Operation and Parts Breakdown
Model
Torque
1990
60 in / lbs
1992
80 in / lbs
1994
80 in / lbs
Socket Size
5/16"
5/16"
3/8"
Tools Needed
Wheeler­Rex  ●  Ashtabula, Ohio
1­800­321­7950  ●  www.wheelerrex.com
5/32" Allen Wrench
Torque Wrench
(must read inch pound)
5/8" Open End Box Wrench
Allen Socket
5/16" or  3/8"

Advertisement

loading
Need help?

Need help?

Do you have a question about the TwinTite 1992 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wheeler-Rex TwinTite 1992

  • Page 1 Tools Needed  5/32” Allen Wrench  Operation and Parts Breakdown Torque Wrench  (must read inch pound)  5/8” Open End Box Wrench  Allen Socket  5/16” or  3/8”  Model  Torque  Socket Size  1990  60 in / lbs  5/16"  1992  80 in / lbs  5/16”  1994  80 in / lbs  3/8"  Wheeler­Rex  ●  Ashtabula, Ohio  1­800­321­7950  ●  www.wheelerrex.com ...
  • Page 2 Attaching the TwinTite  1. Place wire form (# 701155)  4. Squeeze wire form to fit  around handle of drill.  snug against drill handle,  then tighten screws (2) with  5/32” allen wrench located  in wire holder.  2. Put wire form ends through  5. Place top strap (# 701152),  holes in wire holder  bottom strap (# 701153),  (# 701154).  and two screws (# 275131)  on wire form so that the  screws can be tightened  from outside the drill  handle.  Note: The grooves in the  straps should face each  other to form a circular shape.  6. Tighten both screws with  3. Place hex stem of TwinTite  5/32” allen wrench in top &  in drill chuck & tighten.  bottom strap; make sure  that the wire form is seated  Note: Wire form may need to  in the grooves of the top &  be bent slightly to fit your  bottom strap. Wire form can  make & model of drill.  be cut if it extends past  TwinTite body.  Wheeler­Rex  ●  Ashtabula, Ohio  1­800­321­7950  ●  www.wheelerrex.com...
  • Page 3 Checking Torque Specs  Operating the TwinTite  1. Place drill drive direction in reverse to tighten fasteners.  1. Place drill in vise & lightly  clamp to hold drill hands  free.  2. Put TwinTite sockets on the no­hub coupling fasteners. One  side may slide on before the second will line up. Slowly press  trigger on drill allowing the TwinTite to turn and the second  socket will then line up.  2. Hold drill chuck with one  hand while using torque  wrench with allen socket to  see what the current torque  limit is.  Model  Torque  Socket Size  1990  60 in / lbs  5/16"  1992  80 in / lbs  5/16”  1994  80 in / lbs  3/8" 3.To increase torque setting:  Hold drill chuck while using  a 5/8” open end box wrench  to tighten adjusting nut  3. Pull trigger to the full on position to tighten both fasteners.  (#701145), and repeat step 2.  When a fastener has met the torque setting a ‘clicking’  Note: Tighten the adjusting nut  sound will be heard, and the socket will stop moving. Do not  slightly; the torque will quickly  stop tightening until the second fastener has reached the  increase. To decrease torque  torque limit. At this point both sockets will not be rotating, ...
