ......Ball, 3/8” 3 ....1 ....11566 ......Bull Stop 4 ....1 ....10328 ......Elbow, 1/4” x 1/4” T 5 ....

  • Page 31: 2310 Safety Brine Valve

    2310 Safety Brine Valve Item No. Quantity Part No. Description 1 ....1 ....19645 ......Safety Brine Valve Body 2 ....1 ....19803 ......Safety Brine Valve Arm Assembly 3 ....1 ....19804 ......Stud, 10-24 4 ....1 ....19805 ......Nut, 10-24 5 ....

  • Page 32: Wiring Diagram

    Wiring Diagram Page 40...
  • Page 33 Model 5600SXT Upflow Service Manual IMPORTANT: Fill in Pertinent Information on Page 3 for Future Reference...
  • Page 34 Control Valve Assembly 61500-6600-6700_UF_REVB Page 24...
  • Page 35 Control Valve Assembly Item No. Quantity Part No. Description 1 .......1 ......19707-30 ......Valve Body, 5600 Upflow, Bayonet 2 .......1 ......13255 ......Clip, Mounting 3 .......5 ......13242 ......Seal, 5600 4 .......1 ......13304 ......O-ring, -121 5 .......1 ......12281 ......O-ring, -338 6 .......4 ......14241 ......
  • Page 36 Valve Powerhead Assembly 61501-56SE_REVA Page 26...
  • Page 37 Valve Powerhead Assembly Item No. Quantity Part No. Description 1 ..... 1 .......14448-100 ....Drive Housing Assy, with Pin, 56SXT 2 ..... 2 .......12473 ......Screw, Hex Wsh 10-24 x 5/8 3 ..... 1 .......19474 ......Harness, Power, 56SXT, Elect 4 ..... 1 .......13299 ......Washer, Spring, 3/8 5 .....
  • Page 38 3/4” Turbine Meter Assembly Item No. Quantity Part No. Description 1 ....2 ....13314 ......Screw, Hex Washer, 8-18 x 5/8 2 ....2 ....19569 ......Clip, Flow Meter 3 ....1 ....19797 ......Meter Body Assembly, 3/4” Turbine 4 ....4 ....13305 ......O-ring, 119 5 ....
  • Page 39 Bypass Valve Assembly & Yokes (Plastic) Item No. Quantity Part No. Description 1 ....2 ....13305 ......O-ring, -119 2 ....2 ....13255 ......Clip, Mounting 3 ....2 ....13314 ......Screw, Hex Washer Head, 8-18 x 5/8 4A ....1 ....18706 ......Yoke, Plastic, 1” NPT ..........
  • Page 40 Bypass Valve Assembly (Metal) Item No. Quantity Part No. Description 1 ....1 ....17290 ......Bypass Valve Body, 3/4” ..... 1 ....17290NP ....Bypass Valve Body, 3/4” Nickel Plated ..... 1 ....13399 ......Bypass Valve Body, 1” ..... 1 ....13399NP ....Bypass Valve Body, 1”, Nickel Plated 2 ....
  • Page 41 2300 Safety Brine Valve Item No. Quantity Part No. Description 1 ....1 ....11942 ......Brine Valve Vody 1/4” NPT 2 ....1 ....10138 ......Ball, 3/8” 3 ....1 ....11566 ......Bull Stop 4 ....1 ....10328 ......Elbow, 1/4” x 1/4” T 5 ....
  • Page 42 2310 Safety Brine Valve Item No. Quantity Part No. Description 1 ....1 ....19645 ......Safety Brine Valve Body 2 ....1 ....19803 ......Safety Brine Valve Arm Assembly 3 ....1 ....19804 ......Stud, 10-24 4 ....1 ....19805 ......Nut, 10-24 5 ....
  • Page 43 Wiring Diagram Page 46...
  • Page 44 MODEL 6600 Downflow Brining Service Manual IMPORTANT: Fill in pertinent information on page 2 for future reference.
  • Page 45 MODEL 6600 Downflow Valve Wiring Diagram Page 13 Printed in U.S.A.
  • Page 46 MODEL 6600 Downflow Valve Powerhead (See Opposite Page For Parts List) Page 14 Printed in U.S.A.
  • Page 47 MODEL 6600 Downflow Valve Powerhead Parts List Item No. Quantity Part No. Description 1... 1 ... 26001-02 ... . . Drive Housing, Black 2.
  • Page 48 MODEL 6600 Downflow Control Valve Assembly - Downflow Brining (See Opposite Page For Parts List) Page 16 Printed in U.S.A.
  • Page 49 MODEL 6600 Downflow Control Valve Assembly - Downflow Brining Parts List Item No. Quantity Part No. Description *1... . 2 ... . . 13255....Adapter Clip 2.
  • Page 50 MODEL 6600 Downflow Meter Assembly Item No. Quantity Part No. Description 1 ... 1... . 13821....Meter Body 2 .
  • Page 51 MODEL 6600 Downflow By-Pass Valve Assembly, Brass Item No. Quantity Part No. Description ″ 1... 1 ... 17290 ....By-Pass Valve Body, 3/4 ″...
  • Page 52 MODEL 6600 Downflow By-Pass Valve Assembly, Plastic Item No. Quantity Part No. Description 1 ... . 1... . . 19723 ....By-Pass Valve Body, Plastic 2 .
  • Page 53 MODEL 6600 Downflow 2300 Safety Brine Valve Item No. Quantity Part No. Description 1... 1 ... 60027-00 ... . . 2300 Safety Brine Valve Body ″...
  • Page 54 MODEL 6600 Downflow 2310 Safety Brine Valve (See Opposite Page For Parts List) Page 22 Printed in U.S.A.
  • Page 55 MODEL 6600 Downflow 2310 Safety Brine Valve Parts List Item No. Quantity Part No. Description 1... 1 ... 19645 ....Safety Brine Valve Body 2.
  • Page 56 6700XTR Downfl ow Service Manual IMPORTANT: Fill in Pertinent Information on Page 3 for Future Reference...
  • Page 57 6700XTR Powerhead Assembly 61501-6700_REVC Page 20...
  • Page 58 6700XTR Powerhead Assembly Item No. Quantity Part No. Description 1 ....1 ....15494-04 ....Drive Panel Assy, 6700 2 ....1 ....17844 ......Bracket, Support, 6700 3 ....1 ....13299 ......Washer, Spring, 3/8 4 ....1 ....13017 ......Gear, Idler 5 ....1 ....23045 ......Gear, Drive, 6700 6 ....1 ....

