Thank You
for your purchase of one of the finest marine power packages
available. It incorporates numerous design features to assure
operating ease and durability.
With proper care and maintenance, you will thoroughly enjoy using
this product for many boating seasons. To ensure maximum
performance and carefree use, we ask that you thoroughly read this
manual.
The Operation, Maintenance & Warranty Manual contains specific
instructions for using and maintaining your product. We suggest that
this manual remain with the product for ready reference whenever
you are on the water.
Again, thank you for purchasing one of our Mercury Marine products.
We sincerely hope your boating will be pleasant!
Warranty Message
The product you have purchased comes with a limited warranty from
Mercury Marine; the terms of the warranty are set forth in the
Warranty Information section of this manual. The warranty
statement contains a description of what is covered, what is not
covered, the duration of coverage, how to best obtain warranty
coverage, important disclaimers and limitations of damages, and
other related information. Please review this important information.
Mercury Racing,
N7480 County Road "UU"
Fond du Lac, WI 54935-9585
i
7406
