LED Connector Module ZL-CM08L120
Cables and PLC I/O Modules
PLC Type
Cable Type
DL205
ZL-2CBL1
WARNING : WIRE ONLY ACCORDING TO WIRING DIAGRAMS SHOWN BELOW TO
AVOID CAUSING DAMAGE TO THE PLC OR CONNECTOR MODULE. MATCH THE
CORRECT COMBINATION OF CABLE, PLC I/O MODULE, AND CONNECTOR MODULE AS SHOWN.
EXAMPLE CONNECT
TYPE CONNECTION FOR SENSOR DC
CONFIGURATION NPN
C 0 1 2 3 4 5 6
A2A2A2 A2A2A2 A2A2
A1A1 A1A1 A1
TYPE
A
ZL-CM08L120
PLC I/O Module Type
D2-08NA-1
-
A1
A1A1
SENSOR DC
TYPE
AT1-AN-1A
Connector Module Type
ZL-CM08L120
TYPE CONNECTION FOR SENSOR DC
A2A2A2 A2A2A2 A2A2
A1A1 A1A1 A1
TYPE
B
PAG. 1
CONFIGURATION PNP
C 0 1 2 3 4 5 6
-
A1
A1A1
SENSOR DC
TYPE
AT1-AP-1A
REV 1.1