  • Page 59: Control Valve Assembly

    Control Valve Assembly 61500-6600-6700_DF_REVB Page 22...
  • Page 60 Control Valve Assembly Item No. Quantity Part No. Description 1 ....1 ......19700-10 ....Valve Body, 5600, Downflow 2 ....2 ......13255 ......Clip, Mounting 3 ....5 ......13242 ......Seal, 5600 4 ....1 ......13304 ......O-ring, -121 5 ....1 ......12281 ......O-ring, -338 6 ....4 ......14241 ......

  • Page 61: Meter Assembly

    Meter Assembly 60086_REVD_60086-50 Item No. Quantity Part No. Description 1 ....1 ....13874 ......Cap, Meter, Electronic 2 ....1 ....14715 ......Gear Assy, Electronic Meter Cap 3 ....1 ....41055 ......Plate, Intermediate 4 ....1 ....13847 ......O-ring, -137, Std, Meter 5 ....5 ....17798 ......Screw, Slot Hex Wsh Hd 6 ....1 ....
  • Page 62 Bypass Valve Assembly, Non-Metallic 60049_REVD Item No. Quantity Part No. Description 1 ....2 ....13305 ......O-ring, -119 2 ....2 ....13255 ......Clip, Mounting 3 ....2 ....13314 ......Screw, Slot Ind Hex, 8-18 x .60 4A ....1 ....18706 ......Yoke, 1”, NPT, Plastic ..........
  • Page 63 Bypass Valve Assembly, Brass 60040SS_REVL 60041_REVK Item No. Quantity Part No. Description 1 ....1 ....40614 ......By-pass Body, 3/4” .......... 40634 ......By-pass Body, 1”, SS 2 ....1 ....14105 ......Seal, By-pass, 560CD 3 ....1 ....11972 ......Plug, By-pass 4 ....1 ....11978 ......Plate, By-pass, Top 5 ....1 ....
  • Page 64 2300 Safety Brine Valve 60027_REVA Item No. Quantity Part No. Description 1 ....1 ....60027-00 ....Safety Brine Valve, 2300 Less Elbow 2 ....1 ....10138 ......Ball, 3/8” Brass 3 ....1 ....11566 ......Ball Stop, Slow-Fill 4 ....1 ....10328 ......Fitting, Elbow, 90 Deg. 1/4 NPT x 3/8 T 5 ....2 ....
  • Page 65 2310 Safety Brine Valve 42112_REVA Item No. Quantity Part No. Description 1 ....1 ....19645 ......Body, Safety Brine Valve, 2310 2 ....1 ....19803 ......Safety Brine Valve, Arm Assy 3 ....1 ....19804 ......Screw, Sckt Hd, Set, 10-24 x .75 4 ....1 ....
  • Page 66 Valve Wiring Diagram Page 35...

