Nemschoff Palisade 2.0
USB Charging Unit Installation Instructions
How to assemble USB charging unit
Tools Required
Power Drive
Step 1
1.1 Slide the clip-on nuts in place.
Nemschoff for Palisade 2.0
Slip Clip
Parts Included
UBI Hub Assembly
Mounting Plate
Slip Clip
Wire Tie
#6 Philips Flat
Head Screw
Velcro
Step 2
2.1 Attach mounting plate to USB body.
Flat Head Screw
1
1BNVLY rev B
Class 2 Power Unit
Power Unit Plug
Cable Clip
Cable Clamp
#8-32 Flat
#8 Screw
Head Screw
Mounting Plate
Assembly Instructions