  • Page 67: Service Assemblies

    Service Assemblies Air Check: Pistons: 60002-34 ..Air Check, #500, 34” Long 60102-71 ..Piston Assy, 6600, Downflow Brining and Rapid Rinse Brine Line Flow Control: 14309....Retainer, Piston Rod 60022-12 ..BLFC, .125 GPM, 5000/5600/9000 13001-04 ..Piston Rod Assy, 6600, Downflow 60022-25 ..
  • Page 68 Service Manual...
  • Page 70 .................................... 4 ........................................................................................................................
  • Page 72 ..................................................4 ......................................4 ............................................................................................................................
  • Page 73 Injector Cap Regulated, 20 PSI TORQUE - 9.0 IN-LBS 10% TORQUE - 5.5 IN-LBS 10% ....................................4 .................................................................
  • Page 74 ....................................... 4 ....4 ................................
  • Page 75 ....................................4 ....................................................4 ............4 ............4 ............4 ....................
  • Page 76 ..................................................................................
  • Page 77 ................................................. 4 ............................................................................................
  • Page 78 .................................... 4 ..................................................................................................4 .........
  • Page 79 ....................................4 .........................................................................................................................
  • Page 80 Valve Wiring Diagram...
  • Page 81 ....Meter: ........................................................................................
  • Page 82 7 7 0 0...

  • Page 83: Connexion De La Carte

    7 - CONNEXION DE LA CARTE CONNEXION OF THE CARD / BEFESTIGUNG DER ELEKTRONIK / CONEXIÓN DE LA TARJETA / CONNESSIONE DELLA SCHEDA ELETTRONICA ITEM DÉSIGNATION DESCRIPTION BEZEICHNUNG DESCRIPCIÓN DESCRIZIONE Carte électronique Circuit board μP Karte Circuito electronico Scheda elettronica Moteur Motor Motor...

  • Page 84: Démontage Et Remontage

    8 - DÉMONTAGE ET REMONTAGE ASSEMBLY AND REMOVAL / MONTAGE UND DEMONTAGE / DESMONTAJE Y MONTAJE / SMONTAGGIO E RIMONTAGGIO LA CARTE / THE BOARD / DIE ELEKTRONIK / LA TARJETA / LA SCHEDA Débrancher toutes les connexions à la carte. Retirer la vis qui maintient la carte électronique. Pousser la carte vers la gauche et la soulever en même temps.
  • Page 85 8 - DÉMONTAGE ET REMONTAGE ASSEMBLY AND REMOVAL / MONTAGE UND DEMONTAGE / DESMONTAJE Y MONTAJE / SMONTAGGIO E RIMONTAGGIO Boîte d’engrenage principale / Main gearbox / Hauptantrieb Caja de engranajes principal Fig.1 A l’aide d’une clé hexagonale 10, tourner la came à cycle dans le sens de la flèche (anti-horaire) afin d’aligner les flèches (A) et (B).
  • Page 86 10 - TÊTE DE COMMANDE POWER HEAD / STEUERKOPF / CABEZA DE MANDO / TESTA DI COMMANDO ITEM QTY DESCRIPTION DÉSIGNATION BU28364 Cover assembly Couvercle assemblé 28366 Electronic circuit board Carte électronique 28365 Main drive gear assembly Ensemble d’engrenage 40967 Screw BR40980 Back plate Platine...
  • Page 87 11 - CORPS DE VANNE VALVE BODY / VENTILKÖRPER / CUERPO DE LA VÁLVULA / CORPO DELLA VALVOLA ITEM QTY DESCRIPTION DÉSIGNATION 40916 Valve body without mixing machining Corps de vanne sans l’usinage mixing 41457 Valve body with mixing machining Corps de vanne avec l’usinage mixing 18303-01 O’ring...

  • Page 88: Compteur & Accessoires

    12 - COMPTEUR & ACCESSOIRES METER & ACCESSORIES / WASSERZÄHLER & ZUBEHÖRE / CONTADOR & ACCESSORIOS / CONTATORE & ACCESSORI ITEM QTY DESCRIPTION DÉSIGNATION 26217 Cover Pro2 assy, with clear window , grey Couvercle Pro2 assy, avec fenêtre, gris 40945 Retainer clip, DLFC Clip de maintien de sortie d’égout, DLFC Compteur assemblé...
  • Page 89 13 - ENCOMBREMENT ß VALVE DIMENSIONS / MA SKIZZE / DIMENSIONES / INGOMBRO Résultats des tests sur demande / Test results available on request / Ergebnis der Testversuche auf Anfrage erhältlich / Resultado de los test bajo demanda / Risultati dei testi su richiesta 7700...
